User’s Guide
For L512CBT/L513CBT/L514CBT/L515CBT
DECT 6.0 Cordless / Corded Phones
with Bluetooth® and
Answering System
Warning
Use only the power adapters and telephone line
cords provided in the box.


• 30 name and number phonebook for the cordless handset and corded base respectively.
• Answering machine with 15 minutes digital recording time.*
• Caller ID shows you who is calling and includes details of the last 30 callers in a calls list.**
Call log Capacity is 30, the same for the cordless handset and corded base.
• Register up to 5 cordless handsets to the corded base.
• Make internal calls, transfer external calls, hold 3-way conversation between two internal callers and an
external caller.
*The recording time includes the pre-recorded voice menu and outgoing announcements.
**You must subscribe to your network provider's Caller ID or Call Waiting service for these features to work.
Please note that only the Corded phone operates during power outage (with limited functions).
Welcome...
to your new Motorola Phone!
Please retain your original dated sales receipt for your records. For warranty service of your Motorola product,
you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required
for warranty coverage.
For product-related questions, please call:
US and Canada: 1-888-331-3383
On the Web: www.motorola.com
This ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of
products that save energy and help protect our environment. We are proud to mark this product
with the ENERGY STAR ® label indicating it meets the latest energy efficiency guidelines.


IMPORTANT
Only use the telephone line cords supplied.
Got everything?
• Cordless handset
• Cordless charger
• NiMH rechargeable battery pack
• Power adapter for the cordless charger
• Corded base
• Corded handset
• Telephone line cords (one for connecting the corded base and handset)
• Power adapter for the corded base
• Quick Start Guide
• User’s Guide
In multihandset packs, you will find one or more additional cordless handsets, cordless chargers with
power adapter units, additional rechargeable battery packs, and battery doors.
This User’s Guide provides you with all the information you need to
get the most from your phone.
Before you make your first call you will need to set up your phone.
Follow the simple instructions in 'Getting Started' on the next few
pages.


4
1. Getting started ......................................... 7
1.1 Installing and charging the cordless
handset battery pack ................................... 8
1.2 Installing the cordless charger..................... 8
1.3 Connecting the corded base........................ 9
1.4 Wall mounting on corded base .................... 9
1.5 Setting the display language ..................... 10
1.6 Setting date and time................................. 10
2. Getting to know your phone ................. 11
Enjoy your corded base phone .............. 19
3. Using the phone..................................... 19
3.1 Introducing Bluetooth................................. 19
3.2 Bluetooth Setup ......................................... 20
3.2.1 Setting up Cellular ......................... 20
3.2.2 Replacing a paired device ............. 20
3.2.3 Paired Devices .............................. 21
3.3 Making a home call using your landline...... 21
3.4 Making a cellular call using your
corded base phone.................................... 21
3.5 Speed dial calling ...................................... 22
3.6 Answering a home call .............................. 22
3.7 Answering a cellular call ............................ 22
3.8 Receiving a cellular call while on a
home call ................................................... 22
3.9 Receiving a home call while on a
cellular call ................................................. 23
3.10 Ending a call .............................................. 23
3.11 Adjusting volume ....................................... 23
3.12 Dialing from the redial list .......................... 24
3.13 Dialing from the calls list ............................ 24
3.14 Muting a call...............................................24
3.15 Adding an entry to the phonebook.............24
3.16 Storing a phonebook entry as a
one touch number...................................... 24
3.17 Dialing from the phonebook.......................25
3.18 Caller ID..................................................... 25
3.18.1 Calls List ........................................ 25
3.18.2 Viewing the calls list ...................... 26
3.18.3 Saving a number from the
calls list to the phonebook ............. 26
3.18.4 Deleting a calls list entry ............... 26
3.18.5 Deleting the entire calls list ........... 26
3.19 Personal Settings.......................................27
3.20 Intercom..................................................... 28
3.20.1 Calling another cordless handset ... 28
3.20.2 Transferring an external home call
to another cordless handset .......... 28
3.20.3 Three-party conference call .......... 28
3.21 Setting the dial mode ................................. 29
3.22 Setting the Flash Time............................... 29


