User’s Manual of IMG-2x00T Modbus Gateway Series

RS232/RS422/RS485

Industrial Modbus Gateway

IMG-2100T / IMG-2105AT

IMG-2102T / IMG-2102TS

IMG-2200T / IMG-2400T

User’s Manual of IMG-2x00T Modbus Gateway Series

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no

warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for

a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability

for any inaccuracies or omissions that may have occurred.

Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of

PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes

no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to

this User's Manual and/or to the products described in this User's Manual, at any time without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and

suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be

required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode operation. For energy saving, please remove the power cable to

disconnect the device from the power circuit. In view of saving the energy and reducing the unnecessary power consumption, it

is strongly suggested to remove the power connection for the device if this device is not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and human health as a result of the presence of

hazardous substances in electrical and electronic equipment, end users of electrical and electronic

equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of

WEEE as unsorted municipal waste and have to collect such WEEE separately.

Revision

PLANET IMG-2x00T Series User's Manual

Model: IMG-2100T / IMG-2102T / IMG-2102TS / IMG-2105AT/ IMG-2200T / IMG-2400T

Revision: 1.0 (October, 2020)

Part No: EM-IMG-2x00T_v1.0

Produkt Specifikationer

Mærke:	Planet
Kategori:	Ikke kategoriseret
Model:	IMG-2102T
Kode for international beskyttelse (IP):	IP30
Bredde:	32 mm
Dybde:	87.8 mm
Højde:	135 mm
Vægt:	386 g
Produktfarve:	Blå
Opbevaringstemperatur (T-T):	-40 - 85 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Driftstemperatur (T-T):	-40 - 75 °C
Netværksstandarder:	IEEE 802.3, IEEE 802.3u
LED-indikatorer:	Ja
Monteringstype:	DIN-skinne/vægmontering
Effektkrav:	9~48V DC / 24V AC, redundant power with reverse polarity protection
Fuld duplex:	Ja
Seriel grænsefladetype:	RS-232, RS-422/485
Kontrolpanel display:	Ingen
