Side 1/69

*Actual resolution:

3840 × 2160p

Operating Instructions

Functional Manual

UHD LCD Display For business use

Model No. TH-98SQ1W

98-inch model

TH-86SQ1W

86-inch model

TH-65SQ1W

65-inch model

TH-55SQ1W

55-inch model

TH-49SQ1W

49-inch model

English Please read these instructions before operating your set

and retain them for future reference.

DPQP1288ZA/X1

TP0819TS0 -PB

English

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that

you will have many years of enjoyment from your new LCD

Display.

To obtain maximum benefit from your set, please read these

Instructions before making any adjustments, and retain them

for future reference.

Retain your purchase receipt also, and note down the model

number and serial number of your set in the space provided

on the rear cover of these instructions.

Visit our Panasonic Web Site

https://panasonic.net/cns/prodisplays/

Table of Contents

Before use

● Illustrations and screens in this Operating Instructions

are images for illustration purposes, and may be

different from the actual ones.

● Descriptive illustrations in this Operating Instructions

are created mainly based on the 98-inch model.

Important Safety Instructions 4

..........................

FCC STATEMENT 5

..............................................

Important Safety Notice 6

...................................

Safety Precautions 8

...........................................

Precautions for use ........................................

Accessories 13

....................................................

Accessories Supply 13 ··········································

Remote Control Batteries 14 ··································

Attaching the USB Memory Cover 14 ·······················

Attaching the Function Board 15 ·····························

Cautions when moving 17

..................................

Eyebolt ........................................................... 18

Connections 19

....................................................

AC cord connection and fixing / Cable fixing 19 ··········

Video equipment connection 21

······························

Before connecting 22 ············································

HDMI 1 and HDMI 2 terminals connection 22

·············

DVI-D IN terminal connection 23

·····························

PC IN terminal connection 24

·································

DisplayPort IN / DisplayPort OUT terminal connection

···· 25

DIGITAL LINK terminal connection 27 ······················

SERIAL IN terminal connection 28

···························

IR IN / IR OUT terminal connection 29

······················

AUDIO OUT terminal connection 30

·························

USB terminal connection 30 ···································

Speaker terminal connection 31 ······························

Identifying Controls 32

........................................

Display 32

··························································

Remote Control Transmitter

·······························

Basic Controls 35

................................................

Selecting the input signal 37

···································

RECALL························································· 38

Volume Adjustment ·········································· 38

Sound mute On / Off 38

·········································

OFF TIMER

····················································

ASPECT Controls 40

...........................................

Digital ZOOM 42

...................................................

On-Screen Menu Displays 43

.............................

Adjusting Position 45

..........................................

Auto setup 45

······················································

Produkt Specifikationer

Mærke:	Panasonic
Kategori:	Skærm
Model:	TH-65SQ1W
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50/60 Hz
Bredde:	1458 mm
Dybde:	69 mm
Højde:	836 mm
Vægt:	36000 g
Produktfarve:	Sort
Pakkevægt:	47000 g
Pakkedybde:	248 mm
Pakkebredde:	1642 mm
Pakkehøjde:	1037 mm
Skærm diagonal:	65 "
Skærmopløsning:	3840 x 2160 pixel
Berøringsskærm:	Ingen
USB-port:	Ja
HD-type:	4K Ultra HD
Skærmteknologi:	IPS
Naturligt aspektforhold:	16:9
Skærmens lysstyrke:	500 cd/m²
Responstid:	8 ms
Synsvinkel, horisontal:	178 °
Synsvinkel, vertikal:	178 °
Skærm diagonal (metrisk):	163.8 cm
LED-baggrundsbelysning type:	Edge-LED
Indbyggede højttaler(e):	Ja
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Relativ luftfugtighed ved opbevaring (H-H):	20 - 80 %
Udgangseffekt (RMS):	20 W
Antal HDMI-porte:	2
HDCP:	Ja
DVI-port:	Ja
Ethernet LAN-porte (RJ-45):	2
Ethernet LAN:	Ja
VESA montering:	Ja
Panel montering grænseflade:	400 x 400 mm
Strømforbrug (standby):	0.5 W
Strømforbrug (typisk):	320 W
Driftstemperatur (T-T):	0 - 40 °C
Ethernet LAN-datahastigheder:	10,100 Mbit/s
Strømforbrug (slukket):	0.3 W
Kabler inkluderet:	Vekselstrøm
Batterier inkluderet:	Ja
Energiforbrug (SDR) pr. 1000 timer:	175 kWh
Fjernbetjening inkluderet:	Ja
Energieffektivitetsklasse (SDR):	G
Energiforbrug (HDR) pr. 1000 timer:	- kWh
Energieffektivitetsskala:	A til G
Monteringstype:	Væg
Antal indbyggede højttalere:	2
Understøttet placering:	Indendørs
Antal USB-porte:	2
Formål:	Universel
Vis antal farver:	1.073 milliarder farver
Lyd (L, R) indgang:	2
Kontrastforhold (typisk):	1100:1
Kontrastforhold (dynamisk):	50000:1
Antal DisplayPorts:	2
Lyd (L, R) udgang:	1
Aktiv skærmområde (B x H):	1428.4 x 803.5 mm
Produktdesign:	Digital fladpaneldisplay
VGA (D-Sub) indgangsporte:	1
HDCP-version:	2.2
Fjernbetjening (IR) indgang:	1
Fjernbetjening (IR) udgang:	1
Panel levetid:	50000 t
Driftstimer (timer/dage):	24/7
Antal HDMI-indgangsporte:	2
RS-232C:	Ja
Multi-display understøttes:	Ja
Antal DVI-D-porte:	1
Facet bredde (bund):	15.3 mm
Facet bredde (øverste):	11.7 mm
Orientering:	Horisontal/vertikal
Facet bredde (side):	12.2 mm
DisplayPorts indgang:	1
DisplayPorts udgang:	1
Antal højttalerudgange:	2