5
3.23 Setting the Area Code ............................... 29
3.24 Resetting all settings ................................. 30
3.25 Using your answering machine ................. 30
3.25.1 Playing messages .........................30
3.25.2 Turning on or off the answering
machine .........................................30
3.25.3 Setting the announcement mode ....31
3.25.4 Setting the number of rings ...........31
3.25.5 Announcement ..............................31
3.25.6 Recording a memo ........................32
3.25.7 Call screening on/off ......................33
3.25.8 Deleting all old messages ..............33
3.25.9 Remote access ..............................33
3.25.10 Setting the security code ...............34
Enjoy your cordless handset ................. 35
4. Using the phone .....................................35
4.1 Bluetooth Setup......................................... 35
4.1.1 Setting up Cellular .........................35
4.1.2 Replacing a paired device .............35
4.1.3 Paired Devices ..............................36
4.2 Making a home call using your landline...... 36
4.3 Making a cellular call using your
cordless DECT handset ............................ 36
4.4 Speed dial calling ...................................... 37
4.5 Answering a home call .............................. 37
4.6 Answering a cellular call ............................ 37
4.7 Receiving a cellular call while on a
home call ................................................... 37
4.8 Receiving a home call while on a
cellular call................................................. 37
4.9 Ending a call .............................................. 38
4.10 Adjusting volume ....................................... 38
4.11 Muting a call .............................................. 38
4.12 Dialing from the redial list .......................... 38
4.13 Dialing from the calls list............................ 38
4.14 Adding an entry to the phonebook ............ 39
4.15 Storing a phonebook entry as a
one touch number ..................................... 39
4.16 Dialing from the phonebook ...................... 39
4.17 Caller ID .................................................... 39
4.17.1 Calls List ....................................... 40
4.17.2 Viewing the calls list ...................... 40
4.17.3 Saving a number from the
calls list to the phonebook ............ 40
4.17.4 Deleting a calls list entry ............... 41
4.17.5 Deleting the entire calls list ........... 41
4.18 Personal Settings ...................................... 42
4.19 Intercom .................................................... 43
4.19.1 Calling another cordless handset
or corded base .............................. 43


6
4.19.2 Transferring an external home call
to another cordless handset or
corded base .................................. 43
4.19.3 Three-party conference call .......... 44
4.20 Setting the dial mode................................. 44
4.21 Setting the Flash Time............................... 44
4.22 Setting the Area Code ............................... 44
4.23 Registration ............................................... 45
4.24 Resetting all settings ................................. 45
4.25 Paging/Finding cordless handset .............. 45
4.26 Using your answering machine ................. 46
4.26.1 Playing messages ......................... 46
4.26.2 Turning on or off the answering
machine ........................................ 46
4.26.3 Setting the announcement mode .... 47
4.26.4 Setting the number of rings ........... 47
4.26.5 Announcement .............................. 47
4.26.6 Recording a memo ........................ 48
4.26.7 Call screening on/off ..................... 48
4.26.8 Deleting all old messages ............. 49
4.26.9 Remote access ............................. 49
4.26.10 Setting the security code .............. 50
5. Help ......................................................... 50
6. General information............................... 52


Getting started 7
1. Getting started
WARNING
• Do not place your phone in the bathroom or other
humid areas.
Location
When choosing a location for your new phone, here are
some important guidelines you should consider:
• Avoid sources of noise and heat, such as motors,
fluorescent lighting, microwave ovens, heating
appliances and direct sunlight.
• Avoid areas of excessive dust, moisture, and low
temperature.
• Avoid other cordless telephones or personal
computers.
• Never install the telephone wiring during a lightning
storm.
• Never install telephone jacks in wet locations unless
the jack is specifically designed for wet locations.
• Never touch non-insulated telephone wires or
terminals unless the telephone line has been
disconnected at the network interface.
• Use caution when installing or modifying telephone
lines.
HANDSET RANGE
Optimal range is reached when there are no other
electrical appliances working within the range area. Any
obstruction between the corded base and cordless
handset will also reduce the range significantly.
SIGNAL STRENGTH
When out of range of the corded base, the screen shows
SEARCHING...
. If you are on a call, the line will hang up. Move
back within in range. The cordless handset will
automatically re-connect to the corded base.
Setting up
IMPORTANT
The corded base must be plugged into the electrical
outlet at all times. Do not connect the telephone line
cord into the wall jack until the cordless handset is fully
charged. Only use the power adapter and telephone
line cord supplied with the product.
WHICH POWER ADAPTER
The power adapter with the smaller pin plug is for the
corded base unit and the power adapter with the bigger
pin plug is for the cordless charger unit.


