Side 1/65
Introduction........................................................... 2
In the Package.................................................................2
Product Registration.........................................................2
Using This Manual........................................................ 2
MIDI Controller Section Main Features......................... 2
Audio Section Main Features........................................ 2
Synthesizer Features.......................................................2
Quick Start Guide.................................................. 3
Conventions used in this Manual.................................... 3
Connecting Up To equipment......................................... 3
Stand Alone Operation.................................................... 3
Playing the Synthesizer........................ ....................... 3.....
Windows XP USB Driver Installation............................. 4
MAC OS X USB Driver Installation................................. 4
About ASIO on Windows XP........................................... 4
About Core Audio on MAC OS X..................................... 4
Selecting The X-Station as the Audio Device................. 5
Selecting The X-Station as the Audio Device in Cubase. ........ 5
The X-Station Control Panel........................................... 5
About Latency.................................................................. 5
Selecting The X-Station as the MIDI Device in Cubase.......... 6
Selecting The X-Station as the Audio Device in LOGIC.. ........ 6
Selecting The X-Station as the Audio Device in Reason.. ........ 7
Selecting The X-Station as the MIDI Device in Reason.. ........ 7
Controlling a VST Plug-In or Reason Instrument........................ 7
Factory Supplied Templates........................................... 7
Using The Programmable Template Controls................ 8
Sending A Snapshot Of The Controls............................10
Selecting A Sound On External MIDI Devices.............. 10
Changing The Action Of The Pitch / Mod Joystick.........10
Audio Connection And Setup.........................................10
Setting Up The Microphone Or Instrument Inputs.........10
Monitoring......................................................................10
Recording And Listening................................................10
Recording And Listening With Effects............................11
MIDI Tutorial......................................................... 12
Introduction................................................................... 12
How MIDI Ports Are Used............................................ 12
MIDI Messages............................................................. 12
Detailed Operation.............................................. 15
Front Panel Layout....................................................... 15
Modes And Menus....................................................... 16
Using Menus................................................................ 16
Entering Text................................................................ 16
The Template Common Menu...................................... 17
Template Edit Mode (Editing A Template).................... 18
The Template Edit ‘CC’ Pages..................................... 18
The Template Edit ‘NRPN’ & ‘RPN’ Pages.................. 19
The Template Edit ‘MMC’ Pages.................................. 19
The Template Edit ‘Note On/Off’ Pages....................... 20
The Template Edit ‘SYSEX MESSAGE’ Pages............ 20
The Template Edit ‘Program Change’ Pages............... 21
Using The X / Y Touchpad........................................... 21
Using The Footswitch Or Pedal................................... 22
Saving A Template To Memory..................................... 22
The Dual Multi Effects Processor................................. 23
The Delay Effect........................................................... 23
The Reverb Effect......................................................... 24
The Chorus Effect......................................................... 24
The Compressor........................................................... 25
The Distortion Effect..................................................... 26
The EQ Processor........................................................ 26
Advanced Features............................................. 27
Using The Transport Buttons....................................... 27
The Global Mode Menu.............................................. 27
Saving The Global Settings To Memory....................... 29
Upgrading The Operating System From MIDI............. 29
Synthesis Tutorial............................................... 30
Elements Of A Sound.................................................. 30
The Oscillators And Mixer............................................ 31
The Filter....................................................................... 32
Envelopes And Amplifier.............................................. 33
LFOs............................................................................. 35
Memories...................................................................... 35
Summary...................................................................... 35
The KS Synthesizer............................................. 36
Introduction................................................................... 36
Selecting KS Synth Patches........................................ 36
Editing A Synth Patch (Sound)..................................... 37
Saving A Synth Patch................................................... 37
Using Menus................................................................ 38
The Oscillator / Mixer Section..................................... 38
The Filter Section......................................................... 40
The LFOs Section........................................................ 41
The Envelopes Section................................................ 42
The Arpeggiator Section............................................... 43
The Effects Section...................................................... 44
The Oscillator Menu..................................................... 44
The Mixer Menu........................................................... 45
The Filter Menu............................................................ 47
The LFO Menu............................................................. 47
The Arpeggiator Menu.................................................. 49
The Sync Menu............................................................ 50
The Wheels Menu........................................................ 51
The Aftertouch And Breath Menu................................. 52
