Side 1/36
Installation & Operation Manual
L20-378 rev. 3 (01/13)
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this manual
for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: ____________________
ENGLISH
Covering all Solstice & Solstice Supreme
With Matchless Ignition
Built after 08/2000
D
E
I
F
I
T
R
E
C
D
E
S
I
G
N
CIRET IFED
TO THE PURCHASER, OWNER AND STORE MANAGER
Please review these warnings prior to posting them in a prominent location for reference.
ii
L20-378 rev.3 (01/13)
TO THE PURCHASER
Post in a prominent location the instructions to be followed in the
event that an operator smells gas. Obtain this information from
your local gas supplier.
FOR YOUR PROTECTION
DO NOT store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Do not spray aerosols in the vicinity of this appliance when it is
in operation.
WARNING
Improper installation, operation, alteration, adjustments, service
or maintenance can cause property damage, injury or death.
Read the installation, operating and maintenance instructions
thoroughly before installing, operation, servicing this appliance.
WARNING
Installation, maintenance and repairs should be performed by a
Pitco Authorized Service and Parts (ASAP) company technician
or other qualified personnel. Installation, maintenance or repairs
by an unauthorized and unqualified personnel will void the
warranty.
WARNING
Installation and all connections must be made according to
local codes in force. In the absence of local codes in North
America, the installation must conform with the National Fuel
Gas Code, ANSI Z223.1/NFPA 54 or the Natural Gas and
Propane Installation Code CSA B149.1 as applicable. In
Australia, the appliance must installed in compliance with
AS/NZS 5601.
WARNING
During the warranty period if a customer elects to use a non-
original part or modifies an original part purchased from Pitco
and/or its Authorized Service and Parts (ASAP) companies, this
warranty will be void. In addition, Pitco and its affiliates will not
be liable for any claims, damages or expenses incurred by the
customer which arises directly or indirectly, in whole or in part,
due to the installation of any modified part and/or received from
an unauthorized service center.
WARNING
This appliance, when installed, must be electrically grounded in
accordance with local codes, or in the absence of local codes,
with the National Electrical Code, ANSI/NFPA 70, or the Canadian
Electrical Code, CSA C22.2, as applicable and the hose must
comply with AS/NZS 1869 and be class B or D.
WARNING
Adequate means must be provided to LIMIT the movement or this
appliance without depending on the gas or electrical cord
connection. Single appliances equipped with legs must be
stabilized by installing anchor straps. All appliances equipped
with casters must be stabilized by installing restraining chains.
WARNING
An appliance equipped with casters and a flexible gas line must
be connected to the gas supply with a quick disconnect device.
In North America this quick disconnect must comply with ANSI
Z24.41. In Australia, the quick disconnect must comply with AS
4627.
WARNING
DO NOT alter or remove structural material on the appliance to
accommodate placement under a ventilation hood.
WARNING
If the appliance is equipped with a power cord and it is damaged,
it must be replaced by a Pitco Authorized Service and Parts
(ASAP) company technician, or a similarly qualified person in
order to avoid a hazard.
WARNING
The power supply must be disconnected before servicing,
maintaining or cleaning this appliance.
WARNING
The appliance is NOT jet stream approved. DO NOT clean the
appliance with a water jet.
WARNING
DO NOT attempt to move this appliance or transfer hot liquids
from one container to another when the unit is at operating
temperature or filled with hot liquids. Serious personal injury
could result if skin comes in contact with the hot surfaces or
liquids.
WARNING
DO NOT use an open flame to check for gas leaks!
WARNING
DO NOT sit or stand on this appliance. The appliance’s front
panel, tank, splash back, tank cover, workshelf, drain board is
not a step. Serious injury could result from slipping, falling or
contact with hot liquids.
WARNING
NEVER use the appliance as a step for cleaning or accessing the
ventilation hood. Serious injury could result from slips, trips or
from contacting hot liquids.
WARNING
The oil/shortening level should NOT fall below the minimum
indicated level line at any time. The use of old shortening can be
dangerous as it will have a reduced flash point and be more
prone to surge boiling.
WARNING
The contents of the crumb catch and/or filter pan of any filter
system must be emptied into a fireproof container at the end of
the frying operation each day. Some food particles can
spontaneously combust into flames if left soaking in certain
oil/shortening materials.
WARNING
Completely shut the appliance down when shortening/oil is being
drained from the appliance. This will prevent the appliance from
heating up during the draining and filling process. Serious injury
can occur.
WARNING
This appliance is intended for indoor use only.
WARNING
DO NOT operate appliance unless all panels and access covers
are attached correctly.
WARNING
It is recommended that this appliance be inspected by a qualified
service technician for proper performance and operation on a
yearly basis.
WARNING
There is an open flame inside this appliance. The unit may get
hot enough to set nearby materials on fire. Keep the area around
the appliance free from combustibles.
WARNING
DO NOT supply the appliance with a gas that is not indicated on
the data plate. If you need to convert the appliance to another
type of fuel, contact your dealer.
WARNING
If gas flow to appliance is interrupted, or pilots extinguish, wait 5
minutes before attempting to relight the pilot to allow any
residual gas in appliance to dissipate.
WARNING
Ensure that the appliance can get enough air to keep the flame
burning correctly. If the flame is starved for air, it can give off a
dangerous carbon monoxide gas. Carbon monoxide is a clear
odorless gas that can cause suffocation.
WARNING
Never add oil to the appliance when it is at operating
temperature. Splashing hot oil can cause severe injuries.
WARNING
Never add water to hot oil. Violent boiling can occur causing
severe injury.
WARNING
This appliance is intended for professional use only and should
be operated by fully trained and qualified personnel.
WARNING
Excessive loading or loading of over wet food can cause surge
boiling. The maximum cooking load must not exceed
(14T- 1.5lbs (0.68kg), 14-3 lbs (1.36 kg), 18- 5 lbs (2.27 kg)
WARNING
In North America, gas appliances equipped with casters must
be installed with connectors that comply with the Standard for
Connectors for Movable Gas Appliances, ANSI Z21.69.CSA
6.16 Latest Edition. This connection should include a quick
disconnect device that complies with the Standard for Quick
Disconnect Devices for Use With Gas Fuel ANSI Z221.41.CSA
6.9 Latest Edition. In Australia, an appliance equipped with
casters and a flexible gas line must be connected to the gas
supply with a quick disconnect device that complies with AS
4627 and a restraining cable. The restraining cable must not
exceed 80% of the length of the flexible gas line.
