Side 1/5

Receiver Wiring Adaptor

120 70-8117

Revision 03/13/17

STEP 1 -- MATCH & CONNECT WIRES

*120708117*

IMPORTANT

Before starting, compare items on your invoice with items

received. Thoroughly check packing materials. If an item

is missing, please call Crutchfield at 1-888-955-6000.

Match wires below to the matching function of each wire on your receiver (refer to instructions supplied with receiver). The wire colors of your

new receiver may, or may not, match the wire colors of the adaptor. Match adaptor and receiver wires by function, disregarding color.

Some wire functions depend upon what vehicle the harness is being applied to. See the chart on the next page as a guide for your particular

vehicle.

Individually tape off any unused wires.

Make final wiring connections following instructions on page 3.

White/Black - Left Front Speaker Negative

Violet/Black - Right Rear Speaker Negative

Yellow - 12 Volts Constant Power

Red - 12 Volts Switched Power

White - Left Front Speaker Positive

Blue - Power Antenna

Violet - Right Rear Speaker Positive

Green - Left Rear Speaker Positive

Gray - Right Front Speaker Positive

Gray/Black - Right Front Speaker Negative

Black - Chassis Ground

Green/Red - (see next page)

Dark Blue/Pink - (see next page)

Green/Black - Left Rear Speaker Negative

Green/Orange - (see next page)

Brown/White - (see next page)

Green/White - (see next page)

- (see next page)

White/Red - (see next page)

Brown/Blue - (see next page

Receiver Wiring Adaptor

120 70-8117

Green/Red

Dark Blue/Pink

White/Red

Brown/Blue

Green/Orange

Brown/White

Green/White

Wire Color Vehicle/Function

4Runner, Sienna-

Rear Tweeters Negative

Matrix, Solara Convertible, Tacoma-

Sub Coil 2 Negative

Sequoia, Solara Coupe-

Left Front Tweeter Negative

Prius, Tundra-

Not Used (tape off)

4Runner, Prius, Sienna-

Center Speaker Negative

Matrix, Solara Convertible, Tacoma-

Sub Coil 1 Negative

Sequoia, Solara Coupe-

Right Front Tweeter Negative

Tundra-

Not Used (tape off)

4Runner-

Subwoofer Coil 1 Negative

Matrix, Prius, Tundra-

Left Front Door Woofer Negative

The White/Black wire is for the Left Front

Tweeter Negative

Sequoia, Solara, Tacoma-

Not Used (tape off)

Sienna-

Subwoofer Coil 2 Negative

4Runner- Matrix, Prius, Tundra-

Subwoofer Coil 2 Negative

The Gray/Black wire is for the Right

Front Tweeter Negative

Sienna-

Subwoofer Coil 1 Negative

4Runner, Sienna-

Rear Tweeters Positive

Matrix, Solara Convertible, Tacoma-

Sub Coil 2 Positive

Sequoia, Solara Coupe-

Left Front Tweeter Positive

Prius, Tundra-

Not Used (tape off)

4Runner, Prius, Sienna-

Center Speaker Positive

Matrix, Solara Convertible, Tacoma-

Sub Coil 1 Positive

Sequoia, Solara Coupe-

Right Front Tweeter Positive

Tundra-

Not Used (tape off)

4Runner-

Subwoofer Coil 1 Positive

Matrix, Prius, Tundra-

Left Front Door Woofer Positive

The White wire is for the Left Front

Tweeter Positive

Sienna-

Subwoofer Coil 2 Positive

Sequoia, Solara, Tacoma-

Not Used (tape off)

4Runner-

Subwoofer Coil 2 Positive

Matrix, Prius, Tundra-

Right Front Door Woofer Positive

The Gray wire is for the Right Front

Tweeter Positive

Sienna-

Subwoofer Coil 1 Positive

Sequoia, Solara, Tacoma-

Not Used (tape off)

Page 2

STEP 1 -- MATCH & CONNECT WIRES -- CONTINUED

Sequoia-

Not Used (tape off)
