Matrox Millennium P690 PCIe x16 Manual

Matrox Videokort Millennium P690 PCIe x16

Læs gratis den danske manual til Matrox Millennium P690 PCIe x16 (69 sider) i kategorien Videokort. Denne vejledning er vurderet som hjælpsom af 25 personer og har en gennemsnitlig bedømmelse på 4.5 stjerner ud af 13 anmeldelser. Har du et spørgsmål om Matrox Millennium P690 PCIe x16, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/69

User Guide

10818-301-0322

2008.12.01

Matrox Parhelia

Matrox Millennium P750

Matrox Millennium P690

Matrox Millennium P650

ENGLISH

2 Matrox graphics card – User Guide

Hardware installation

This section describes how to install your Matrox card. If your Matrox graphics card is already

installed in your computer, skip to “Standard (ATX) connection setup”, page 6 or “Low-profile

connection setup”, page 10. For information specific to your computer, like how to remove its cover,

see your system manual.

WA R N I NG :

To avoid personal injury and to prevent damage to your computer or Matrox

hardware, turn off your computer, unplug it, and then wait for it to cool before you install

your Matrox product and touch any of the internal parts of your computer.

While your computer is turned off but still plugged in, some electrical current is supplied

to the motherboard. This current may prevent newly installed hardware from working

properly.

Also, static electricity can severely damage electronic parts. Before touching any electronic

parts, drain static electricity from your body (for example, by touching the metal frame of

your computer). When handling a card, carefully hold it by its edges and avoid touching

its circuitry.

Note:

If your Matrox product supports stereo output

and you want to use a stereo-output bracket (provided

with some Matrox products), you need to connect your

stereo-output bracket to your graphics card. For more

information, see “Stereo output”, page 20.

Note:

Matrox low-profile graphics cards ship with standard (ATX) brackets compatible

with most systems. If you have a low-profile system, you may need to change the standard

bracket on your graphics card to a low-profile bracket. For more information, see

“Replacing brackets on a low-profile graphics card”, page 5.

Stereo-output bracket

Produkt Specifikationer

Mærke:	Matrox
Kategori:	Videokort
Model:	Millennium P690 PCIe x16
Dybde:	168 mm
Højde:	111 mm
Formfaktor:	Full-Height/Half-Length (FH/HL)
Strømforbrug (typisk):	10 W
Maksimal opløsning:	2048 x 1536 pixel
HDMI:	Ingen
Mac kompabilitet:	Ingen
Grænsefladetype:	PCI Express x16
Antal VGA-porte (D-sub):	2
TV-tuner, integreret:	Ingen
Maksimal digital opløsning:	1920 x 1200 pixel
Antal DVI-I-porte:	2
Antal installerede processorer:	1
Kølingstype:	Passiv
Maksimal analog opløsning:	2048 x 1536 pixel
Grafisk adapter, RAMDAC:	400 MHz
Hukommelsestype for grafikadapter:	GDDR2
Hukommelsesbus:	128 Bit
Antal DVI-porte:	2
DirectX-version:	Ingen
DVI dobbelt link:	Ja
Video indgang:	Ingen
Minimum system strømføring:	- W
Tv-udgang:	Ingen
Tv-indgangsport:	Ingen
Maksimalt antal skærme pr. grafikkort:	2
Beslagshøjde:	Full-Height (FH)
Dobbelt VGA:	Ja
