NEC Display Solutions of America, Inc.

PA500U/PA500X/PA550W/PA600X Installation Guide

Desktop and Ceiling Mount Rev 1.5

www.necdisplay.com PA500U/PA500X/PA550W/PA600X Page 1 of 13

Contents

Product Description, Lens Specs, Screen/Aspect Ratio

Notes and Formulas Pg 1

Distance Charts and Formulas Pg 2-4

Ceiling Mount/Desktop Installation Pg 5

Lens Shift Adjustable Range Pg 6

Cabinet Dimensions Pg 7

Cabinet Dimensions Pg 8

Cabinet Dimensions (Terminal Cover) Pg 9

Lens Dimensions (Optional) Pg 10-11

Ceiling Mount Dimensions and Input Panel Pg 12

Control Codes Pg 13

Product Description

Type: 3 panel LCD projector, Dimensions: 19.7”(W) x 6.5”(H) x 14.4”(D)

0.79 p-Si TFT w/MLA (PA500X/PA600X)

0.75 p-Si TFT w/MLA (PA550W) Weight: PA500X/550W/600X: 17.0 lbs

0.76 p-Si TFT w/MLA (PA500U) PA500U: 17.2 lbs.

Resolution: 1024 x 768 (4:3) Brightness: PA500X: 5000 Lumens

1920 x 1200 (16:10) PA500U: 5000 Lumens

PA550W: 5500 Lumens

Fan Noise: PA500X: 38 dB / 31dB @ 1 meter PA600X: 6000 Lumens

PA500U: 38 dB / 32dB @ 1 meter

PA550W: 38 dB / 31dB @ 1 meter

PA600X: 38 dB / 31dB @ 1 meter

Power Consumption: PA500X/PA550W: 464W (max) BTU’s: PA500X/PA550W: 1583 BTU/hour

PA600X: 464W (max) PA600X: 1583 BTU/hour

PA500U: 477W (max) PA500U: 1628 BTU/hour

Network Ready, integrated wired and wireless adapter

Manual: Lens Shift, Horizontal & Vertical /Zoom/ Focus

Lens Specifications

NP11FL: NP14ZL: Throw Ratio: ~ 0.8:1 Focal Length: 13.2mm Throw Ratio: 2.97 -4.79:1 Focal Length: 48.5 - 77.6mm

Screen Sizes: 60”-150” F/#:2.3 Screen Sizes: 60” - 200” F/#:2.2

NP12ZL: NP15ZL:Throw Ratio: 1.19 - 1.56:1 Focal Length: 19.4 – 25.3mm Throw Ratio: 4.70 - 7.02:1 Focal Length: 76.6 - 116.5mm

Screen Sizes: 40” - 200” F/#:2.2 _________ Screen Sizes: 80” - 200” F/#:2.2

NP13ZL: Throw Ratio: 1.50 - 3.02:1 Focal Length: 24.4 – 48.6mm

Screen Sizes: 40” - 200” F/#:1.7

Screen/Aspect Ratio

4:3, 16:9 and 16:10 screens are fully supported with proper aspect ratio control for both type sources using NEC developed

scaling technology. Menu selections have settings for each screen type and aspect ratio control for each source type.

Notes

 For screen sizes not indicated on the projection tables, use the formulas below.

If the figures on the tables do not match the results of formulas, use the figures in the table..

 Distances are in inches, for millimeters multiply by 25.4.

  Distances may vary 5%.

NEC Display Solutions of America, Inc.

PA500U/PA500X/PA550W/PA600X Installation Guide

Desktop and Ceiling Mount Rev 1.5

www.necdisplay.com PA500U/PA500X/PA550W/PA600X Page 2 of 13

Formulas: 4:3 Aspect Ratio (PA500X/PA600X—XGA)

The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size

varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to

calculate all screen dimensions. Plug in the image width for “W” in the Projection Formulas.

Refer to the diagrams and charts for popular screen sizes on page 2 and 3:

Projection Formulas: Definitions: 4:3 Screen Formulas:

NP11FL: C = 0.827W – 1.374 W = Image Width W = H x 4/3

NP12ZL: C(Wide) = 1.214W – 1.794 ------ C(Tele) = 1.578W – 1.794 H = Image Height (size) H = W x 3/4

NP13ZL: C(Wide) = 1.524W – 1.974 ------ C (Tele) = 3.043W – 1.972 C = Throw distance Diagonal = W x 5/4

NP14ZL: C(Wide) = 3.034W – 4.844 ------ C(Tele) = 4.855W – 4.844

NP15ZL: C(Wide) = 4.797W – 7.630 ------ C(Tele) = 7.291W – 7.630

Note: Tilting the front of the projector up or down by more than 45° from level could reduce lamp life by up to 20%.

