VQT4E90
Operating Instructions
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions carefully.
Please keep this manual for future reference.
• This Blu-ray Disc Player / HDD Recorder is for viewing and recording free to view channels
only. It does not receive pay TV or encrypted channels.
Blu-ray Disc™ Player / HDD Recorder
Model No. DMR-PWT520
DMR-PWT420
Region management information
BD-Video: This unit can play BD-Video discs
supporting the region code “B”.
DVD-Video:
This unit can play DVD-Video discs
supporting the region number “2”
or “ALL”.
e.g., e.g.,
35
2
Model number suffix “EB” denotes UK model.
Web Site: http://www.panasonic-europe.com
EB
VQT4E90
2
Unit
• To reduce the risk of fire, electric shock or
product damage,
- Do not expose this unit to rain, moisture,
dripping or splashing.
- Do not place objects filled with liquids, such as
vases, on this unit.
- Use only the recommended accessories.
- Do not remove covers.
- Do not repair this unit by yourself. Refer
servicing to qualified service personnel.
- Do not let metal objects fall inside this unit.
- Do not place heavy items on this unit.
AC mains lead
• To reduce the risk of fire, electric shock or
product damage,
- Ensure that the power supply voltage
corresponds to the voltage printed on this unit.
- Insert the mains plug fully into the socket
outlet.
- Do not pull, bend, or place heavy items on the
lead.
- Do not handle the plug with wet hands.
- Hold onto the mains plug body when
disconnecting the plug.
- Do not use a damaged mains plug or socket
outlet.
• Install this unit so that the AC mains lead can be
unplugged from the socket outlet immediately if
any problem occurs.
SD card
• Keep the Memory Card out of reach of children
to prevent swallowing.
Unit
• This unit utilizes a laser. Use of controls or
adjustments or performance of procedures other
than those specified herein may result in
hazardous radiation exposure.
• Do not place sources of naked flames, such as
lighted candles, on this unit.
• This unit may receive radio interference caused
by mobile telephones during use. If such
interference occurs, please increase separation
between this unit and the mobile telephone.
• This unit is intended for use in moderate
climates.
Placement
• Place this unit on an even surface.
• To reduce the risk of fire, electric shock or
product damage,
- Do not install or place this unit in a bookcase,
built-in cabinet or in another confined space.
Ensure this unit is well ventilated.
- Do not obstruct this unit’s ventilation openings
with newspapers, tablecloths, curtains, and
similar items.
- Do not expose this unit to direct sunlight, high
temperatures, high humidity, and excessive
vibration.
Batteries
• Danger of explosion if battery is incorrectly
replaced. Replace only with the type
recommended by the manufacturer.
• Mishandling of batteries can cause electrolyte
leakage and may cause a fire.
- Do not mix old and new batteries or different
types at the same time.
- Do not heat or expose to flame.
- Do not leave the battery(ies) in a car exposed
to direct sunlight for a long period of time with
doors and windows closed.
- Do not take apart or short circuit.
- Do not recharge alkaline or manganese batteries.
- Do not use batteries if the covering has been
peeled off.
- Remove batteries if you do not intend to use
the remote control for a long period of time.
Store in a cool, dark place.
• When disposing the batteries, please contact
your local authorities or dealer and ask for the
correct method of disposal.
Safety precautions
WARNING
CAUTION
VQT4E90 3
For your safety, please read the following text
carefully.
This appliance is supplied with a moulded three
pin mains plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please
ensure that the replacement fuse has a rating of
5-ampere and that it is approved by ASTA or BSI
to BS1362.
Check for the ASTA mark Ï or the BSI mark Ì
on the body of the fuse.
If the plug contains a removable fuse cover you
must ensure that it is refitted when the fuse is
replaced.
If you lose the fuse cover the plug must not be
used until a replacement cover is obtained.
A replacement fuse cover can be purchased from
your local dealer.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the
type of AC mains plug (figures A and B). Confirm
the AC mains plug fitted and follow the
instructions below.
