Side 1/12
SPECIFICATIONS
Input: 18V
No Load Speed: 800-1,400/min
Brush Diameter Max.: 115mm
Working Width Max.: 215mm
Max. Inlet Pressure: 87 psi (6 bar)
Max. Water Inlet Temp.: 35 C°
Noise Rating: 94.6dB (A)
IP Rating: IPX0
Tool Weight: 4.1kg
STANDARD EQUIPMENT
Surface Brush
SURFACE
BRUSH
INSTRUCTION MANUAL
ozito.com.au
Additional Handle
Soft 2-Piece Nylon Brush & Cover
Hose Clip, Water Control Valve
Medium 2-Piece Nylon Brush
PXSBS-018
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofce) 25 Fox Drive, Dandenong South, Victoria, Australia 3175.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
0321
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other
than that specied on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way
• Professional, industrial or high frequency use.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty Warranty excludes consumable parts, for example: and included
accessories.
KNOW YOUR PRODUCT SETUP & PREPARATION
1. ASSEMBLY
1. Water Inlet Connector
2. Motor Housing
3. Hose Clip
4. Telescopic Shaft
5. Additional Handle
6. Speed Controller
7. Rear Handle
8. Battery Seating
9. On/Off Trigger
10. Forward/Reverse Switch
11. Knob
12. Nylon Brush
13. Brush Cover
14. Splash Guard
15. Shaft Collar
SURFACE BRUSH
1234567
8
BATTERY & CHARGER
This tool is compatible with all battery and chargers from the Ozito
Power X Change Range.
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
10
11
9
WARNING!: ENSURE THE TOOL IS SWITCHED
OFF AND THE BATTERY DISCONNECTED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
Fitting the Additional Handle
For transport reasons the Main Handle is at 90 to the brush housing. To °
ensure that you have a comfortable working position, the main handle must
be aligned with the brush housing and the length of the Telescopic Shaft can
be adjusted.
1. Unscrew the two knobs on the
handle and separate the handle
from the bracket.
2. Place the top half in position and
secure in place with the bracket
on the underside and the two
knobs.
3. Tighten the two knobs to hold the
additional handle in position.
Note: To adjust the position, simple loosen the two knobs sufciently to
allow handle adjustment into the desired position, then tighten the two knobs
to secure in place.
1. Turn the Lock Nut anti-clockwise
to loosen and turn the Main
Handle 90 into alignment with °
the brush housing.
2. To change the working height,
extended the Telescopic Shaft
to the desired height and then
retighten the Lock Nut by turning
it clockwise.
12 13 14 15
Adjusting the Working Height
