PRODUCT SPECIFICATION camera solutions
C3468 / REVISED 10-4-10
International Standards
Organization Registered Firm;
ISO 9001 Quality System
Spectra® IV IP Series Network Dome System
H.264, DIGITAL PAN/TILT/ZOOM HIGH-SPEED DOME
Product Features
•Ability to Control and Monitor Video Over IP Networks
•Simultaneous IP and Analog Video and Control
•H.264, MPEG-4, and MJPEG Compression
•Supported Protocols: TCP/IP, UDP/IP (Unicast, Multicast IGMP), UPnP,
DNS, DHCP, RTP, RTSP, NTP, IPv4, SNMP, QoS, HTTP, HTTPS, LDAP
(client), SSH, SSL, SMTP, FTP, mDNS (Bonjour ®), and 802.1x (EAP)
•Multilevel Password Protection
•3 Autofocus, High Resolution Integrated Camera/Optics Packages
•Horizontal Zone and Window Blanking
•Sensitivity Down to 0.00015 lux PAL (35X Models)
•On-Screen Compass and Tilt Display
•Up to 2 Simultaneous Video Streams
•Web Viewing, up to 16 Cameras Simultaneously
•Open IP Standards
•Bidirectional Full-Duplex Audio
Spectra® IV IP dome systems incorporate all of the features and
functions of Spectra IV (including analog), while allowing you to
control and monitor video over an IP network from virtually anywhere
in the world. Spectra IV IP is a high-speed dome with a built-in
100Base-TX network interface for live streaming to any network
application.
Spectra IV IP supports two simultaneous video streams. The two
streams can be compressed in MJPEG, MPEG-4, and H.264 formats
across several resolution configurations. The streams can be
configured in a variety of frame rates, bit rates, and group of pictures
(GOP) structures for additional bandwidth administration. The H.264
compression video files are up to 20 times smaller than MJPEG,
making network video storage more affordable.
Spectra IV IP allows you to view and control analog video while
viewing, recording, and controlling network IP video. There is no need
to abandon your current analog infrastructure if you are making the
move to network video as a recording solution. Continue to monitor
and control video in the analog domain while recording video in the
network domain, and let Spectra IV IP’s professional compression
method do the work for you without the need for external encoders.
Spectra IV IP dome system consists of a back box, a dome drive, and
a lower dome. These three system components are interchangeable
with other Spectra IV IP dome systems, making retrofitting and
application adjustments simple.
Spectra IV IP features several back box options. All back boxes
feature built-in memory, which can be used to store camera and
location-specific dome settings, including labels, presets, patterns,
and zones.
All cameras in Spectra IV IP dome drives feature an EXview HAD™
imager for increased sensitivity and LowLight™ technology allowing
the cameras to compensate for scenes where minimal light is present.
Both the 27X and the 35X cameras feature built-in motion detection
and advanced 128X wide dynamic range (WDR) that enables the
system to compensate for scenes where dramatic contrasts in lighting
are present. The 35X day/night camera’s electronic image
stabilization digitally reduces blurring of the camera image due to
vibration caused by external sources, such as wind and traffic.
Web Interface
Spectra IV IP uses a standard Web browser for powerful remote
setup and administration. Up to 16 cameras can be viewed on the
same network.
Network protocols such as Secure Sockets Layer (SSL) configuration
for security certificates, Secure Shell (SSH) for remote logon, and
Quality of Service (QoS) for priority or guarantee data flow can be
managed using a Web browser.
Systemization
Spectra IV IP easily connects to Pelco IP and hybrid systems such as
Endura® version 1.5 (or later), MPEG-4; Endura version 2.0 (or later),
H.264; Digital Sentry® version 4.2 (or later); DX8100 version 2.0 (or
later); and DVR5100 version 1.5.4 (or later). The camera also features
open architecture connectivity to third-party software. Pelco offers an
application programming interface (API) for interfacing to Pelco’s
network cameras.