Illustrations may differ from actual AC mains plug.
1.Open the fuse cover with a screwdriver.
2.Replace the fuse and close or attach the fuse
cover.
Please check and identify the supplied
accessories.
(Product numbers correct as of March 2012.
These may be subject to change.)
• Do not use AC mains lead with other equipment.
Caution for AC Mains
Lead
Fuse cover
Figure A Figure B
Figure A Figure B Fuse
(5 ampere)
Fuse
(5 ampere)
Supplied accessories
Remote control:
[PWT520] (N2QAYB000762)
[PWT420] (N2QAYB000763)
1 pc.
Batteries for remote control: 2 pcs.
AC mains lead (K2CT2YY00003):1 pc.
RF coaxial cable (K1TWACC00003):1 pc.
Indemnity concerning recorded content
Panasonic does not accept any responsibility for
damages directly or indirectly due to any type of
problems that result in loss of recording or edited
content (data), and does not guarantee any
content if recording or editing does not work
properly. Likewise, the above also applies in a
case where any type of repair is made to the unit
(including any other non-HDD related
component).
Restriction on use of unauthorized copied
content
This unit adopts the following technology for
copyright protection.
Cinavia Notice
This product uses Cinavia technology to limit
the use of unauthorized copies of some
commercially-produced film and videos and
their soundtracks. When a prohibited use of
an unauthorized copy is detected, a message
will be displayed and playback or copying will
be interrupted. More information about
Cinavia technology is provided at the Cinavia
Online Consumer Information Center at
http://www.cinavia.com. To request additional
information about Cinavia by mail, send a
postcard with your mailing address to:
Cinavia Consumer Information Center, P.O.
Box 86851, San Diego, CA, 92138, USA.
VQT4E90
4
Table of contents
Safety precautions . . . . . . . . . . . . . . . . . . . . . .2
Caution for AC Mains Lead. . . . . . . . . . . . . . . .3
Supplied accessories . . . . . . . . . . . . . . . . . . . .3
Getting started
HDD and media information . . . . . . . . . . . . . . .6
- Recordable/playable contents . . . . . . . . . . . . . . . . .6
- Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Unit care . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Control reference guide . . . . . . . . . . . . . . . . .11
Connection . . . . . . . . . . . . . . . . . . . . . . . . . . .13
- Basic connections . . . . . . . . . . . . . . . . . . . . . . .13
- Amplifier/receiver connections . . . . . . . . . . . . . . .14
- Network connection . . . . . . . . . . . . . . . . . . . . . .16
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
- TV operation buttons . . . . . . . . . . . . . . . . . . . . .18
- Easy Setting . . . . . . . . . . . . . . . . . . . . . . . . . . .19
- Easy Network Setting . . . . . . . . . . . . . . . . . . . . .21
FUNCTION MENU screen . . . . . . . . . . . . . . .23
Watching broadcasts
Watching broadcasts . . . . . . . . . . . . . . . . . . .24
- Using Channel List . . . . . . . . . . . . . . . . . . . . . . .24
- Using TV Guide system. . . . . . . . . . . . . . . . . . . .25
- Using channel information . . . . . . . . . . . . . . . . . .25
- Operations while watching broadcast . . . . . . . . . . .26
- REWIND LIVE TV/PAUSE LIVE TV . . . . . . . . . . . .27
Recording
Recording TV programmes. . . . . . . . . . . . . . .28
- Operation during Recording . . . . . . . . . . . . . . . . .29
Timer recording. . . . . . . . . . . . . . . . . . . . . . . .30
- Various functions with Freeview . . . . . . . . . . . . . .32
- Manually programming timer recording . . . . . . . . . .33
- Timer recording options. . . . . . . . . . . . . . . . . . . .33
- Timer recording from channel information . . . . . . . .34
- Notes on timer recording . . . . . . . . . . . . . . . . . . .34
- To confirm and edit a timer programme . . . . . . . . . .35
Playing back video
Playing titles on the HDD . . . . . . . . . . . . . . . .36
- DIRECT NAVIGATOR (VIDEO) screen . . . . . . . . . .36
Playing titles on the media . . . . . . . . . . . . . . .39
- Notes for BD-Live discs . . . . . . . . . . . . . . . . . . . .40
Operation during play . . . . . . . . . . . . . . . . . . .41
- General operations. . . . . . . . . . . . . . . . . . . . . . .41
- 3D video playback . . . . . . . . . . . . . . . . . . . . . . .43
Editing video
Deleting recorded titles . . . . . . . . . . . . . . . . . . 45
Editing recorded titles . . . . . . . . . . . . . . . . . . . 46
Copying video