The Pan Menu.............................................................. 53
The KS Synth Mode Global Menu................................ 54
Routing MIDI To And From The KS Synthesizer.......... 54
The KS Synth General Settings................................... 55
Saving The KS Synth General Settings....................... 55
Appendix.............................................................. 56
Troubleshooting............................................................ 56
Using The X-Station With Reason............................... 57
Known Anomalies With Reason.................................. 57
Preset Template Listings...........................................58-61
The KS Synth Patch Preset Listings............................ 62
MIDI Implementation Chart........................................... 64
Safety CE Notices And Approvals................................ 65
CONTENTS
Contents
• •1
Thank you for purchasing the X-Station controller keyboard and synthe-
sizer. The X-Station is a state of the art product, it turns any com-
puter into a complete, professional music & audio production
workstation with hardware synthesizer, audio & MIDI interface,
control surface and effects processor – all in one package with
USB, PSU or battery power!
When used with a computer running a MIDI / Audio sequencer package
it will provide a superb, compact recording setup.
It may be used to control sequencers, popular software virtual instru-
ments on a computer or traditional hardware instruments via either a
USB connection or a standard MIDI interface. In addition to the control
features it contains two audio pre-amplifiers together with a twin multi-
effects processor that allows the recording and replay of mono or
stereo audio signals to and from a computer.
The front panel provides a wealth of programmable controls arranged in
the format of a traditional synthesizer, each of which can be configured
to suit the needs of the instrument to be controlled. Each control can be
stored within a Template memory for instant recall at a later time.
The X-Station is equally at home in a live performance or studio situa-
tion where it can be used as a stand-alone synthesizer, MIDI controller
keyboard and recording device. Its comprehensive range of controls
may be used to dynamically alter any sound parameters precisely and
in real time whilst simultaneously recording and replaying stereo audio
data.
In the package
The X-Station package contains the following list of items.
•Main Keyboard X-Station Unit
•Power Supply
•User Manual
•USB Cable
•Set of Template Overlays
•X-Station Driver and Resources CD-ROM
When opening the package, please make sure all of the items above
are present, if not then please contact your local dealer.
www.novationmusic.com - Product Registration
Please take the time to register your new Novation X-Station. Point
your browser to www.novationmusic.com and complete the registra-
tion form. We advise that you visit www.novationmusic.com from time
to time to check for feature upgrades along with the appropriate docu-
mentation.
Using This Manual
This manual consists of seven sections; Introduction, Quick Start
Guide MIDI Tutorial, , Detailed Operation, Advanced Features,
Synthesis Tutorial The KS Synthesizerand . For easy reference, the
section name is printed at the top of each page. An is alsoAppendix
provided containing reference data.
It is assumed that the reader already has a basic knowledge of MIDI in
order to configure user Templates. Those with limited MIDI experience
may find the MIDI Tutorial useful. Although very little MIDI knowledge is
required to use the the X-Station with the factory programmed
Templates.
It is recommended that this manual is read in sequence chapter by
chapter.
The main features of both its MIDI controller capability and Audio oper-
ation are listed below.
MIDI Controller Section Main Features
X-Station features a superb two, four or five octave semi-weighted
velocity-sensitive keyboard with combined Pitch bend and Modulation
joystick. The keyboard is transposable up or down across the entire
MIDI note range and can transmit Channel Aftertouch.
A programmable X/Y touch pad surface for simultaneous control of mul-
tiple parameters is provided.
MIDI or USB operation. USB and MIDI may be used simultaneously. A
MIDI OUT port, a MIDI IN Port, a Foot pedal input socket and a
Footswitch input socket are available.
Power can be supplied by the USB port, Batteries or a 9V DC adapter.
A virtual synthesizer control panel layout comprising 28 buttons, 16
pots, 3 encoders and 9 sliders are assignable to each template. There
is no need for template labels for control of most synthesizers
Any front panel control may be configured to transmit on any MIDI
channel, to any destination utilising the comprehensive MIDI specifica-
tion. Available options include Controller numbers, NRPNs, RPNS,
Bank Change, Program Change and definable System Exclusive
Strings. System Exclusive strings may be up to 20 bytes long. Control
data may be inserted anywhere within the System Exclusive message.
40 Template editable memories are available. Each Template contains
definitions for all front panel controls. Templates may be individually
named for easy reference and saved to/from an external sequencer via
MIDI Sysex bulk dumps
Audio Section Main Features
Two Novation high precision, low noise high bandwidth audio pre-ampli-
fiers with phantom power and over 70 dB headroom deliver a warm,
clear signal typical of Novation's commitment to sonic excellence.
Complete multi-effects processors are available per input channel fea-
turing simultaneous Reverb / Chorus-Phaser / Delay / Compressor /
Distortion and EQ.
Integrated USB low latency Audio and MIDI - Requires just a single
USB connection a computer.
High power independent headphone output with separate stereo con-
verter for zero latency monitoring of input signal with or without effects
44.1 / 48 Khz 24 bit simultaneous 2 channel Audio input and output
operation
Driver software included to run on Windows XP or MAC OSX.
Synthesizer Features
The X-Station includes a 3-oscillator virtual analog synthesizer model
based on the renowned Novation KS-series and is 8-voice polyphonic.
The extensive control interface provides instant access to most param-
eters, making sound creation fast and intuitive. The synthesizer is total-
ly integrated with computer recording setups: The stereo audio output is
sent straight through the USB cable onto the track into any ASIO-com-
patible sequencer.
There are 200 excellent factory sound programs which have been care-
fully crafted to cover most styles of music and programs can be easily
imported and exported into a sysex librarian.
INTRODUCTION
Using This Manual - Main Features - Conventions Used
• •2