TECHNICAL SPECIFICATIONS
CAMERA/OPTICS
Day/Night (35X) Day/Night (27X) Day/Night (23X)
Signal Format NTSC (DD4CBW35)
PAL (DD4CBW35-X)
NTSC (DD427)
PAL (DD427-X)
NTSC (DD423)
PAL (DD423-X)
Scanning System Interlace/Progressive selectable Interlace/Progressive selectable 2:1 Interlace
Image Sensor
Effective Pixels
NTSC
PAL
1/4-inch EXview HAD™
768 (H) X 494 (V)
752 (H) X 582 (V)
1/4-inch EXview HAD
768 (H) X 494 (V)
752 (H) X 582 (V)
1/4-inch EXview HAD
768 (H) X 494 (V)
752 (H) X 582 (V)
Horizontal Resolution
NTSC
PAL
>540 TV Lines
>540 TV Lines
>540 TV Lines
>540 TV Lines
540 TV Lines
540 TV Lines
Lens f/1.4 (focal length, 3.4 ~ 119 mm) f/1.4 (focal length, 3.4 ~ 91.8 mm) f/1.6 (focal length, 3.6 ~ 82.8 mm)
Zoom 35X optical, 12X digital 27X optical, 12X digital 23X optical, 12X digital
Zoom Speed (optical range) 3.2/4.6/6.6 seconds 3.2/4.6/6.6 seconds 2.9/4.2/5.8 seconds
Horizontal
Angle of view
Focus
55.8° at 3.4 mm wide zoom;
1.7° at 119 mm telephoto zoom
Automatic with manual override
55.8° at 3.4 mm wide zoom;
2.3° at 91.8 mm telephoto zoom
Automatic with manual override
54° at 3.6 mm wide zoom;
2.5° at 82.8 mm telephoto zoom
Automatic with manual override
Maximum Sensitivity at 35 IRE
NTSC/EIA
PAL/CCIR
0.55 lux at 1/60 sec (color)
0.018 lux at 1/2 sec (color)
0.00018 lux at 1/2 sec (B-W)
0.45 lux at 1/50 sec (color)
0.015 lux at 1/1.5 sec (color)
0.00015 lux at 1/1.5 sec (B-W)
0.55 lux at 1/60 sec (color)
0.018 lux at 1/2 sec (color)
0.00018 lux at 1/2 sec (B-W)
0.45 lux at 1/50 sec (color)
0.015 lux at 1/1.5 sec (color)
0.00015 lux at 1/1.5 sec (B-W)
0.65 lux at 1/60 sec (color)
0.15 lux at 1/60 sec (B-W)
0.55 lux at 1/50 sec (color)
0.12 lux at 1/50 sec (B-W)
Sync System Internal/AC line lock, phase adjustable
using remote control, V-Sync
Internal/AC line lock, phase adjustable
using remote control, V-Sync
Internal/AC line lock, phase adjustable
using remote control, V-Sync
White Balance Automatic with manual override Automatic with manual override Automatic with manual override
Shutter Speed
NTSC
PAL
Automatic (electronic iris)/Manual
1/2 ~ 1/30,000
1/1.5 ~ 1/30,000
Automatic (electronic iris)/Manual
1/2 ~ 1/30,000
1/1.5 ~ 1/30,000
Automatic (electronic iris)/Manual
1/2 ~ 1/30,000
1/1.5 ~ 1/30,000
Iris Control Automatic iris control with manual
override
Automatic iris control with manual
override
Automatic iris control with manual
override
Gain Control Automatic/OFF Automatic/OFF Automatic/OFF
Video Output 1 Vp-p, 75 ohms 1 Vp-p, 75 ohms 1 Vp-p, 75 ohms
Video Signal-to-Noise >50 dB >50 dB >50 dB
Wide Dynamic Range 128X 128X —
Electronic Image Stabilization Integrated/Selectable — —
Image Enhancement Integrated/Selectable — —
Video Motion Detection Integrated Integrated —