Copying titles . . . . . . . . . . . . . . . . . . . . . . . . . 49
Playing photos . . . . . . . . . . . . . . . . . . . . . . . .50
- DIRECT NAVIGATOR (PHOTO) screen . . . . . . . . .50
- Photo play option. . . . . . . . . . . . . . . . . . . . . . . . 51
- Slideshow Settings. . . . . . . . . . . . . . . . . . . . . . . 51
Editing photos . . . . . . . . . . . . . . . . . . . . . . . . .52
Copying photos. . . . . . . . . . . . . . . . . . . . . . . .53
- Selecting and copying the photos . . . . . . . . . . . . .53
- Copying automatically. . . . . . . . . . . . . . . . . . . . .53
Music
Playing music . . . . . . . . . . . . . . . . . . . . . . . . . 54
- Copying music to HDD . . . . . . . . . . . . . . . . . . . .54
- Playing music recorded on HDD . . . . . . . . . . . . . . 55
- Operations during music play . . . . . . . . . . . . . . . .56
Editing music/playlist . . . . . . . . . . . . . . . . . . .57
With Other Equipment
Copying the HD Video or the SD Video . . . . .58
- Copying HD Video (AVCHD format) . . . . . . . . . . . .58
- Copying SD Video (MPEG2 format) . . . . . . . . . . . . 59
Convenient functions
Registering the external HDD (USB HDD) . . .60
- Connecting the USB HDD . . . . . . . . . . . . . . . . . .60
- Disconnecting the USB HDD . . . . . . . . . . . . . . . . 60
- Registering the USB HDD . . . . . . . . . . . . . . . . . .61
Format SD card . . . . . . . . . . . . . . . . . . . . . . .62
Smart Home Networking (DLNA) . . . . . . . . . .63
- Using this unit as Server . . . . . . . . . . . . . . . . . . .63
- Using this unit as Client. . . . . . . . . . . . . . . . . . . .64
- Using this unit as Media Renderer . . . . . . . . . . . . . 65
VIERA Connect (Enjoying Internet Service)
. . .66
- To enjoy video communication (e.g., SkypeTM ) . . . . .66
VIERA Link functions . . . . . . . . . . . . . . . . . . .67
Playback menu . . . . . . . . . . . . . . . . . . . . . . . . 68
VQT4E90 5
Getting started
Watching broadcasts
Recording
Playing back video
Editing video
Copying video
Music
With Other Equipment
Convenient functions
Troubleshooting
Reference
Changing the unit’s settings (Setup) . . . . . . . 70
- Common procedures. . . . . . . . . . . . . . . . . . . . . 70
- Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
- HDD / Disc / USB HDD . . . . . . . . . . . . . . . . . . . 75
- Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
- Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
- Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
- Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
- Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
- Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
- Language code list . . . . . . . . . . . . . . . . . . . . . . 83
Software (Firmware) Update . . . . . . . . . . . . . 84
Other operations . . . . . . . . . . . . . . . . . . . . . . 85
- Entering text . . . . . . . . . . . . . . . . . . . . . . . . . . 85
- Switching the aspect ratio of the screen . . . . . . . . . 85
- HOLD function . . . . . . . . . . . . . . . . . . . . . . . . . 85
Troubleshooting
Troubleshooting guide. . . . . . . . . . . . . . . . . . 86
- General operation. . . . . . . . . . . . . . . . . . . . . . . 86
- Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
- TV screen and video . . . . . . . . . . . . . . . . . . . . . 87
- Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
- Recording, timer recording and copying . . . . . . . . . 89
- Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
- Edit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
- Photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
- USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
- TV Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
- Broadcast . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
- VIERA Link . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
- Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
- Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
- Messages on the unit’s display . . . . . . . . . . . . . . 92
- When you experience problems
with Easy Network Setting . . . . . . . . . . . . . . . . . 94
Reference
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 96
Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
About descriptions in these operating
instructions
• These operating instructions are applicable to models
DMR-PWT520 and DMR-PWT420. The illustrations in
these Operating Instructions show images of
DMR-PWT520 unless otherwise indicated.
