Side 1/4

9M RETRACT AB LE AIR HOSE REEL

9M RE T RACT ABLE AIR H OSE REE L

RETRACTABLE

AIR HOSE REEL

INSTRUCTION MANUAL

SPECIFICATIONS

Max. Operating Pressure: 10bar (145psi)

Connecting Hose Length: 1m

Air Hose Length: 9m

Working Temperature: 5 to 60°C

Swivel Range: 0 to 180°

Fittings: ¼” BSP Nitto

Weight: 2.815kg

AAHR-090

STANDARD EQUIPMENT

IN ORDER TO MAKE A CLAIM UNDER THIS

WARRANTY YOU MUST RETURN THE PRODUCT

TO YOUR NEAREST BUNNINGS WAREHOUSE WITH

YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO

RETURNING YOUR PRODUCT FOR WARRANTY

PLEASE TELEPHONE OUR CUSTOMER SERVICE

HELPLINE:

Australia 1800 069 486

New Zealand 0508 069 486

3 YEAR REPLACEMENT WARRANTY

Your product is guaranteed for a period of 36 months from the

original date of purchase. If a product is defective it will be replaced

in accordance with the terms of this warranty. Warranty excludes

consumable parts, for example: valve adapters and accessories.

WARNING! The following actions will result in the warranty

being void.

• If the tool has been operated on a supply voltage other than that

speciﬁed on the tool.

• If the tool shows signs of damage or defects caused by or

resulting from abuse, accidents or alterations.

• Failure to perform maintenance as set out within the instruction

manual.

• If the tool is disassembled or tampered with in any way.

• Professional, industrial or high frequency use.

WARRANTY

TO ENSURE A SPEEDY RESPONSE PLEASE

HAVE THE MODEL NUMBER AND DATE OF

PURCHASE AVAILABLE. A CUSTOMER SERVICE

REPRESENTATIVE WILL TAKE YOUR CALL AND

ANSWER ANY QUESTIONS YOU MAY HAVE

RELATING TO THE WARRANTY POLICY OR

PROCEDURE.

OZITO Australia/New Zealand (Head Ofﬁce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.

ozito.com.au

Air Hose Reel

3 x Wall Plugs & 3 x Screws

0520

The beneﬁts provided under this warranty are in addition to other

rights and remedies which are available to you at law.

Our goods come with guarantees that cannot be excluded at law. You

are entitled to a replacement or refund for a major failure and for

compensation for any other reasonably foreseeable loss or damage.

You are also entitled to have the goods repaired or replaced if the

goods fail to be of acceptable quality and the failure does not amount

to a major failure.

Generally you will be responsible for all costs associated with a claim

under this warranty, however, where you have suffered any additional

direct loss as a result of a defective product you may be able to claim

such expenses by contacting our customer service helpline above.

RETRACTABLE AIR HOSE REEL WARNINGS

WARNING! The appliance is not to be used by

persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction.

Young children should be supervised to ensure that they do not play

with the appliance.

1. After use, switch o󰀨 the compressed air and empty the hose.

2. The equipment must only be operated in an ambient temperature of 5

to 40°C. The hose must not be exposed to direct sunlight, as this can

result in damage to the hose over time.

3. Do not expose the equipment to rain. Never use the equipment in

damp or wet locations.

4. Disconnect the hose reel from the compressor after use.

5. Protect the hose from heat, oil and sharp edges.

6. Keep the hose retracted and wound up when not in use.

7. Do not release hose when it is retracting. The hose may whip about

and cause injury.

8. Ensure hose is locked before putting hose or connected tool down.

9. Secure hose reel to the wall according to instructions in the manual

before use.

WARNING! Refer to instruction manuals of all

independent tools/accessories connected to the air hose

and adhere to all safety warnings before use.

ONLINE MANUAL

Scan this QR Code with

your mobile device to take

you to the online manual.

9M RET RACT ABLE AIR HOSE REEL

Mounting To a Wall

Use the supplied screws to mount the hose reel to the wall. If

mounting to concrete, brick or masonry walls, use the supplied wall

plugs as well.

1. Mark and drill out 3 holes

spaced 65mm apart where

you wish to mount the hose

reel.

2. Attach the screws to the wall.

3. Slide holes in the bracket over

the screw heads and down to

lock hang the reel.

4. Swivel the reel out of the way and tighten the screws as necessary.

WARNING! ALWAYS SECURE RETRACTABLE AIR

HOSE REEL TO WALL AS DESCRIBED IN MANUAL

BEFORE USE.

1. Air Hose

2. Reel Stopper

3. Hose Reel

4. Wall Mount Bracket

5. Connecting Hose

RETRACTABLE AIR HOSE REEL

KNOW YOUR PRODUCT

1. INSTALLING THE HOSE REEL

SETUP & PREPARATION

65mm

9M RETRA CTABLE AIR H OS E REE L

1 2 3
