Side 1/3

RouterBOARD 900 series

Quick Setup Guide and Warranty Information

RB900 is a RouterBOARD device family with a built-in 802.11 wireless device and one Ethernet port. Several mod-

els are available with 5GHz or 2GHz 802.11n or 5GHz 802.11ac wireless, with SFP slot, and miniPCIe slot.

First use

• Connect antenna cables to the built in Wi-Fi connectors

• Device accepts 8-30V with a passive PoE powered Ethernet cable or with a power connector to the Power

Jack

Powering

The board accepts power with the following modes:

•Passive 8-30V PoE to ethernet port. Higher voltage needed to compensate for power loss on long cables;

at least 18V suggested.

•Direct input to the power jack 8-30V (select models only)

Booting process

RouterOS is the operating system of all RouterBOARD routers. Please see documentation here: http://mt.lv/help

This device doesn't come fitted with a Serial Port connector, so initial connection has to be done via the Ethernet

cable, using the MikroTik Winbox utility. Winbox should be used to connect to the default IP address of

192.168.88.1 adminwith the username and . no password

In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of

the device when starting it until the LED light turns off, and Groove will start to look for Netinstall servers.

In case IP connection is not available, the Winbox utility can also be used to connect to the MAC address of the

device. More information in the documentation.

Extension Slots and Ports

•One Ethernet port (With Auto MDI/X so you can use either straight or cross-over cables for connecting to

other network devices). The Ethernet port accepts 8-30V DC powering from a passive PoE injector.

•Built-in 802.11b/g/n WiFi card (AR9342) with one or two MMCX connectors

•Only RB912UAG-2HPnD/RB912-5HPnD/RB922UAGS-5HPacD/RB922UAGS-5HPacT: !

miniPCI-e slot for either a 802.11 Wireless card, or a 3G modem (when a 3G modem is used in miniPCIe

slot, USB port will become inactive. In RouterOS you can select which of the 3G modems you want to use,

USB or miniPCIe). SIM slot is available for miniPCIe 3G cards.

•Only RB922UAGS-5HPacD/ RB922UAGS-5HPacT: !

One SFP port for 1.25GBit modules, DDMI support

Buttons and Jumpers

•RouterOS reset jumper hole – resets RouterOS software to defaults. Must short circuit the metallic sides of

the hole (with a screwdriver, for example) and boot the device. Hold screwdriver in place until RouterOS

configuration is cleared.

•Reset button – Holding this button during boot time will make the RouterBOARD look for Netinstall servers.

Release the button after the LED light goes out.

Operating System Support

Currently tested operating system is MikroTik RouterOS (starting from version v6.30).

See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 26 Oct 2016

Federal Communication Commission Interference Statement

List of FCC IDs: RB921UAGS-5SHPacD-OUT (NetMetal), RB921UAGS-5SHPacT-OUT (NetMetal),

- FCCID: TV7RB921-5SHPACT; RB922UAGS-5HPacD-OUT (NetMetal), RB922UAGS-5HPacT-OUT

(NetMetal), RB922UAGS-5HPacD, RB911G-5HPacD, RB911G-5HPacD-OUT (NetBox) - FCCID: TV7RB922-5H-

PACT!

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a res-

idential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instructions, may cause harmful interference to radio communications. However, there is no guaran-

tee that interference will not occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could

void the user’s authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. This device and its antenna must not be co-located or operation

in conjunction with any other antenna or transmitter.

IMPORTANT: Exposure to Radio Frequency Radiation.

63 cm minimum distance has to be maintained between the antenna and the occupational user and 140 cm to

general public. Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled

environment can be satisfied.

List of additional approved antennas

• Omni Directional (fiberglass pole) WLO-2450-15 15 dBi

• Omni Directional (hor. polarization) HP, ODH 24-13 13 dBi

• Sector SA 24-90-17-WB 17 dBi

• Panel WLP-2450-20 20 dBi

• Dish DC 24-HD-PFIP 24 dBi

Antenna Installation. WARNING: It is installer's responsibility to ensure that when using the authorized antennas in

the United States (or where FCC rules apply); only those antennas certified with the product are used. The use of

any antenna other than those certified with the product is expressly forbidden in accordance to FCC rules CFR47

part 15.204. The installer should configure the output power level of antennas, according to country regulations and

per antenna type. Professional installation is required of equipment with connectors to ensure compliance with

health and safety issues.

See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 26 Oct 2016
