Side 1/2

PLANET Fiber Transceiver

QSFP-40G-SR4/QSFP-40G-LR4

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective

owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and applications,

and makes no warranty and representation, either implied or expressed, with respect to the quality,

performance, merchantability, or tness for a particular purpose.

PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims liability for any

inaccuracies or omissions that may have occurred.

Information in this User’s Manual is subject to change without notice and does not represent a commitment on

the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User’s

Manual. PLANET makes no commitment to update or keep current the information in this User’s Manual, and

reserves the right to make improvements to this User’s Manual and/or to the products described in this User’s

Manual, at any time without notice.

If you nd information in this manual that is incorrect, misleading, or incomplete, we would appreciate your

comments and suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with the Instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to correct the interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio interference, in which case

the user may be required to take adequate measures.

WEEE Warning

To avoid the potential effects on the environment and human health as a result of the presence of

hazardous substances in electrical and electronic equipment, end users of electrical and electronic

equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of

WEEE as unsorted municipal waste and have to collect such WEEE separately.

Revision

User’s Manual of PLANET QSFP+ Transceiver

For Models: QSFP-40G-SR4/QSFP-40G-LR4

Rev: 1.0 (December, 2017)

Part No: 2350-AG0890-000

1. Overview

Thank you for purchasing PLANET QSFP+ Transceiver which includes the Ethernet module of the QSFP-40G-SR4

and QSFP-40G-LR4.

The QSFP+ 40G Ethernet modules can be installed in PLANET switch products with 40G QSFP+ interface. The

QSFP+ transceivers can be extended from a distance of 100m (multi-mode, MPO/MTP) to up to 10km (single-

mode, LC).

2. Checklist

Your QSFP+ Package should contain the following items:

 The QSFP+ Transceiver Module x 1

 The User’s Manual x 1

If any item is missing or damaged, please consult the dealer from whom you purchased your QSFP+ 40G

Ethernet transceiver module.

3. Introduction and Model List

3-1 The QSFP-40G Series Ethernet Transceiver Module List

40G Ethernet Transceiver (40GBASE-SR4/LR4 QSFP+)

Model DDM Speed

(Mbps)

Connector

Interface Fiber Mode Distance Wavelength

(nm)

Operating

Temp.

QSFP-40G-SR4 YES 40G MPO/MTP Multi mode 100m(OM3)

150m(OM4) 850nm 0 ~ 60°C

QSFP-40G-LR4 YES 40G 10km 1310nmLC Single mode 0 ~ 60°C

Attenuation coefcient

Wavelength region Typical link value

1260nm-1360nm 0.5 dB/km

SFP Model

Physical Fiber Cable Length “n” km

QSFP-40G-LR4

10＜＜n 20 3 dB

20＜＜n 40 --

4. Installing QSFP+ Transceiver Module

4-1 Install the QSFP+ Ethernet Transceiver

Module

Please follow these steps to install the QSFP+ Ethernet

transceiver module:

1. Power on the Switch and place the Switch on a at

surface. Install the new QSFP+ Ethernet transceiver

module by inserting it into the slot and sliding it in until

it stops (See Figure 1). Press it rmly until you hear

the module snap into place. Never force, twist or bend

the QSFP+ Ethernet transceiver module. The QSFP+

Ethernet transceiver module slides in smoothly and the

Switch will automatically detect the new module.

2. After the Fiber connection is done successfully, check the LEDs to verify whether there is a link and a proper

connection at the port.

Please refer to the user’s manual for more about the Switch or module’s management.

4-2 Remove the QSFP+ Ethernet Transceiver Module

1. Make sure there is no network activity by consulting or checking

with the network administrator.

2. Remove the Fiber Optic Cable gently.

3. Turn the handle or pull out the tab of the QSFP+ Ethernet Trans-

ceiver module gently.

Warning

Never pull out the QSFP+ Ethernet Transceiver

module without pulling the handle or the push

bolts on the module. Directly pulling out the QSFP+

Ethernet Transceiver module would damage the

QSFP+ Ethernet Transceiver module.

Appendix A

A.1 Fiber Optic Cable Connection Parameters

The wiring details are shown below:

 Fiber Optic Patch Cables:

Standard Fiber Type Cable Specications

40GBASE-SR4 Multi-mode 50/125μm

40GBASE-LR4 Single mode 9/125μm

Safety Notice

Fiber optic SFP modules are equipped with a Class 1 laser, which emits invisible radiation. Read the following

safety warnings carefully:

Note

Class 1 Laser Product

Complies with FDA Regulation 21 CFR 1040.10 and 1040.11

Warning

Class 1 radiation is present when the device or system is powered up.

Warning

Only trained and qualified personnel should be allowed to install or replace these modules.

PLANET Technology Corp.

10F., No 96, Minquan Rd., Xindian Dist.,

New Taipei City 231, Taiwan 2350-AG0890-000

Figure 1: Insert the QSFP+ Ethernet Transceiver Module

QSFP+ Ethernet Transceiver

100m~10km

QSFP+ Ethernet Transceiver

100m~10km
