Side 1/4

CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

AX-LR90092

INSTALLATION INSTRUCTIONS

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell

caps, etc.)

TABLE OF CONTENTS

Connections to be made .......................................2

Installing the AX-LR90092 interface ....................3

Programming the ASWC-1 interface .....................3

Land Rover Range Rover Sport* (with M.O.S.T. 25 ampliﬁer) Data Interface with SWC 2005-2009 †

Land Rover Discovery** (with M.O.S.T. 25 ampliﬁer) Data Interface with SWC 2004-2009

†

• Provides accessory power

• Retains R.A.P. (retained accessory power)

• Designed for ampliﬁed models

• Provides NAV outputs (parking brake, reverse, speed sense)

• Retains audio controls on the steering wheel

• Micro “B” USB updatable

• AX-LR90092 interface

• AX-LR90092 ampliﬁer interface

• ASWC-1 interface

• AX-LR90092 harness

• ASWC-1 harness

• Female 3.5mm connector with stripped leads

* 1st gen no time retention

** No time retention

† NAV screen will only show LR logo

CONNECTIONS TO BE MADE

From the aftermarket radio to the AX-LR90092 harness:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the battery wire.

• Connect the Red wire to the accessory wire.

• If the aftermarket radio has an illumination wire, connect the Orange wire to it.

• Connect the Blue wire to the power antenna turn-on wire.

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the Blue/Pink wire to the VSS/speed sense wire.

• Connect the Green/Purple wire to the reverse wire.

• Connect the Light Green wire to the parking brake wire.

•

Connect the Red and White RCA jacks to the front ampliﬁer output jacks of the aftermarket radio

From the aftermarket radio to the ASWC-1 harness:

This harness is only to be used if the vehicle is equipped with steering wheel controls.

• Connect the Red wire to the accessory wire.

• The 3.5mm jack is to be used to retain audio controls on the steering wheel control.

• For

the radios listed below, connect the

female 3.5mm connector with stripped leads

to the male

3.5mm SWC jack from the ASWC-1 harness. Any remaining wires tape off and disregard

• Eclipse: Connect the steering wheel control wire, normally Brown, to the Brown/White

wire of the connector. Then connect the remaining steering wheel control wire, normally

Brown/White, to the Brown wire of the connector.

• Metra OE: Connect the steering wheel control Key 1 wire (Gray) to the Brown wire.

• Kenwood or select JVC with a steering wheel control wire: Connect the Blue/Yellow

wire to the Brown wire.

• XITE: Connect the steering wheel control SWC-2 wire from the radio to the Brown wire.

• Parrot Asteroid Smart or Tablet: Connect the 3.5mm jack into the AX-SWC-PARROT (sold

separately), and then connect the 4-pin connector from the AX-SWC-PARROT into the radio

Note:

The radio must be updated to rev. 2.1.4 or higher software.

• Universal “2 or 3 wire” radio: Connect the steering wheel control wire, referred to

as Key-A or SWC-1, to the Brown wire of the connector. Then connect the remaining

steering wheel control wire, referred to as Key-B or SWC-2, to the Brown/White wire of

the connector. If the radio comes with a third wire for ground, disregard this wire.

Note:

After the interface has been programmed to the vehicle, refer to the manual provided

with the radio for assigning the SWC buttons. Contact the radio manufacturer for more

information

• For all other radios: Connect the 3.5mm jack from the ASWC-1 harness, into the jack on the

aftermarket radio designated for an external steering wheel control interface. Please refer to

the aftermarket radios manual if in doubt as to where the 3.5mm jack goes to.
