Axxess Integrate
®
Axxess Integrate
®
Installation Instructions for AX-NIS24SWC-6VInstallation Instructions for AX-NIS24SWC-6V
INTERFACE FEATURES
• Pre-wired ASWC-1 harness (ASWC-1 sold separately)
• Retains the factory AUX-IN jack
• Retains the factory backup camera to an aftermarket radio*
• Includes the AX-CAM6V 12-volt to 6-volt converter
* Will not work with models equipped with an "All Around Camera" system
AX-NIS24SWC-6V
Nissan (with NAV) 2011-up
INTERFACE COMPONENTS
• AX-NIS24SWC-6V harness • AX-CAM6V 12-volt to 6-volt converter
• Wire cutter • Crimping tool • Solder gun • Tape
• Connectors (example: butt connectors, bell caps, etc.)
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
NISSAN
Altima 2013-up
Cube
2011-2014*
Frontier 2013-up*
Juke 2011-2014*
NV 2012-up*
NV200 2012-up*
Rogue (w/ Bose)
2012-2013*
Rogue 2011*
Sentra 2011-up*
Titan 2013-2015*
Versa 2013-up*
Xterra
2013-2015*
APPLICATIONS
* For use when retaining the OE backup camera only
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Connections to be made
• Connect the Black wire with a ring terminal to chassis ground.
• Connect the Black wire of the AX-CAM6V wire to chassis ground.
• Connect the Red wire labeled "Camera Power 6V" to the Blue/Red wire
of the AX-CAM6V.
• Connect the Green/Purple wire to the reverse wire of the aftermarket radio,
and also to the Blue/White wire of the AX-CAM6V.
• For all models except the Cube / Rogue, if retaining the factory AUX-IN jack,
connect the Red & White RCA jacks to the AUX input.
• Connect the Yellow RCA jack to the rear camera input of the aftermarket radio
.
12-pin pre-wired ASWC-1 harness:
This harness is to be used along with the optional ASWC-1 (not included) to
retain steering wheel audio controls. Please refer to the ASWC-1 instructions
for radio connections and programming.
Note: Disregard the harness that comes with the ASWC-1.
• Connect the unlabeled Red wire to the accessory wire.
