Neff B6ACM7AG7A Manual

Neff Ovn B6ACM7AG7A

Læs gratis den danske manual til Neff B6ACM7AG7A (3 sider) i kategorien Ovn. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Neff B6ACM7AG7A, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/3
1/3
N 50, Built-in
ov
en, 60 x 60 cm, G
r
ap
h
it
e-Grey
B6ACM7AG7A
Included accessories
1 x enamel baking tray, 1 x combination grid, 1 x universal pan
Optional accessories
Z11AB15A0 : , Z11AU15A0 : , Z11CR10X0 : , Z11GU20X0 : ,
Z11TI15X0 : , Z12CB10A0 : Baking tray, anthracite enamelled ,
Z12CL10A0 : , Z12CM10A0 : Moussaka pan, anthracite enamelled ,
Z12CN10A0 : , Z12CP10A0 : , Z12CU10A0 : Multipurpose pan,
anthracite enamelled , Z1365WX0 : Wireless food thermometer ,
Z1608BX0 : Full ext rails, level independent , Z1650BE0 : Half tray ,
Z1655CA0 : Air Fry & Grill tray , Z1913X0 : Baking Stone
Joyful interaction: unrestricted access thanks to the retracting
Hide® door, Meatprobe and Pyrolytic Self-Cleaning.
√ Hide® – The unique fully disappearing oven door.
√ Home Connect - Control your oven via the App.
√ Singlepoint Meatprobe - keeps one eye constantly on the oven
temperature
√ Pyrolytic Self-Cleaning with Easy Clean: The best duo for optimal
cleaning.
√ LCD-Display – simple, straightforward with large characters for
clear reading
Features
Technical Data
Gross weight : 42.3 kg
Built-in / Free-standing : Built-in
Cleaning : Pyrolytic+Hydrolytic
Required niche size for installation (HxWxD) : 585-595 x 560-568 x
550 mm
Dimensions (HxWxD) : 595x594x548 mm
Dimensions of the packed product (HxWxD) : 675 x 660 x 690 mm
Control Panel Material : Glass
Door Material : Glass
Net weight : 39.6 kg
Usable volume of cavity : 71 l
Heating functions : Bottom heat, Bread Baking Setting, Conventional
heat, Full width grill, Hot Air, Hot air gentle, Hot Air grilling, Pizza
setting
Number of interior lights : 1
Length electrical supply cord : 120.0 cm
Interior Lights - cavity 1 : 1
Telescopic Racking System : Accessory
Included accessories : 1 x enamel baking tray, 1 x combination grid, 1
x universal pan
Broil Element Wattages cavity 1 : 2800 W
Convection Element Wattages cavity 1 : 2200 W
Energy efficiency rating : A+
Energy consumption per cycle conventional (2010/30/EC) : 0.94
kWh/cycle
Energy consumption per cycle forced air convection (2010/30/EC) :
0.69 kWh/cycle
Energy efficiency index (2010/30/EC) : 81.2 %
Connection Rating : 3600 W
Fuse protection : 16 A
Voltage : 220-240 V
Frequency : 50; 60 Hz
Plug type : no plug
Energy input : Electric
Required cutout/niche size for installation (in) : x
Dimensions of the packed product : 26.57 x 25.98 x 27.16
Net weight : 87.000 lbs
Gross weight : 93.000 lbs
Length electrical supply cord : 120.0 cm
Net weight : 39.6 kg
'!2E20AE-cibedg!
2/3
N 50, Built-in
ov
en, 60 x 60 cm, G
r
ap
h
it
e-Grey
B6ACM7AG7A
Features
Heating Functions
●
Oven with 8heating methods:
Bread Baking, Full surface grill, CircoTherm® gentle, CircoTherm®,
Top/bottom heating, Pizza Setting, Bottom heating, Circo-roasting
●
Heating methods only via Home Connect App: air fry, let rest,
preheating
●
Temperature range 30 °C - 275 °C
●
Cavity volume: 71 net usable litres
Racks and Rails
●
Number of shelf levels: 4
●
Large capacity oven with shelf supports, Telescopic shelf rails
available as optional accessory
Design
●
Graphite-Grey Edition
●
Rotary Control, Retractable control knobs
●
Cavity inner surface: enamel
Cleaning
●
Pyrolytic self cleaning
●
EasyClean® program
●
Full glass inner door - safer touch door
Convenience
●
White LCD display
●
Electronic clock with start / stop function
●
Automatic temperature proposal, automatic start, Actual
temperature display, Optical temperature control, Meat probe
function
●
Hide®, the fully retracting oven door
●
Bar handle
●
Single-point meat probe
●
Rapid heat-up
●
Halogen lighting
●
Cooling fan
●
Stainless-steel fan
●
Info button
●
HomeConnect
Accessories
●
1 x combination grid, 1 x universal pan, 1 x enamel baking tray
Safety Features
●
Maximum door temperature 30° C
●
Quadruple glazed CoolTouch door
●
Automatic door lock during pyrolysis, Individual adjustable child
lock, Safety switch off, Residual heat indicator, Door contact
switch
Technical Information
●
Length of mains cable: 120 cm
●
Nominal voltage: 220 - 240 V
●
Total connected load electric: 3.6 KW
Dimensions
●
Appliance dimensions (HxWxD): 595 mm x 594 mm x 548 mm
●
Installation dimensions (HxWxD): 585 mm - 595 mm x 560 mm -
568 mm x 550 mm
●
Please reference the built-in dimensions provided in the
installation drawing
●
We recommend you to choose complementary products within
N50, in order to assure an optimal design combination of your
Built-In appliances.

Produkt Specifikationer

Mærke: Neff
Kategori: Ovn
Model: B6ACM7AG7A
