In the Dodge and Jeep vehicles listed below there are
no 12 volt accessory wires currently in the factory har-
ness making the installer run an accessory wire to the
fuse box or underneath the steering column when
installing an aftermarket radio. The XSVI-6522 is
designed to provide a 12 volt 10 amp switched acces-
sory output along with the rest of the wires needed to
install an aftermarket radio. The R.A.P. (Retained
Accessory Power) function, where power is supplied to
the radio after the ignition is shut off until one of the
front doors are opened, is retained by the XSVI-6522.
NO
TE: The XSVI-6522 does not retain use of the fac-
tory amplifier if so equipped. INITIALIZE THE XSVI
INTERFACE BEFORE TURNING ON RADIO: With all
connections made and harnesses connected to the
vehicle, turn ignition key to the ON position for thir-
ty seconds, then turn key off.
Wiring the XSVI-6522:
Wiring up the XSVI-6522 is like
wiring up any other wire harness that would attach to
the aftermarket radios harness.The Metra/EIA wire
code can be found on the back of this package that will
aid you in the wiring of your aftermarket radio.
(See Applications on back of page)
INSTXSVI-6522 Rev. 03/12/10
1-800-221-0932 www.metraonline.com
METRA ELECTRONICS CORPORA
TION
© COPYRIGHT 2010
XSVI-6522
INSTALLATION INSTRUCTIONS