• [PWT520] :indicates features applicable to
DMR-PWT520 only.
• [PWT420] :indicates features applicable to
DMR-PWT420 only.
• Pages to be referred to are indicated as “>±±”.
VQT4E90
6
Getting started
HDD and media information
Getting started
(–: Impossible)
Recordable/playable contents
Media type Standard symbol Playable contents Recordable
contents
Built-in hard disk drive
(HDD) [HDD]
• Video
• AVCHD/AVCHD 3D
• JPEG
• MPO (3D photo)
• MP3
External HDD (>
>
>
>> 60)§
§
§
§§1, 2 [USB_HDD]
• Video
BD-Video
[BD-V]
• Video
–
BD-RE
[BD-RE]
• Video
• AVCHD/AVCHD 3D
• JPEG
• MPO (3D photo)
–
BD-R
[BD-R]
• Video
• AVCHD/AVCHD 3D §3
• DivX®
• MKV
–
DVD-Video§
§
§
§§4
[DVD-V]
• Video
–
DVD-R
DVD-R DL
[DVD-R]
• Video
• DivX®
• JPEG
• MP3
• AVCHD§3
• MKV
• MPO –
DVD-RW
[DVD-RW]
• Video
• AVCHD§3–
+R/+R DL [+R] • Video
• AVCHD§3–
+RW [+RW] • Video
• AVCHD§3–
Getting started
VQT4E90 7
(–: Impossible)
§1Referred to as “USB HDD” in these operating instructions.
§2It cannot be recorded directly. (Only compatible with copying from the built-in HDD)
§3Recorded with AVCHD compatible devices (Panasonic video camera, etc.). It may not be able to
play back depending on the device.
§4Includes finalised DVD-R, DVD-R DL, DVD-RW, +R and +R DL.
§5It cannot be played back directly from the USB memory. Playback is possible by copying to the
HDD. (>58)
§6Some SD Video (MPEG2) contents recorded by a video camera, etc., can be played back only after
copying to HDD. Other MPEG2 contents will not be played back. (>59)
§7Some SD Video (MPEG2) contents recorded by a video camera, etc., can be played back only after
copying to HDD. Other MPEG2 contents can be played back directly. (>59)
• [USB] Video images of the copyright-protected DivX contents stored on USB device can be output only through the HDMI
output terminal.
• The producer of the disc can control how discs are played. So you may not always be able to control play as described in
these operating instructions. Read the disc’s instructions carefully.
• With certain recording states and folder structures, the play order may differ or playback may not be possible.
When this unit works as a DLNA client (>64), following contents are playable.
§ Only when the server is another DIGA. (>63)
• Depending on the server, the contents other than stated above can be played back.
