Side 1/2
5/8Ah
18V LI-ION
ULTRA
PERFORMANCE
MULTI-AH
Before using the charger or battery read all instructions and cautionary markings on the charger, battery pack and the
product using the battery pack. Do not lose these safety instructions.
Battery Warnings
1. The battery pack is not fully charged out of the carton. First read the safety instructions and then follow the charging
notes and procedures.
2. For optimum battery performance avoid low discharge cycles. Charge the battery pack frequently.
3. Use and store the battery pack in dry conditions with low humidity between 0-50°C, ideally at 15°C. Avoid exposing
battery pack and charger to direct sunlight.
4. Do not keep battery pack in places where temperatures are liable to reach over 50°C, such as in a car, metal shed or
similar that is in direct sunlight.
5. Do not ignite the battery pack or expose it to re. There is a risk of explosion!
6. Do not exhaustively discharge batteries. Exhaustive discharge will damage the battery cells. The most common
cause of exhaustive discharge is long-term storage and continued use of low-charge batteries. Always store the
battery with some charge. Charge the batteries every 2-3 months to restore charge. Stop working as soon as the
performance of the battery falls noticeably or the electronic protection system triggers.
7. Protect batteries and the tool from overloads. Overloads will quickly result in overheating and cell damage inside
the battery housing without this overheating being apparent externally.
8. Avoid damage and shocks. Do not use batteries which have been dropped from a height of more than one meter or
strong external impact, even if the housing of the battery pack appears to be undamaged. The battery cells inside
the battery may have suffered serious damage. 
9. If the battery pack suffers overloading and overheating, the integrated protective cut-off will switch off the equip-
ment. Do not press the ON/OFF switch on the tool if the protective cut-off has actuated. This may damage the
battery pack. Allow the battery to cool to room temperature before use.
10. Use only original battery packs. The use of other batteries may result in injuries, explosion and a re risk.
11. Protect your rechargeable battery against moisture, rain and high humidity. Moisture, rain and high humidity can
cause dangerous cell damage. Never charge or use batteries which have been exposed to moisture, rain or high
humidity.
12. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack is damaged, do not
use the battery.
13. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or
other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a re.
14. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If accidental contact occurs, ush
with water and seek medical help immediately. Liquid ejected from the battery may cause irritation or burns.
15. Do not use a battery pack or tool that is damaged or modied. Damaged or modied batteries may exhibit unpredict-
able behaviour resulting in re, explosion or risk of injury.
16. Do not expose a battery pack or tool to re or excessive temperature. Exposure to re or temperature above 130°C
may cause explosion.
17. Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer.
18. Do not disassemble Battery. This may result in a risk of electric shock, electrocution or re.
Charger Warnings
19. Please check the data marked on the rating plate of the battery charger. Ensure to only connect the battery charger
to a power supply with the voltage marked on the rating plate.
20. Protect the battery charger and its cable from damage and sharp edges. Have damaged cables repaired by an
authorised service agent before use.
21. Keep the battery charger, batteries and the cordless tool out of children’s reach.
22. Do not use damaged battery chargers.
23. Do not use the supplied battery charger to charge other cordless tools. Only charge Ozito PXC rechargeable batteries
with an Ozito PXC Charger.
24. The battery pack may become warm during use. Allow the battery pack to cool to room temperature before
commencing with the charging.
25. Do not over-charge batteries. Do not exceed the maximum charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or partly charged battery pack will result in over-charging and
cell damage. Do not leave fully charged batteries in the charger. Overcharging batteries may result in a risk of re.
26. Charge the battery pack in dry conditions with low humidity between 10-40°C. Avoid exposing battery pack and
charger to direct sunlight.
27. Do not use batteries which have suffered deformation during the charging process or shows any other signs of
abnormalities including, excessive curvature of the housing, gassing, hissing or cracking.
28. Never fully discharge the battery pack. A complete discharge of the battery pack will lead to premature ageing of
the battery cells.
29. Never charge the batteries unsupervised.
30. Do not cover or place any object on top of the charger, place the charger away from heat sources.
31. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the
charger.
32. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or
stress.
33. An extension cord should not be used unless necessary. Use of an improper extension cord could result in the risk of
re, electric shock or electrocution.
34. Do not disassemble charger. This may result in a risk of electric shock, electrocution or re.
35. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning. Removing the
battery pack will not reduce this risk.
36. Do not use the cordless tool or the battery charger near vapours and inammable liquids.
37. Keep away from readily combustible material whilst charging.
BATTERY & CHARGER SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! When using electric tools basic safety precautions should always be followed to
reduce the risk of fire, electric shock and personal injury.
• Read the whole manual carefully and make sure you know how to switch the tool off
in an emergency, before operating the tool. Save these instructions and other documents
supplied with this tool for future reference.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do not play with the
appliance.
• Always remove the battery from the tool: WARNING!
- when the batteries are to be charged,
- when the tool is left unattended,
- when the tool is being checked, cleaned, or having maintenance work done,
- when the tool is to be stored,
- or if the tool vibrates abnormally.
• Do not combine different types of batteries or new and used batteries.
• Do not use modified or damaged batteries.
DESCRIPTION OF SYMBOLS
Watt Hour
Do not store or use battery in
temperatures exceeding 50 C°
Volts
Direct Current
Amp HourAh
Wh
V
Warning
Lithium Ion Battery
Do not put in the rubbish
Do not get battery wet
Recycle Battery
Do not incinerate
Regulatory Compliance
Mark (RCM)
Read Instruction Manual
Do not store battery when the charge
is low; store between 40-60%.
Do not expose to rain.
40-60%
0%
PXUBP-580
1. Digital Display
2. Battery Release Button
3. Output Selector
8Ah MAX.
BATTERY
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
Battery Capacity: 5.0 / 8.0Ah Li-ion
Power Consumption: 90 / 144Wh
Weight: 1.05kg
ozito.com.au
3
2
1
Power tools that are no longer usable should not be disposed
of with household waste but in an environmentally friendly
way. Please recycle where facilities exist. Check with your local
council authority for recycling advice.
Recycling packaging reduces the need for landll and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
CARING FOR THE ENVIRONMENT
BATTERY CHARGE LEVEL
1. Press the output selector. The battery charge
percentage and then the battery capacity in Ah
will appear on the digital display.
CHANGING THE OUTPUT
The battery is preset to 5.0Ah for shipping. Follow the steps below to change the output
to 8.0Ah.
1. Press and hold the display button for 6 seconds. Let go when the battery starts
counting. The battery will start counting up from ‘1’ to ‘9’.
2. Press the display button again when the
number reaches ‘8’.
NOTE: The battery will continue counting to ‘9’.
The selected output Ah value will appear on the
display once the count is completed.
3. To change the battery back to a 5.0Ah, repeat step
1, then press the battery button when the count up
reaches ‘5’ instead.
BATTERY PROTECTION SYSTEM
The tool is equipped with a battery protection system, which helps to ensure longevity
of the battery. The output power automatically cuts off during operation when the tool
and/or battery are placed under the following situations:
• When the tool is overloaded:
If this occurs, release the trigger switch and remove causes of overload, then pull
the switch trigger again to restart.
• When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the tool.
Note: The indicated capacity may be lower than the actual level during use or
immediately after using the tool.
WARRANTY
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are
entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under
this warranty, however, where you have suffered any additional direct loss as
a result of a defective product you may be able to claim such expenses by
contacting our customer service helpline above.
36 MONTH REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the original date
of purchase and is intended for DIY (Do It Yourself) use only. If a product is
defective it will be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
OZITO Australia/New Zealand (Head Ofce)
25 Fox Drive, Dandenong South, Victoria, Australia 3175.
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
PXUBP-580
1. OPERATION
CHARGING YOUR LITHIUM ION BATTERY
This battery has been shipped in a low charge condition, and requires charging prior to
use. Allow several cycles of charging and discharging (through use with a compatible
tool) for the battery to reach its optimum performance / runtime.
Only use the battery pack with Ozito PXC 18V cordless products.
This battery is compatible with chargers from the 18V Ozito PXC range available through
your local Bunnings Warehouse. Product availability may differ.
1. Insert the power plug of the charger into the mains socket outlet. The green LED
will begin to ash when properly connected to power supply.
2. Insert the battery pack into the battery charger.
3. Remove battery from the charger once fully charged. Disconnect the charger from
the power supply.
Note: The battery pack can become a little warm during the charging. This is normal.
If the battery pack fails to charge, check:
if there is voltage at the socket outlet
that the battery and charger are properly connected.
If the battery pack still fails to charge, please contact our customer service center.
1222
WARNING! DO NOT COVER OR PLACE ANY OBJECT ON
TOP OF THE CHARGER; PLACE THE CHARGER AWAY
FROM HEAT SOURCES.
WARNING! NEVER LEAVE THE BATTERIES CHARGING
UNSUPERVISED.

