This Owner’s/Operator’s Manual is designed to familiarize the operator with the various features
and component parts of the equipment and to assist you with the assembly, operation and mainte-
nance of your new Hand-held Blower.
It is essential that any operator of this Hand-held Blower product reads and understands
the contents of this manual before using the Hand-held Blower.
Important safety instructions will be identified by the following safety symbol:
Failure to comply with the instructions in this manual may result in serious injury or death.
For additional assistance, contact any local authorized Maruyama dealer.
TABLE OF CONTENTS
SPECIFICATIONS
Models
Length×Width×Height※1
Dry Weight※1
Engine Displacement
Fuel Tank Capacity
Carburetor
Ignition System
325 255× ×370mm
30.1cm3
0.5R
Walbro Diaphragm Type
Solid State
BL3200
4.4 kg
Reverse2 Start
Use only non-leaded regular gasoline.
2-Cycle oil mix 25:1 ratio must be approved for air-cooled engines.
13m/s2
NGK
BPMR6Y
0.6
∼
0.7mm
Fuel Mixture:
Starter
Vibration Level Handle
(Max. rpm)
Sound Pressure Level
(Max. rpm) 80dB(A)
Spark Plug:
Make
Type
Electrode Gap
13m3/minMaximum Air Volume
Foreword······················································ 1 Starting and stopping procedure ··············· 10
Specifications ·············································· 1 Carburetor adjustment······························· 12
Product description······································ 2 Operating the Hand-held Blower ··············· 13
Marking························································ 3 Regular maintenance ································ 13
Symbol Explanation····································· 3 Storage······················································ 18
Safety instructions ······································· 4 Troubleshooting ········································· 19
Assembly····················································· 7 Maintenance period··································· 19
Before operation·········································· 8
※1. Dry weight without Pipe A and B
