INSTALLATION INSTRUCTIONS

V00029MX_08

Page 1 of 16

PATCHRUNNER

2 Vertical Managers and Racks

Part Number(s): See Sheet 2

Part Numbers and Part Contents.....................................................................................................2

Door Removal..................................................................................................................................3

Installation of Vertical Managers to Racks.......................................................................................4

Door Installation...............................................................................................................................5

Finger Removal and Replacement..................................................................................................7

End Panel Installation......................................................................................................................8

Waterfall Installation.......................................................................................................................11

Other Compatible Accessories.......................................................................................................13

Table of Contents

Description Page

For Technical Support: www.panduit.com

INSTALLATION INSTRUCTIONS

V00029MX_08

Page 2 of 16

PATCHRUNNER

2 Vertical Cable Managers may be installed with either side facing forward.

PART CONTENTS

(1) PATCHRUNNER

2 Vertical Cable Manager with (1) door per side

(8) M10 Serrated Flange Bolts

(8) M10 Serrated Flange Nuts

Produkt Specifikationer

Mærke:	Panduit
Kategori:	Ikke kategoriseret
Model:	AR4P
Dimensioner (BxDxH):	515.9 x 1066.8 x 213.9 mm
Materiale:	Stål
Stativ-montering:	Ja
Rammetype:	Åben ramme
