What it does:

The netis WF2409D 300Mbps Wireless N Router is a combined wired and wireless device for SOHO network

applications. It’s compatible with 802.11b/g/n devices and provides the wireless transfer speed up to 300Mbps,

offering a powerful performance on faster downloading, Internet calling and HD video streaming. Bundled with

three 5dBi high gain detachable antennas, it ensures a better wireless coverage and allows you to enjoy the

wireless freedom anywhere around your home.

WF2409D

Easy Network, Trustable

Features:

>Incredible wireless high speed up to 300Mbps, great for faster downloading, 

Internet calling and HD video streaming

>MIMO high gain 5dBi antennas providing maximum range and stable connections

>Various WAN connection types in Router mode- DHCP, Static IP, PPPoE, WISP

>Multiple wireless modes- AP, Repeater, AP+WDS, WDS, Client

>Multi-SSID providing additional separate network for guests and friends

300Mbps Wireless N Router

Detachable

5dBi

Repeater

QoS

WISP

WPS

WDS Multi SSID

Mbps

300

>Easy wireless security setup at a push of the WPS button

>Intelligent bandwidth control to manage the bandwidth usage for each computer reasonably

>Internet Access Control- IP filtering, MAC Filtering, Domain Filtering based on time

AD-1101

Fast Ethernet PCI Adapter

300Mbps Wireless N Router

Wired

Wireless

WF2409D

DL4102

Internet

WF-2109

300Mbs Wireless N USB Adapter

WF-2113

300Mbs Wireless N PCI-E Adapter

Related products

WF-2113

AD-1101

WF

DL4102

Wired ADSL2+ Modem

Specification:

64/128-bit WEP WPA-PSK/WPA2-PSK (TKIP/AES) SSID Broadcast Enable/ Disable Wireless MAC FilteringWireless Security

IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Wireless

Standards

Signal Rate

Frequency Range

Transmit Power

Up to 300Mbps

2.4-2.4835GHz

20dBm(MAX)

Data Transfer Rate

Wireless Mode AP, WDS, AP+WDS, Repeater, Client, Multiple AP

Dimensions(L x W x H )

IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX

Hardware

Standard

Interface

LED

Button

1 * 10/100M Auto MDI/MDIX RJ45 WAN port

4 * 10/100M Auto MDI/MDIX RJ45 LAN port

PWR, WPS, SYS, WLAN, WAN, LAN1-LAN4

Default, WPS

DC 9V/500mA (Output)

145 x 155 x 35 mm

Power Supply

Others

DHCP(Dynamic IP), PPPoE, Static IP, WISP

Software

WAN Type

Port Forwarding

QoS

Access Control

Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port

WMM, Application Priority, Bandwidth Control

IP/MAC/Domain filtering

PPTP, L2TP, IPSEC

DDNS, Static Routing, Firmware upgrade

VPN Pass-through

FCC, CE

Others

Certification

Environment

Package 1 *WF2409D 1 * Quick Installation Guide 1 * Power Adapter 1 * Ethernet Cable 1 * Cradle    

Specifications are subject to change without notice. Netisis a registered trademark of Netis Systems Co., Ltd. Other brands and product names are trademarks or

registered trademarks of their respective holders. No part of the specifications maybe reproduced in any form or by any means or used to make any derivative such

as translation, transformation, or adaptation without permission fromNetis Systems Co., Ltd.

WF2409D

300Mbps Wireless N Router

Antenna 3 * external 5dBi antenna, detachable

Topological Graph:

802.11n: 40MHz (300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)

20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)

801.11g: (54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)

802.11b: (11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)

Operating Temperature: 0 ~40 Storage Temperature: -40 ~70℃ ℃ ℃ ℃

Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
