Side 1/5

RB5009UPr+S+OUT

RB5009UPr+S+OUTRB5009UPr+S+OUT

RB5009UPr+S+OUT

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

The Installation of the equipment must comply with local and national electrical codes.

This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.

Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed.

Setup

Make sure your ISP is allowing hardware change and will automatically issue an IP address.

Connect your ISP cable to the first Ethernet port.

Connect your PC to any of the Ethernet ports.

Connect the device to the power source.

Use a Web browser or WinBox to connect to the default IP address of 192.168.88.1 from any port, with the username and no password

admin

(or,

for some models, check user and wireless passwords on the sticker).

If IP is not available, download WinBox from our webpage and use it to connect through MAC address.

Update RouterOS software to the latest version, and make sure that the device has an internet connection.

If the device does not have an internet connection update software by downloading the latest version from our webpagehttps://mikrotik.com

/download

Find the latest software and choose your packages.

To get the architecture type of your device model, open WinBox, WebFig go to (System/Resources).

Download packages to the PC and upload them to the WinBox, WebFig, (Files) menu, and reboot the device.

Set up your password to secure the device.

Powering

PoE-in 802.3af/at

PoE-Out 802.3af/at the Same voltage as supplied via 2-pin terminal - Passive PoE or

802.3af/at Compatible (if 44–57V PSU used)

PoE-Out ports Ether1 - Ether8, max out per port output (input < 30 V): 620 mA, max out per port output (input > 30 V): 420 mA

Smart PoE Controller

Max total out 2.59 A

Total output power 130 W

Total output current 2.28 A

Number of DC inputs 2

Supported input voltage 24-57 V (PoE in) 24-57 (2-pin terminal)

Max power consumption (without attachments) 15 W

Max power consumption 150 W

Configuration

Once logged in, we recommend clicking the "Check for updates" button in the QuickSet menu, as updating your RouterOS software to the latest version

ensures the best performance and stability. For wireless models, please make sure you have selected the country where the device will be used, to

conform to local regulations.

RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself accustomed to

the possibilities: . In case an IP connection is not available, the Winbox tool ( ) can be used to connect to the MAC

https://mt.lv/help https://mt.lv/winbox

address of the device from the LAN side (all access is blocked from the Internet port by default).

For recovery purposes, it is possible to boot the device for reinstallation, see section .

Buttons and jumpers

Mounting

We recommend Cat6 cables for our devices.

The mounting and configuration of this device should be done by a qualified person, to comply class please observe the strict procedures for

IP66

IP66IP66

mounting instructions.

Extension slots and ports

4RB5009UPr+S+OUT

Product code RB5009UPr+S+OUT

CPU Quad-Core 88F7040 1.4 GHz

CPU architecture ARM 64bit

Size of RAM 1 GB

RAM type DDR4

Storage 1 GB, NAND

Number of 1G Ethernet ports 7

Number of 2.5G Ethernet ports 1

Number of 10G SFP+ ports 1

USB 1 USB 3 type A

Operating system RouterOS v7, License level 5

Switch chip model 88E6393

Produkt Specifikationer

Mærke:	Mikrotik
Kategori:	Router
Model:	RB5009UPr+S+OUT
Bredde:	222 mm
Dybde:	239 mm
Højde:	57 mm
Brugervejledning:	Ja
Produktfarve:	Hvid
Ethernet LAN-porte (RJ-45):	8
Strømforbrug (typisk):	150 W
Driftstemperatur (T-T):	-40 - 70 °C
Intern hukommelse:	1024 MB
Operativsystem installeret:	RouterOS
Certificering:	CE, EAC, ROHS
Ethernet WAN:	Ingen
DSL WAN:	Ingen
SIM-kort slot:	Ingen
3G/4G kompatibilitet USB-modem:	Ingen
Netværksstandarder:	IEEE 802.3af, IEEE 802.3at
DC-in-stik:	Ja
Strømkilde type:	PoE
USB version:	3.2 Gen 1 (3.1 Gen 1)
Antal USB-porte:	1
Processorfrekvens:	1400 MHz
Processorproducent:	Marvell
Processormodel:	88F7040
Intern lagerkapacitet:	1 GB
Strøm over Ethernet (PoE):	Ja
Ethernet-grænsefladetype:	2.5 Gigabit Ethernet, Gigabit Ethernet
Gennemsnitstid mellem fejl (MTBF):	200000 t
Indbygget processer:	Ja
Power over Ethernet (PoE) porte, antal:	8
Antal SFP + modulslots:	1
Spændingsovervågning:	Ja
Temperaturovervågning:	Ja
SFP WAN:	Ingen