Distance Chart for popular 4:3 screens

Rear Lens

NP11FL

Diagonal Width(W) Height (H) 0.8:1

inches inches inches inches

40 32 24 25.09 37.05 - 48.7 46.8 - 95.40 92.2 150.5

60 48 36 38.32 56.48 - 74.0 71.2 - 144.09 140.8 - 228.2 222.5 - 342.3

67 53.6 40.2 42.95 63.28 - 82.8 79.7 - 161.13 157.8 - 255.4 249.4 - 383.2

72 57.6 43.2 46.26 68.13 - 89.1 85.8 - 173.30 169.9 - 274.8 268.5 - 412.3

84 67.2 50.4 54.20 79.79 - 104.2 100.4 - 202.52 199.0 - 321.4 314.6 - 482.3

90 72 54 58.17 85.61 - 111.8 107.8 - 217.12 213.6 - 344.7 337.6 - 517.3

100 80 60 64.79 95.33 - 124.4 119.9 - 241.47 237.9 - 383.6 376.0 - 575.7

120 96 72 78.02 114.75 - 149.7 144.3 - 290.16 286.4 - 461.2 452.7 - 692.3

150 120 90 97.87 143.89 - 187.6 180.9 - 363.19 359.2 - 577.8 567.9 - 867.3

180 144 108 NA 173.02 - 225.4 217.5 - 436.22 432.1 - 694.3 683.0 - 1042.3

210 168 126 NA 202.16 - 263.3 254.1 - 509.25 504.9 - 810.8 798.1 - 1217.3

240 192 144 NA 231.29 - 301.2 290.6 - 582.28 577.7 - 927.3 913.3 - 1392.2

270 216 162 NA 260.43 - 339.1 327.2 - 655.32 650.5 - 1043.8 1028.4 - 1567.2

300 240 180 NA 289.57 - 376.9 363.8 - 728.35 723.3 - 1160.4 1143.5 - 1742.2

400 320 240 NA 386.69 - 503.2 485.7 - 971.79 966.0 - 1548.8 1527.3 - 2325.5

500 400 300 NA 483.81 - 629.4 607.6 - 1215.23 1208.8 1937.2 1911.0 - 2908.8

Screen Size (4:3)

4.70 - 7.20:1

NP12ZL NP13ZL NP14ZA NP15ZL

2.97 -4.79:1

Zoom Lenses

1.19 - 1.56:1 1.50 - 3.02:1

inchesinches inches inches

Produkt Specifikationer

Mærke:	NEC
Kategori:	videoprojektorer
Model:	PA600X
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Vægt:	7700 g
Produktfarve:	Hvid
Produkttype:	Projektor til stort spillested
Wi-Fi:	Ingen
Understøttede videotilstande:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
3D:	Ingen
Indbyggede højttaler(e):	Ja
Opbevaringstemperatur (T-T):	-10 - 50 °C
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Format til analogt signal:	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Udgangseffekt (RMS):	10 W
Antal HDMI-porte:	1
DVI-port:	Ingen
Ethernet LAN-porte (RJ-45):	1
Komponentvideo (YPbPr/YCbCr) indgang:	1
Ethernet LAN:	Ja
Strømforbrug (standby):	16 W
Strømforbrug (typisk):	464 W
Driftstemperatur (T-T):	5 - 40 °C
Dimensioner (BxDxH):	499 x 366 x 164 mm
Kabler inkluderet:	VGA
Batterier inkluderet:	Ja
Understøttede grafikopløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Sammensat videoindgang:	1
Støjniveau:	38 dB
Fjernbetjening inkluderet:	Ja
Certificering:	UL, C-UL, NOM
Strømforbrug (strømbesparelse):	372 W
Full HD:	Ja
Antal indbyggede højttalere:	1
Lydindgang:	1
Fokus:	Vejledning
Kontrastforhold (typisk):	2000:1
Horisontal scanningsområde:	15 - 108 kHz
Antal DisplayPorts:	1
Antal VGA-porte (D-sub):	3
Brændviddeområde:	24.4 - 32.5 mm
Projektor lysstyrke:	6000 ANSI lumens
Projektionsteknologi:	LCD
Projektor indbygget opløsning:	XGA (1024x768)
Skærmstørrelse kompatibilitet:	25 - 500 "
Projiceringsafstand:	0.74 - 20.9 m
Trapezkorrektion, vertikal:	30 °
Matrix størrelse:	0.8 "
Vertikalt scanningsområde:	48 - 120 Hz
RS-232-porte:	1
Levetid for lyskilde:	3000 t
Lampeeffekt:	330 W
Levetid for lyskilde (økonomisk tilstand):	4000 t
Lyskilde type:	Lampe
Seriel grænsefladetype:	RS-232
Trapezkorrektion, horisontal:	40 °
Støjniveau (økonomisk tilstand):	31 dB
HD-Ready:	Ja
Lydudgang:	1
Maksimal analog opløsning:	1920 x 1200 pixel
