MED450X2

Description:

The MED450X2 is the very latest Multimedia Player developed by Mede8er for today’s demanding media enthusiast.

The X2 has been designed for good solid media playback from a Hard Drive, USB device, SD Card, Internet or Local

Network source. The MED45X2 is equipped with advanced features like Fast Gigabit Port and Super Fast USB 3.0

Slave port and is upgrade ready for the fast PCIe WiFi kit that will be available as an optional aftermarket upgrade

kit. The Mede8er fully supports the very latest video codec's such as MKV-H264, BDMV, BDISO, M2TS for seamless

playback of all supported media files. You can now pass full HD Audio streams via HDMI to your amplifier for a full

7.1 surround sound experience.

Main features:

• Fanless design

• 2.5” HDD space, support up to 1TB

• Hard Drive Spin Down Function

• External IR Jack

• Built In View Manager (5 Custom Views)

• Built In Favourites Manager

• Movie XML Med Data in Media Library

• Alpha Search in Media Library

• Internet Media Streams

• Social Media

• Built in Web Browser

• Mac HFS+ compatible

• Metal chassis - solid design

• Video Wall with full Metadata Search *

• Full Parental Control on Folders

• Watched Indicator

• Network - Ethernet 10/100/1000* Mbps port

• Optional Wi-Fi (802.11b/g/n up to 300Mbps)

• Optional PCIe Wi-Fi kit

• Samba server - NAS storage

• Internet Radio (SHOUTcast)

• Photo Grid Picture View

• SD Card slot / Sony Pro Duo Card Slot

• Photo slide show with background music

• Subtitle: SRT, SSA, SUB, SMI. PGS format

• Plasma Mode - Prevent screen burn in

• Security Lock Slot

Specifications:

Processor: Realtek RTD1185- 256MB SPI Flash - 256MB DDR2 SDRAM

Video Formats Supported: AVI / BDMV Light / BDISO Light / MKV / TS / TP / TRP / M2TS / MPG / MP4 / MOV / M4V /

VOB / ISO / IFO /

DAT / WMV / ASF / RM / RMVB / FLV resolution up to 720p / 1080i / 1080p

Video Codecs Supported: MPEG-1 / MPEG-2 / MPEG-4 SP /ASP /AVC (H.264) / XviD / DivX / WMV9 (VC-1) /

RealVideo 8/9/10 (up to 720P)

Audio Codec Supported: Mp3 / Mp2 / OGG Vorbis / APE - APE Cue /PCM / LPCM / AAC / RA / Dolby True HD - DTS

MA Passthrough on HDMI

Dolby AC3 Downmix & Passthrough / DTS Downmix & Passthrough / FLAC up to 24bit 192Khz (HDMI & Co-Ax Digital

only) Flac Cue / WAV, WMA Standard (DRM, & Advanced Profile not supported)

Photo format Supported: JPEG, BMP, PNG

File System Supported: FAT32 (up to 2TB), NTFS (up to 3TB), MAC HFS+ (USB Drives only)

Video output resolution: NTSC, PAL, 480p, 576p, 720p, 1080i, 1080p, 1080p. 24hz - (other TV sizes not supported)

Input / Output

• HDMI 1.3, Component Video, Composite Video

• Stereo RCA audio for analogue audio connection

• SD / Sony Pro Duo Card Slot

• SPDIF Optical

• USB - 2.0 HOST port x 2

• USB - 3.0 SLAVE port

• RJ45 - Network Connector

General

• 2.5" Internal Hard Drive Bay up to 1TB

• Security Lock Slot

• Media Library Video Wall with Metadata *

• Favourites Manager

• Alpha Jump in Media Library

• BD Menu - Non Java support

• 12 Bit Deep Video Colour support

• Internet Browser (Flash / Video playback not supported)

• Parental Control

• Playlist creation from remote

• Screensaver – Selectable in GUI setup - Default - Photo Album - Flickr Online

• In folder JPEG preview feature

• Easy navigation button use

• Resume playback feature

• Photo slide show with background music

• Network - Ethernet 10/100/1000* Mbps

• Optional Wi-Fi (802.11b/g/n up to 300Mbps) - MED10WFB - DHCP / WPS/ Peer To Peer setup only (No Manual IP)

• Samba server - NAS storage

• UPnP Device, DLNA (DMR) compliant

• Internet Radio (SHOUTcast) / .pls Playlist support

• File Copying - Card, USB, HDD and Network

• Subtitle: SRT, SSA, SUB, SMI, PGS format

• Size: 140 X 105 X 36 mm

* Subject to Firmware update -- In development

* 1) Typical wire network transfer speeds Samba NAS -- From PC to MED500X2 (up to 8.5MB/sec) -- From MED500X2 to PC up to

12MB/sec to MED500X2 internal HDD

* Tested with 500GB Internal SATA HDD

2) Typical Video Streaming on Gigabit Network -- Full BDMV / BDISO non 3D (up to max 8.5MB/sec)

Optional accessories: Please note that Mede8er can supply bundle packages based on client’s request, these

bundles applicable with this MED450X2 type are a player+accessories+build in HDD up to 1TB.

WiFi by PCIe + Antenna WiFi by USB dongle Wireless keyboard as remote and to browse

Item: MED20PCIE Item: MED10WFB Item: MEDX2KEY

Produkt Specifikationer

Mærke:	Mede8er
Kategori:	Medieafspiller
Model:	MED450X2
Type:	Desktop
Bredde:	140 mm
Dybde:	105 mm
Højde:	36 mm
Vægt:	- g
Brugervejledning:	Ja
Produktfarve:	Sort
Indbygget skærm:	Ingen
Wi-Fi:	Ingen
HD-type:	Fuld HD
Format til analogt signal:	NTSC, PAL
Lyddekodere:	Dolby TrueHD, DTS-HD Master Audio
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	1
Ethernet LAN:	Ja
Understøttede videoformater:	AVI, IFO, ISO, M4V, MKV, MOV, MP4, MPG, TP, TRP, TS, VOB
Forældrekontrol:	Ja
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Intern hukommelse:	256 MB
Kabler inkluderet:	AV
Understøttede filsystemer:	FAT32, HFS+, NTFS
Understøttede billedformater:	BMP, JPG, PNG
Fjernbetjening inkluderet:	Ja
Lyd-output kanaler:	7.1 kanaler
Universal Plug and Play (UPnP):	Ja
AC-adapter inkluderet:	Ja
Indbygget kortlæser:	Ja
Full HD:	Ja
Understøttede undertekstformater:	pgs, smi, srt, ssa, sub
Video komprimeringsformater:	DivX, H.264, MPEG1, MPEG2, MPEG4, Xvid
Mac kompabilitet:	Ja
Understøttede radiobånd:	Ikke understøttet
Intern hukommelsestype:	DDR2
Samlet lagringskapacitet:	0 GB
S/PDIF-udgang:	Ja
Processormodel:	RTD1185
Opbevaringsmedietype:	Ikke tilgængelig
HDMI-version:	1.3
Sammensat videoudgang:	1
Komponent video (YPbPr/YCbCr) udgang:	1
Flashhukommelse:	256 MB
Indbygget processer:	Ja
Grænseflade til lagerdisk:	SATA
Størrelse på lagerdisk:	2.5 "
HD-Ready:	Ja
Internetradio:	Ja
Maksimal lagerkapacitet:	1 TB
Indbygget lagringsmedie:	Ingen