Produkt Specifikationer

Mærke: Ozito
Kategori: Ikke kategoriseret
Model: PXUBP-580

Har du brug for hjælp?

Hvis du har brug for hjælp til Ozito PXUBP-580 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret Ozito Manualer

Ozito

Ozito PXCG-080 Manual

29 Juli 2025
Ozito

Ozito PXGAR-500 Manual

29 Juli 2025
Ozito

Ozito PXSK-2518 Manual

22 Juni 2025
Ozito

Ozito PXBPS-1828 Manual

2 Juni 2025
Ozito

Ozito PXLEK-1840 Manual

5 Januar 2025
Ozito

Ozito PXBGSS-1815 Manual

10 December 2024
Ozito

Ozito PXBSPS-180 Manual

6 Oktober 2024
Ozito

Ozito SSH-240 Manual

6 Oktober 2024
Ozito

Ozito DMC-1000 Manual

20 September 2024
Ozito

Ozito PXBCSS-184 Manual

15 September 2024

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Kenmore

Kenmore SM2050 Manual

17 August 2025
Vulcan

Vulcan VBB1CF Manual

17 August 2025
MSW

MSW -WPD-PVDC4/2 Manual

17 August 2025
Kenmore

Kenmore DU1275 Manual

17 August 2025
YA-MAN

YA-MAN Bloom 5 Manual

17 August 2025
OSD Audio

OSD Audio NERO-CONTROL12 Manual

17 August 2025
Singercon

Singercon SIN-ALD-2000 Manual

17 August 2025
Vulcan

Vulcan VIB2 Manual

17 August 2025
Mars Gaming

Mars Gaming MNBC5 Manual

17 August 2025
Mars Gaming

Mars Gaming MNBC6 Manual

17 August 2025
