Side 1/49

1English

Table of Contents ...................................................................................1

Usage Notice ..........................................................................................2

Safety Information .........................................................................................2

Precautions....................................................................................................3

Eye Safety Warnings .....................................................................................5

Introduction.............................................................................................6

Product Features ...........................................................................................6

Package Overview.........................................................................................7

Product Overview ..........................................................................................8

Main Unit ................................................................................................................ 8

Control Panel ......................................................................................................... 9

Connection Ports ................................................................................................. 10

Remote Control .................................................................................................... 11

Installation ............................................................................................12

Connecting the Projector .............................................................................12

Powering On/Off the Projector .....................................................................13

Powering On the Projector ................................................................................... 13

Powering Off the projector ................................................................................... 14

Warning Indicator ................................................................................................. 14

Adjusting the Projected Image.....................................................................15

Adjusting the Projector’s Height ........................................................................... 15

Adjusting the Projector’s Zoom / Focus ............................................................... 16

Adjusting Projected Image Size ........................................................................... 16

User Controls .......................................................................................17

Control Panel & Remote Control .................................................................17

On-screen Display Menus ...........................................................................20

How to operate .................................................................................................... 20

Menu Tree ............................................................................................................ 21

Image ................................................................................................................... 22

Display ................................................................................................................. 26

Setup .................................................................................................................... 30

Options ................................................................................................................. 35

Appendices...........................................................................................38

Troubleshooting ...........................................................................................38

Image Problems .................................................................................................. 38

Intermission Problems ........................................................................................41

Projector Status Indication .................................................................................. 41

Remote Control Problems ................................................................................... 43

Replacing the Lamp.....................................................................................44

Compatibility Modes ....................................................................................46

Optoma Global Ofces ................................................................................47

Regulation & Safety notices ........................................................................49

Table of Contents

English

Usage Notice

Safety Informations

The lightning ash with arrow head within an equilateral triangle is

intended to alert the user to the presence of uninsulated “dangerous

voltage” within the product’s enclosure that may be of sufcient magni-

tude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of import operating and maintenance (servicing)

instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THE PROJECTOR TO RAIN OR MOISTURE. DANGEROUS HIGH

VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE

CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

Class B emissions limits

This Class B digital apparatus meets all requirements of the Canadian Inter-

ference-Causing Equipment Regulations.

Important Safety Instruction

1. Read these instructions –before using this projector.

2. Keep these instructions –for future reference.

3. Follow all instructions.

4. Install in accordance with the manufacturer’s instructions :

A. Do not block any ventilation openings. To ensure reliable

operation of the projector and to protect it from overheating, put the

projector in a position and location that will not interfere with its proper

ventilation. For example, do not place the projector on a bed, sofa,

carpet, or similar surface that may block the ventilation openings. Do not

put it in an enclosure, such as a bookcase or a cabinet that may keep air

from owing through its ventilation openings.

B. Do not use this projector near water or moisture. To reduce

the risk of re or electric shock, do not expose the projector to rain or

moisture.

C. Do not install near any heat sources, such as radiators, heaters,

stoves or other apparatus (including ampliers) that produce heat.

5. Clean only with a dry cloth.

6. Only use attachments/accessories specied by the manufacturer.

7. Refer all servicing to qualied service personnel. Servicing is required

when the projector has been damaged in any way, such as:

 Power supply cord or plug is damaged.

 Liquids have spilled or objects have fallen into the apparatus.

 The projector has been exposed to rain or moisture, does not operate

normally, or has been dropped.

Do not attempt to service this projector yourself. Opening or removing

covers may expose you to dangerous voltages or other hazards. Please

call Optoma to be referred to an authorized service center near you.

8. Do not let objects or liquids enter the projector as they may touch

dangerous voltage points or short-out parts that could result in a re or

electric shock.

9. See projector enclosure for safety related markings.

10. The projector should not be adjusted or repaired by anyone except prop-

erly qualied service personnel.

Produkt Specifikationer

Mærke:	Optoma
Kategori:	videoprojektorer
Model:	TX330
Vekselstrømsindgangsspænding:	100 - 240 V
Bredde:	205.5 mm
Dybde:	156 mm
Højde:	64 mm
Vægt:	1100 g
Produktfarve:	Grå
Lampe type:	P-VIP
Wi-Fi:	Ingen
Bluetooth:	Ingen
Understøttede videotilstande:	1080i,480i,480p,576i,576p,720i
3D:	Ingen
Format til analogt signal:	NTSC,PAL,SECAM
Antal HDMI-porte:	1
DVI-port:	Ingen
Antal USB 2.0-porte:	1
Ethernet LAN:	Ingen
Strømforbrug (standby):	1 W
Strømforbrug (typisk):	225 W
Driftstemperatur (T-T):	5 - 40 °C
Dimensioner (BxDxH):	205.5 x 156 x 64 mm
Kabler inkluderet:	Composite,HDMI,USB,VGA
Batterier inkluderet:	Ja
Understøttede grafikopløsninger:	1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 800 (WXGA),1400 x 1050 (SXGA+),640 x 480 (VGA),800 x 600 (SVGA)
Sammensat videoindgang:	1
Støjniveau:	33 dB
Fjernbetjening inkluderet:	Ja
Forbindelsesteknologi:	Ledningsført
Placering:	Loft
Indbygget kortlæser:	Ingen
Full HD:	Ingen
Antal lamper:	1 Lampe( r)
Bæretaske:	Ja
Cardbus PCMCIA slot type:	Ingen
Slot til kabellås:	Ja
Billedformat:	4:3
Fokus:	Vejledning
Antal farver:	16,78 millioner farver
Kontrastforhold (typisk):	2000:1
Horisontal scanningsområde:	15 - 100 kHz
Antal VGA-porte (D-sub):	1
Kabellåseslids type:	Kensington
Zoom kapacitet:	Ja
Brændviddeområde:	21.79 - 23.99 mm
Projektor lysstyrke:	2200 ANSI lumens
Projektionsteknologi:	DLP
Projektor indbygget opløsning:	XGA (1024x768)
Skærmstørrelse kompatibilitet:	22.9 - 302 "
Projiceringsafstand:	1 - 12 m
Ensartethed:	85 %
Trapezkorrektion, vertikal:	-18 - 18 °
Matrix størrelse:	0.55 "
Vertikalt scanningsområde:	43 - 85 Hz
Forskydning:	115 %
Throw-forhold:	1.95 - 2.15:1
Zoom type:	Vejledning
Levetid for lyskilde:	3000 t
Lampeeffekt:	165 W
Levetid for lyskilde (økonomisk tilstand):	5000 t
Lyskilde type:	Lampe
3D Ready:	Ingen
Antal af S-video-indgange:	1
Optisk diskafspiller type:	Ikke inkluderet
Zoomforhold:	1.1:1
Støjniveau (økonomisk tilstand):	31 dB
HD-Ready:	Ingen
Maksimal analog opløsning:	1400 x 1050 pixel