8 Getting started
1.1 Installing and charging the
cordless handset battery pack
1.
Slide off the battery compartment cover to remove it.
2.
Place the supplied rechargeable battery pack in the
battery compartment, with the battery connector
plugged in, as shown.
3.
Slide the battery compartment cover back on.
4.
Put the cordless handset on the cordless charger to
charge for at least 24 hours. Once charged, the
will indicate that the handset is fully charged.
5.
Use only the rechargeable battery pack provided.
1.2 Installing the cordless charger
1.
Plug the power adapter with the bigger pin plug into
the cordless charger.
2.
Plug the other end of the power adapter into the
wall jack.
3.
Use only the provided power adapter.


Getting started 9
1.3 Connecting the corded base
1.
Connect the corded handset to the corded base
with the provided coiled line cord.
2.
Plug the power adapter with the smaller pin plug &
telephone line cord into the corded base.
3.
Plug the other end of the power adapter &
telephone line cord into the wall jack.
4.
Always use the telephone line cord provided in the
box.
5.
Use only the provided adapter.
1.4 Wall mounting on corded base
This phone can be mounted on any standard wall plate.
1.
Plug the power adapter with the smaller pin plug &
telephone line cord into the corded base.
2.
Snap the wall mount adapter into the notches on
the corded base’s back.
3.
Plug the other end of the power adapter &
telephone line cord into the wall jack.
4.
Align the mounting slots on the corded base with
the mounting posts on the wall. Then push in and
down until the phone is firmly seated.
For wall mounting For desktop


10 Getting started
1.5 Setting the display language
On the corded base:
1.
Press P and then /VOL+ or /REDIAL/
VOL- to select
Settings
.
2.
Repeat to select
Language
.
3.
Repeat to select the desired language.
4.
Press P to save.
On the cordless handset:
1.
Press MENU and then VOL+ or REDIAL/VOL- to
select
SETUP HS
.
2.
Repeat to select
LANGUAGE
.
3.
Repeat to select the desired language.
4.
Press MENU to save.
1.6 Setting date and time
On the corded base:
1.
Press P to select
Date & Time
.
2.
Press P and then edit the time in 12 hour
format.
3.
Press /VOL+ or /REDIAL/VOL- to toggle
AM/
PM
settings.
4.
Press P to continue entering the date.
5.
Press P to save the settings.
On the cordless handset:
1.
Press MENU to select
DATE & TIME
.
2.
Repeat to edit the year and date.
3.
Press VOL+ or REDIAL/VOL- to move between the
input fields
YEAR
and
DATE
.
4.
Press MENU and then edit the time in 12 hour
format. Press VOL+ or REDIAL/VOL- to toggle
AM/
PM
settings.
5.
Press MENU to save the settings.
NOTE
If you have subscribed to your network's Caller ID
service, the date and time is set automatically when a
call is received.
Your phone is now ready for use.


Getting to know your phone 11
2. Getting to know your phone
Overview of the corded base
1 SCROLL UP/ VOLUME UP
a) In menu mode: Press to scroll up.
b) During a call: Press to increase volume.
c) Calls list/phonebook/redial list entry: Press to
scroll up the list.
d) In answering machine mode: Press to increase
message playback volume.
2 RIGHT SOFT KEY
a) In idle mode: Press to access menu list.
b) In menu/editing mode: Press to confirm and save
the settings.
c) During a call: Press to mute/unmute the call.
d) In calls list entry: Press to save the entry to the
phonebook.
e) In phonebook entry: Press to go to phonebook
editing mode.
3 RIGHT/ CALLS LIST
a) In idle mode/during a call: Press to access calls
list.
b) In editing mode: Press to move the cursor to the
right.
4 SPEAKER
a) In idle/pre-dial mode/during a call: Press to turn
on/off the speakerphone.


