Side 1/8

CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

AX-ADBOX2

INSTALLATION INSTRUCTIONS

INTERFACE FEATURES

AX-ADBOX Series - Main Interface Control Box

• Provides accessory power (12-volt 10-amp)

• Maintains the retained accessory power (R.A.P.) feature

• Can be used in non-ampliﬁed, or analog/digital ampliﬁed models

• Retains warning chimes (GM)

• Retains the turn signal click (GM)

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness (ASWC-1 sold separately)

• Retains OnStar/OE Bluetooth

• Adjustable gain control for overall volume digital ampliﬁed models

• Adjustable gain control for chimes and OnStar (GM)

• Retains SYNC in Ford vehicles

• Adjustable gain control for SYNC (Ford)

•

Retains Blind spot detection system in Chrysler/Dodge/Jeep (if equipped)

• Retains balance and fade†

• Micro “B” USB updatable

APPLICATIONS

See application list on page 2

Note:

This is a general list for the AX-ADBOX2 lineup. Please reference the individual harnesses for exact features available.

† If you have a digital amp and you prefer to retain fade control, use the AX-ADBOX1 (excluding Ford and VW vehicles).

INTERFACE COMPONENTS

• AX-ADBOX2 interface

• 16-pin harness with stripped leads

INTRODUCTION

The AX-ADBOX2 main interface control box is designed for, and must be

used along with, the appropriate vehicle wiring harness (sold separately).

APPLICATIONS

The AX-ADBOX2 must be used along with the wiring harness listed for the vehicle in the following table. Refer to the instruction manual provided with the wiring harness for connections

to the 16-pin harness which is included with the AX-ADBOX2.

(Continued on the next page)

BUICK

Century 2004-2005 AX-ADGM03

Enclave 2008-2017 AX-ADGM01

LaCrosse 2005-2009 AX-ADGM03

Lucerne 2006-2011 AX-ADGM01

Rainier 2004-2007 AX-ADGM03

Rendezvous 2002-2007 AX-ADGM03

Terraza 2005-2008 AX-ADGM03

CADILLAC

DTS 2006-2011 AX-ADGM01

Escalade 2003-2006 AX-ADGM03

Escalade 2007-2011 AX-ADGM01

Escalade 2012-2014 AX-ADGM04

Escalade ESV 2003-2006 AX-ADGM03

Escalade ESV 2007-2011 AX-ADGM01

Escalade ESV 2012-2014 AX-ADGM04

Escalade EXT 2003-2006 AX-ADGM03

Escalade EXT 2007-2011 AX-ADGM01

Escalade EXT 2012-2013 AX-ADGM04

SRX 2007-2009 AX-ADGM01

CHEVROLET

Avalanche 2003-2006 AX-ADGM03

Avalanche 2007-2011 AX-ADGM01

Avalanche (w/o NAV) 2012-2013 AX-ADGM01

Avalanche (with NAV) 2012-2013 AX-ADGM04

Captiva Sport 2012-2015 AX-ADGM01

Cavalier 2000-2005 AX-ADGM03

Cobalt 2007-2010 AX-ADGM02

Corvette 2005-2013 AX-ADGM03

Equinox 2007-2009 AX-ADGM01

Express 2003-2007 AX-ADGM03

Express 2008-2011 AX-ADGM01

Express (w/o NAV) 2012-2015 AX-ADGM01

Express (with NAV) 2012-2015 AX-ADGM04

Express 2016-up AX-ADGM01

HHR 2006-2011 AX-ADGM02

Impala 2000-2005 AX-ADGM03

Impala 2006-2013 AX-ADGM01

Kodiak 2003-2009 AX-ADGM03

Malibu 2001-2003 AX-ADGM03

Malibu Classic 2004-2005 AX-ADGM03

Malibu 2008-2012 AX-ADGM02

Malibu (with monochrome display) 2013-2015 AX-ADGM04

Malibu Limited

(with monochrome display) 2016 AX-ADGM04

CHEVROLET

(Cont)

Monte Carlo 2000-2005 AX-ADGM03

Monte Carlo 2006-2007 AX-ADGM01

Silverado 2003-2006 AX-ADGM03

Silverado 2007-2011 AX-ADGM01

Silverado (w/o NAV) 2012-2013 AX-ADGM01

Silverado (with NAV) 2012-2013 AX-ADGM04

Silverado 2500/3500 (w/o NAV) 2014 AX-ADGM01

Silverado 2500/3500 (with NAV) 2014 AX-ADGM04

Silverado Classic 2007 AX-ADGM03

SSR 2003-2006 AX-ADGM03

Suburban 2003-2006 AX-ADGM03

Suburban 2007-2011 AX-ADGM01

Suburban (w/o NAV) 2012-2013 AX-ADGM01

Suburban (with NAV) 2012-2013 AX-ADGM04

Tahoe 2003-2006 AX-ADGM03

Tahoe 2007-2011 AX-ADGM01

Tahoe (w/o NAV) 2012-2013 AX-ADGM01

Tahoe (with NAV) 2012-2013 AX-ADGM04

Trailblazer 2002-2006 AX-ADGM03

Trailblazer 2007-2009 AX-ADGM03

Traverse 2009-2017 AX-ADGM01

Trax 2015-2016 AX-ADGM04

Uplander 2005-2008 AX-ADGM03

Add:

Captiva Sport 2012-2015

AX-ADGM01
