PARTS DIAGRAM
30
32
33
34
35
38
39
40
41
42
43
44
46
47
48
49
50
51
52
53
31
37
45
1
2
3
4
5
6
7
8 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
36
54
55
56
58
57
This page provides Minn Kota® WEEE compliance disassembly
instructions. For more information about where you should
dispose of your waste equipment for recycling and recovery and/
or your European Union member state requirements, please
contact your dealer or distributor from which your product was
purchased.
Tools required, but not limited to: fl at head screw driver, Phillips
screw driver, socket set, pliers, wire cutters.
ENDURA C2 50
50 LBS THRU - 12 VOLT - 36”/ 42” SHA
2064973 rev K ECN 35938 7 /14
minnkotamotors.com | 15
©2014 Johnson Outdoors Marine Electronics, Inc.
PARTS LIST
ITEM QTY PART
NUMBER DESCRIPTION
1 1 2-100-117 ARMATURE  SEMBLY 12V 3.62
2 1 140-010 RADIAL BEARING
3 1 788-015 R AINING RING
4 1 2-200-101 CENTER HOUSING SEMBLY
5 1 2-300-196 BRUSH END HOUSING  SEMBLY 3.62 SPCO 36”
1 2-300-195 BRUSH END HOUSING  SEMBLY 3.62 SPCO 42”
6 1 2-400-101 P IN END HOUSING SEMBLY
7 1 144-049 F NGE BEARING (SERVICE ONLY)
8 1 880-003 SEAL
9 1 880-006 SEAL W/SHIELD
10 188-0362 BRUSH  SEMBLY
11 725-0501 BRUSH R ENTION — PAPER TUBE
12 738-0361 BRUSH P TE WITH HOLDER
13 975-0402 TORSION SPRING
14 1 337-036 G K
15 701-008 O-RING2
16 1 701-081 O-RING
17 2 830-007 SCREW — #8-32
18 830-0422 THRU BOLT #10-32X8.83
19 1 990-067 W HER —  EEL THRU
20 990-0702 W HER — NY TRON
21 20970451 MOTOR SEMBLY 12V 3.62 5SPC FW 36”
1 2097036 MOTOR SEMBLY 12V 3.62 5SPC FW 42”
22 20320461 36” COMPOSITE TUBE
1 2032047 42” COMPOSITE TUBE
n1 1378170 PROPELLER KIT (INCLUD 23-26)
23 20911701 POWER PROPELLER 3-5/8”
24 21517261 W HER — 5/16  D SS
25 20531011 NUT — NYLOC 5/16
26 20926001 DRIVE PIN
n1 2771818 BRACK & HINGE  SEMBLY (INCLUD 30-41)
n1 2771910 BRACK SEMBLY (INCLUD 30, 32, 33)
ITEM QTY PART
NUMBER DESCRIPTION
*30 2061910 BRACK 1
31 20605101 HINGE PIN
n2 2881300 SCREW — C MP, W HER, R AINER KIT
*32 20613002 SCREW — C MP
*33 2 2011710 W HER — C MP
34 20636051 P TIC T-BAR
35 20627061 T-BAR SPRING
36 20672011 B CK TILT LEVER
37 1 2061810 P TIC HINGE
38 20373012 HINGE BUSHING
39 20628001 SNAP-IN TENSION BLOCK
40 20113851 SCREW — TENSION/KNOB
41 20605151 TILT LEVER PIN
42 20615201 DEPTH COL R
43 1 2011365 SCREW — COL R/NEW KNOB
44 20506101 LEADWIRE 10 GA SPADE TERM
45 20207022 SPADE TERMINAL 10GA.
46 22563002 TIE WRAP
47 1 2062515 CONTROL BOX
48 20602151 CONTROL BOX COVER
49 1 2065703 DE L COVER ENDURA C2 50
50 20640281 SWITCH — FWD/REV 5 SP
51 20334011 SCREW — #10-24 X 1-3/4
52 20131101 NUT — 10-24 HEX
53 20121006 SCREW — #8-18 X 5/8
54 29909191 INNER HANDLE SEMBLY
55 20604051 HANDLE PIVOT
56 20121041 SCREW — #6 X 1/2” SS
57 29909281 OUTER HANDLE SEMBLY
58 20600091 FRONT BEARING
n1 2888460 SEAL AND O-RING KIT
ENDURA C2 50
50 LBS THRU - 12 VOLT - 36”/42” SHA
n THIS ITEM IS PART OF AN  SEMBLY.
*THIS ITEM IS PART OF A KIT AND ONLY LI ED FOR VIEWING PURPOS .