12 Getting to know your phone
b) Calls list/phonebook/redial list entry: Press to
make a call with speakerphone.
c) During ringing: Press to answer a call with
speakerphone.
5 CELLULAR
a) In pre-dial mode: Press to make a cellular call.
b) During an incoming cellular call: Press to answer
the cellular call.
6 DELETE/ FLASH
a) During message playback: Press to delete the
current message.
b) In idle mode: Press and hold to erase all read
messages (applicable only when all answering
machine messages are read, new message(s) will
not be deleted).
c) During a call: Press to insert a flash.
7 SKIP/ MEMO
a) During message playback: Press to skip to play
the next message.
b) In idle mode: Press and hold to hear a voice prompt
for recording a memo and then start to record a
memo.
Press
SAVE
key to stop memo recording.
8 #/ PAUSE/ ABC/ FORMAT
a) In idle/pre-dial/number editing mode/during a
call: Press to insert a "#", press and hold to insert a
pause.
b) In name editing mode: Press to toggle ABC/abc.
c) In calls list entry: Press to toggle the Caller ID
display format between 7, 8, 10 and 11 digits.
9 SCROLL DOWN/ VOLUME DOWN/ REDIAL LIST
a) In idle/pre-dial mode: Press to access redial list.
b) In menu mode: Press to scroll down.
c) During a call: Press to decrease volume.
d) Calls list/phonebook/redial list entry: Press to
scroll down the list.
e) In answering machine mode: Press to decrease
volume.
10 */ TONE
a) In idle/pre-dial/editing mode: Press to insert a "*".
b) During a call: Press to switch from pulse to tone
dialing temporarily if pulse mode was selected
before. After the call is ended, the dial mode will
change back to pulse.


Getting to know your phone 13
11 ALPHANUMERIC KEYPAD
a) In idle/pre-dial/editing mode/during a call: Press
to enter characters/numbers.
b) In idle mode: Press and hold to activate speed dial.
12 PLAY/ STOP
a) In idle mode: Press to playback answering machine
messages.
b) In message playback mode: Press to stop playing
messages. Press again to resume message
playback.
13 REPEAT/ ANNC
a) In idle mode: Short press to play the current
announcement or the current announcement mode.
Press and hold to hear a voice prompt of how to
record the personalized announcement of the
current answer mode, press
SAVE
key to stop
recording.
b) During message playback mode: Press once to
replay the current message from the beginning,
press twice to play the previous message.
14 ANNOUNCE MODE
a) In idle mode: Press to toggle between
Announce &
Record
/
Announce Only
mode.
15 ANS ON / OFF
a) In idle mode: Press to turn on or off the answering
machine.
16 LEFT/ PHONEBOOK
a) In idle mode/during a call: Press to access the
phonebook.
b) In editing mode: Press to move the cursor to the left.
17 LEFT SOFT KEY
a) In idle mode: Press to access intercom, press and
hold to enter registration mode.
b) In pre-dial/editing mode: Press to delete one
character/digit. Long press to delete all characters/
digits.
c) During a home call: Press to transfer the call to
another handset.
d) In calls list/phonebook entry: Press to back to the
previous level.
e) In answering machine mode: Press to delete the
current message playback.
18 BASE CRADLE
19 BLUETHOOTH LED 1 and BLUETOOTH LED 2
a) On when Bluetooth device 1 or 2 is connected with
the telephone base.
b) Off when Bluetooth device(s) is (are) disconnected
with the telephone base.


14 Getting to know your phone
Corded base LCD display
Display icons
In idle mode, the current time is displayed.
In idle mode the current date is displayed.
On when there is new voice mail not yet listened
to. Off when new voice mail has been listened to.
(For home line only)
Indicates when a new call has been received.
Off when all new calls have been viewed.
On when the answering machine is turned on.
Flashes when new answering machine
message is received.
On when a Bluetooth device is paired.
Off when Bluetooth feature is disabled.
/ On when Bluetooth device or is connected
with the telephone base.
Off When Bluetooth device(s) is (are)
disconnected from the telephone base.
On when the Cellular line is in use.
Flashes when the Cellular line is put on hold.
Off when the Cellular line is idle.
On when the Home line is in use.
Flashes when the Home line is put on hold.
Off when the Home line is idle.
On when the ringer volume is turned off.
On when the speakerphone is turned on.


