Side 1/16
INSTALLATION INSTRUCTIONS
27" (68.6 CM) AND 30" (76.2 CM) ELECTRIC BUILT-IN
MICROWAVE/OVEN COMBINATION
INSTRUCTIONS D'INSTALLATION
FOUR CONVENTIONNEL ET FOUR À MICRO-ONDES
ÉLECTRIQUES, COMBINÉS ET ENCASTRÉS
DE 27" (68,6 CM) ET 30" (76,2 CM)
BUILT-IN MICROWAVE/OVEN COMBINATION SAFETY
W10351241A
Table of Contents/Table des matières
BUILT-IN MICROWAVE/OVEN
COMBINATION SAFETY................................................................1
INSTALLATION REQUIREMENTS ................................................2
Tools and Parts ............................................................................2
Built-In Microwave/Oven Combination
Location Requirements................................................................2
Electrical Requirements ...............................................................4
INSTALLATION INSTRUCTIONS ..................................................5
Prepare Built-In Microwave/Oven Combination..........................5
Remove Oven Door......................................................................5
Make Electrical Connection .........................................................5
Install Oven...................................................................................7
Complete Installation ...................................................................8
SÉCURITÉ DU FOUR À MICRO-ONDES ET DU FOUR
CONVENTIONNEL COMBINÉS ET ENCASTRÉS........................9
EXIGENCES D'INSTALLATION ...................................................10
Outils et pièces...........................................................................10
Exigences d'emplacement de l'ensemble four à
micro-ondes et four conventionnel encastrés...........................10
Spécifications électriques ..........................................................12
INSTRUCTIONS D'INSTALLATION.............................................13
Préparation de l'ensemble des fours encastrés
(micro-ondes/conventionnel) .....................................................13
Dépose de la porte du four ........................................................13
Raccordement électrique...........................................................13
Installation du four......................................................................15
Achever l'installation ..................................................................16
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT:
Save for local electrical inspector's use.
IMPORTANT :
À conserver pour consultation par l'inspecteur local des installations électriques.
2
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
■ Phillips screwdriver
■ Measuring tape
■ Drill (for wall cabinet installations)
■ 1" (25 mm) drill bit (for wall cabinet installations)
■ Level
■ Flat-blade screwdriver
Parts needed
■ UL listed or CSA approved conduit connector
■ UL listed wire connectors
Parts supplied
■ Four #8–14 x 1" screws
■ Bottom vent
■ Two #8–18 x ³⁄₈" screws - bottom vent
■ Four grommets*
Check local codes. Check existing electrical supply. See
“Electrical Requirements.”
It is recommended that all electrical connections be made by a
licensed, qualified electrical installer.
*Grommets are not included with models KEMS308S,
KEHU309S and KEMS378S.
Built-In Microwave/Oven Combination
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
■ Cabinet opening dimensions that are shown must be used.
Given dimensions provide minimum clearance with oven.
■ Recessed installation area must provide complete enclosure
around the recessed portion of the oven.
■ Grounded electrical supply is required. See “Electrical
Requirements” section.
■ Electrical supply junction box should be located 3" (7.6 cm)
maximum below the support surface when the oven is
installed in a wall cabinet. A 1" (2.5 cm) minimum diameter
hole should have been drilled in the left rear corner of the
support surface to pass the appliance cable through to the
junction box.
■ Oven support surface must be solid, level and flush with
bottom of cabinet cutout. Floor must be able to support a
total weight (microwave and built-in oven) of 208 lbs (95 kg)
for 27" (68.6 cm) models or 249 lbs (113 kg) for 30" (76.2 cm)
models.
IMPORTANT: To avoid damage to your cabinets, check with
your builder or cabinet supplier to make sure that the
materials used will not discolor, delaminate or sustain other
damage. This oven has been designed in accordance with
the requirements of UL and CSA International and complies
with the maximum allowable wood cabinet temperatures of
194°F (90°C).