Produkt Specifikationer

Mærke: Novation
Kategori: Ikke kategoriseret
Model: X-Station 61

Har du brug for hjælp?

Hvis du har brug for hjælp til Novation X-Station 61 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret Novation Manualer

Novation

Novation Launchkey MMini 25 K4 Manual

6 September 2024
Novation

Novation Launch Control XL MKII Manual

3 September 2024
Novation

Novation mm10-X Manual

29 August 2024
Novation

Novation Xio 49 Manual

21 August 2024
Novation

Novation FLkey Mini Manual

21 August 2024
Novation

Novation Launchpad Manual

19 August 2024
Novation

Novation A-Station Manual

16 August 2024
Novation

Novation nio 2|4 Manual

15 August 2024
Novation

Novation Supernova II Rack Manual

15 August 2024
Novation

Novation Launchkey 25 MK1 Manual

15 August 2024

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

AXESS

AXESS AXABH-FD1 Manual

30 Juli 2025
Yealink

Yealink SIP-T23P Manual

30 Juli 2025
Tripp Lite

Tripp Lite TLM606NC Manual

30 Juli 2025
Yealink

Yealink MeetingBoard 65 Manual

30 Juli 2025
Festo

Festo EMME-AS-80-M-HS-AMXB Manual

30 Juli 2025
Rothenberger

Rothenberger ROGROOVER 1-12 Manual

30 Juli 2025
Advantech

Advantech WISE-750 Manual

30 Juli 2025
Heylo

Heylo StaubStop 3000 Manual

30 Juli 2025
Advantech

Advantech ARES-5222A Manual

30 Juli 2025
Tripp Lite

Tripp Lite SRGP1KO Manual

30 Juli 2025