Media type Standard symbol Playable contents Recordable
contents
Audio CD (CD-DA)
[CD]
• Music
–
CD
(including CD-R/RW)
• DivX®
• JPEG
• MKV
• MP3 –
• MPO (3D photo)
SD Cards
[SD]
• AVCHD/AVCHD 3D §3• JPEG
• MPO (3D photo)
• MP4
• JPEG
• MPEG2§6
• MPO (3D photo)
USB memories [USB]
• AVCHD/AVCHD 3D §3, 5
–
• DivX®
• JPEG
• MP3
• MP4
• MPEG2§7
• MKV
• MPO (3D photo)
Playable contents on a DLNA server
• Recorded video§ • AVCHD§ • MP4 • MPEG2
• JPEG • MPO (3D photo) • MP3 • FLAC
Getting started
VQT4E90 9
• This unit does not guarantee connection with all
USB devices.
• FAT12, FAT16 and FAT32 file systems are
supported.
• This unit supports USB 2.0 High Speed.
• Although this unit can use USB 3.0 devices as
USB 2.0 devices, in certain cases USB 3.0
devices cannot be used due to differing
connector shape, larger current ratings, etc.
(Use of USB 2.0 devices is recommended.)
• USB memories support DivX and MKV files less than 4 GB.
• [PWT520] When using Communication Camera (TY-CC20W
or TY-CC10W), connect it to the rear terminal of this unit.
(>66)
• [PWT420] When using Wireless LAN Adaptor (DY-WL5),
connect it to the rear terminal of this unit. (>17)
• Compatible SD card
- SD Memory Card
(from 8 MB to 2 GB, FAT12 and FAT16
formats)
- SDHC Memory Card
(from 4 GB to 32 GB, FAT32 format)
- SDXC Memory Card
(48 GB, 64 GB, exFAT format)
• Using miniSD card or microSD card
Mini-type and micro-type cards can also be
used, but must be used with adaptor cards
(optional).
To format an SD card
Refer to “Format SD card”. (>62)
• Usable memory is slightly less than the card capacity.
• If the SD card is formatted on other equipment, the time
necessary for recording may be longer or the card may not
be able to be used on this unit. In these cases, format the
card on this unit.
• SDHC Memory Cards and SDXC Memory Cards can be
used in equipment that is compatible with the appropriate
cards. (SDHC Memory Cards can also be used in
equipment compatible with SDXC Memory Cards)
• Do not touch the recorded surface of the discs
or the terminal surface of the SD cards.
• If there is dirt or condensation on the disc, wipe
with a damp cloth and then wipe dry.
• Do not attach labels or stickers to discs.
• Do not use disc cleaning sprays, benzine,
thinner, static electricity prevention liquids or
any other solvent.
• Do not use ballpoint pens or other hard writing
implements, when writing on the label side of
the disc.
• Do not drop, stack, or impact discs.
• Do not place objects on discs.
• Do not use the following discs:
- Discs with exposed adhesive from removed
stickers or labels (rental discs, etc.).
- Discs that are badly warped or cracked.
- Irregularly shaped discs.
• Do not expose the terminals of the SD card to
water, garbage or other strange things.
• Do not place in the following areas:
- In hot places, such as under the direct
sunlight.
- In very dusty or humid areas.
- Locations susceptible to significant difference
in temperature (condensation can occur).
- Where static electricity or electromagnetic
waves occur.
Notes for the USB devices
Notes for the SD cards
Media handling
DO
DO NOT
DO DO NOT
DO NOT
Produkt Specifikationer
| Mærke: | Panasonic |
| Kategori: | Blu-ray afspiller |
| Model: | DMR-PWT420 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Panasonic DMR-PWT420 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Blu-ray afspiller Panasonic Manualer
27 Juli 2025
26 Juli 2025
26 Juli 2025
26 Juli 2025
26 Juli 2025
21 December 2024
10 December 2024
29 Oktober 2024
31 August 2024
26 August 2024
Blu-ray afspiller Manualer
- Pyle
- NAD
- Laser
- Magnavox
- Grundig
- Sherwood
- Nedis
- Sharp
- Tascam
- Verbatim
- Asus
- Samsung
- Yamaha
- Onkyo
- Hitachi
Nyeste Blu-ray afspiller Manualer
10 August 2025
10 August 2025
6 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
