Installation Instruction
TK510CS/FS/FW
Trim kit
24”cabinet
(596mm)
TK510CS
TK510FS
TK510FW
Contents
Attention ......................................................................................................................................... P2-7
Step1. Unpacking list ..........................................................................................................................P8
Step2. Feature diagram ......................................................................................................................P9
Step3. Cabinet Preparation ........................................................................................................ P10-12
Step4. Microwave Oven Installation ........................................................................................... P13-14
Step5. Cabinet Installation.......................................................................................................... P15-16
Step6. Finishing Installation........................................................................................................ P17-19
IP3460_F03139P60QP_14_110331.indd 1IP3460_F03139P60QP_14_110331.indd 1 2011-3-31 11:38:462011-3-31 11:38:46
2
en
1. This trim kit can be installed into a cabinet.
The cabinet opening must have the following
internal dimensions as shown in fig 1, p 10-
12.
A vent is required at the rear of the cabinet.
It should travel the full height of the cabinet
and the cabinet should not be obstructed.
Minimum dimension of vent: 45 mm x 562 mm
(fig 1, p 10-12).
MINIMUM INSTALLATION HEIGHT 850 MM.
2. Electrical Connections The appliance is
supplied with a mains plug attached and
should only be connected into an earthed
socket that has been installed according to
the relevant safety regulations.
If the plug is no longer accessible after the
appliance has been built into the cabinet, a
dual pole isolator must be installed to conform
to the relevant safety standards.
3. It is essential that the cabinet is fixed to the
wall for stability. The shelf must be able to
support a weight of 30 kg.
4. If the microwave oven is to be removed from
the kitchen cabinet and used free standing,
the built in parts must be removed, and the
oven returned to its original condition. Keep
these installation instructions for future
reference so the installation process can be
reversed.
TAKE CARE NOT TO KINK OR TRAP THE
MICROWAVE ELECTRICAL CABLE.
The diagram may vary from the actual unit
and is only for your reference.
zh
1. 此專用框架可安裝在開放式橱櫃內。橱櫃內部
尺寸請參考第10-12頁圖1所示。
橱櫃後必須預留有足够高度的通風空隙，幷確
保橱櫃不被阻塞。最小通風尺寸爲45 mm x 562
mm（第10-12頁圖1）。
最小安裝高度爲850 mm。
2. 綫路 本設備配有一個接地插頭，必須確保插在
符合相應安全標準的插座上。
如果當微波爐安裝在橱櫃內後，插頭不易接近
原有插座時，可另行安裝符合相應安全標準的
插座。
3. 確保有足够穩定性的開放式橱櫃，幷且能支撑
30千克的載重。
4. 如果要把微波爐從橱櫃內取出置放在桌上使
用，必須取去專用框架部件使微波爐恢復原來
的狀態。請妥善保存此安裝說明書以備查閱。
不可扭曲或纏繞電綫。
圖標與實際産品可能有不同，僅供參考。
IP3460_F03139P60QP_14_110331.indd Sec1:2IP3460_F03139P60QP_14_110331.indd Sec1:2 2011-3-31 11:38:462011-3-31 11:38:46