Getting to know your phone 15
Overview of your cordless handset Get acquainted with the following 14 buttons on your
handset and their multi-function tasks.
1 Menu / Select
a) In idle mode: Press to access menu list.
b) In menu/editing mode: Press to confirm and save
the settings.
c) During a home call: Press to transfer the call to
another cordless handset or the corded base.
d) In calls list entry: Press to save the entry to the
phonebook.
e) In phonebook entry: Press to go to phonebook
editing mode.
2 Scroll up / Volume up
a) In menu mode: Press to scroll up.
b) In editing mode: Press to move cursor to the left.
c) During a call: Press to increase volume.
d) Calls list/phonebook/redial list entry: Press to
scroll up the list.
e) In answering machine mode: Press to increase
volume.
3 Right / Calls list
a) In idle mode/during a call: Press to access calls
list.
b) In editing mode: Press to move the cursor to the
right.


16 Getting to know your phone
4 Scroll down / Volume down / Redial list
a) In idle mode: Press to access redial list.
b) In menu mode: Press to scroll down.
c) In editing mode: Press to move cursor to the right.
d) During a call: Press to decrease volume.
e) Calls list/phonebook/redial list entry: Press to
scroll down the list.
f) In answering machine mode: Press to decrease
volume.
5 Talk off / Back
a) In menu/editing mode/phonebook entry: Press to
exit to previous level.
b) In pre-dial mode/calls list/redial list entry/
answering machine mode: Press to exit to idle.
c) During ringing: Press to silent the incoming ringer
temporarily.
d) During a call: Press to end a call, either home call
or cellular call.
6 Alphanumeric keypad
a) In idle/pre-dial/editing mode/during a call: Press
to enter characters/numbers.
b) In idle mode: Press and hold to activate speed dial.
7 # / Pause / ABC / Format
a) In idle/pre-dial/number editing mode/during a
call: Press to insert a #, press and hold to insert a
"Pause".
b) In name editing mode: Press to toggle ABC/abc.
c) In calls list entry: Press to toggle between 7, 8, 10
and 11 digit formats when returning calls from Caller
ID list.
d) In phonebook list entry: If the number is more than
15 digits, press to view the next page of remaining
digits.
8 Cellular
a) In idle mode: Press to make a cellular call.
b) During an incoming cellular call: Press to answer
the cellular call.
9 Microphone
10 Speaker
a) In idle/pre-dial mode/during a call: Press to turn
on/off the speakerphone.
b) Call List/phonebook/redial list entry: Press to
make a call with the speakerphone.
c) During ringing: Press to answer a call with the
speakerphone.
d) In answering machine mode: Press to toggle the
message playback via the earpiece or speakerphone.
Produkt Specifikationer
Mærke: | Motorola |
Kategori: | Trådløse DECT telefoner |
Model: | L514CBT |
Har du brug for hjælp?
Hvis du har brug for hjælp til Motorola L514CBT stil et spørgsmål nedenfor, og andre brugere vil svare dig
Trådløse DECT telefoner Motorola Manualer
15 Januar 2025
14 Januar 2025
5 Oktober 2024
24 August 2024
23 August 2024
19 August 2024
12 August 2024
8 August 2024
7 August 2024
3 August 2024
Trådløse DECT telefoner Manualer
- Archos
- Topcom
- Premier
- Sagemcom
- Emporia
- Ericsson
- Logicom
- Alcatel
- Sagem
- Lifetec
- Tiptel
- Hagenuk
- Nortel
- Multi Care Systems
- RTX
Nyeste Trådløse DECT telefoner Manualer
15 Januar 2025
15 Januar 2025
15 Januar 2025
15 Januar 2025
12 Januar 2025
12 Januar 2025
11 Januar 2025
11 Januar 2025
5 Oktober 2024
23 September 2024
