Installation instructions for part LC-GMRC-044

REV. 12/2/2016 INSTLC-GMRC-044

axxessinterfaces.com

•

metraonline.com

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-

volt 10-amp)

• Retains R.A.P. (retained

accessory power)

•

Provides NAV outputs (parking

brake, reverse, and speed sense)

• Used in non-amplified

models, or when bypassing a

factory amplifier

•

Used in models without OnStar

• Retains all warning chimes

• High level speaker input

• Retains balance and fade

• Micro “B” USB updatable

INTERFACE FEATURES

• Wire cutter • Crimping tool • Tape • Solder gun

• Connectors (butt-connectors, bell caps, etc.)

TOOLS REQUIRED

LC-GMRC-044

GM Data Interface

2012-2016

APPLICATIONS

• LC-GMRC-044 interface

• LC-GMRC-044 harness

INTERFACE COMPONENTS

*Only for models with factory navigation.

Note: This interface will not retain OnStar.

CADILLAC

Escalade, Escalade ESV & EXT*

2012-2014

CHEVROLET

Avalanche* 2012-2013

Express* 2013-2015

Malibu (with single color,

monochrome screen)

2013-2015

CHEVROLET (CONT)

Malibu Limited (with single

color, monochrome screen)

2016

Silverado* 2012-2013

Silverado 2500/3500* 2014

Suburban* 2012-2014

Tahoe* 2012-2014

Trax 2015-2016

GMC

Savana* 2013-2015

Sierra * 2012-2013

Sierra 2500/3500* 2014

Yukon / Yukon XL* 2012-2014

Connections to be made ........................................ 2

Installing the LC-GMRC-044 .................................. 3

Initializing the LC-GMRC-044 ................................ 3

Vehicle customization with the optional AX-LCD

... 3

Table of Contents

LC-GMRC-044

From the LC-GMRC-044 harness to the aftermarket radio:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the battery wire.

• Connect the Red wire to the accessory wire.

• Tape off and disregard the Pink wire, it will not be used in this application.

• Connect the Blue/White wire to the power antenna wire.

• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the Green wire to the left rear positive speaker output.

• Connect the Green/Black wire to the left rear negative speaker output.

• Connect the Purple wire to the right rear positive speaker output.

• Connect the Purple/Black wire to the right rear negative speaker output.

The following (3) wires are only for multimedia/navigation radios that require these

wires.

• Connect the Blue/Pink wire to the VSS/speed sense wire.

• Connect the Green/Purple wire to the reverse wire.

• Connect the Light Green wire to the parking brake wire.

Connections to be made
