2. Product Overview
This chapter provides basic information about the QNAP TS-x64U NAS.
About the TS-x64U
The TS-x64U is powered by an Intel® Celeron® N5105/N5095 quad-core 2.9 GHz processor. The NAS
supports connecting expansion units through two native USB 3.2 Gen 2 Type-A ports, and USB JBOD
enclosures through USB ports on PCIe cards. Additionally, the TS-x64U supports SATA 6 Gbps drives
(backward compatible with SATA 3 Gbps), and is equipped with two 2.5 Gigabit Ethernet ports and one
PCIe Gen 3 p5-x2 slot for various applications and expansion options.
Hardware Specications
Warning
• If your QNAP product has hardware defects, return the product to QNAP or a QNAP-
authorized service center for maintenance or replacement. Any attempt to repair or
perform maintenance procedures on the product by you or an unauthorized third
party invalidates the warranty.
• QNAP is not responsible for any damage or data loss caused by unauthorized
modications and installation of unsupported third-party applications.
• For details, see the QNAP Warranty Terms and Conditions.
Tip
Model are subject to change without prior notice. To see the latestspecications
specications, go to https://www.qnap.com.
Ordering P/N Drive bays Memory Power supply
TS-464U-4G 4 4 GB Single
TS-464U-RP-4G 4 4 GB Redundant
TS-1264U-RP-4G 4 4 GB Redundant
Component TS-464U-4G TS-464U-RP-4G TS-1264U-RP-4G
Processor
CPU Intel® Celeron® N5105/N5095
Frequency 4-core/4-thread 2.9 GHz burst
Architecture x86 64-bit
Encryption engine AES-NI
Memory
Pre-installed memory 4 GB RAM: 1 x 4 DDR4 SODIMM
TS-x64U User Guide
Product Overview 4

Component TS-464U-4G TS-464U-RP-4G TS-1264U-RP-4G
Memory slots 2 x SODIMM DDR4
Important
• Use only QNAP memory modules to maintain system
performance and stability. For NAS devices with more
than one memory slot, use QNAP modules with identical
specications.
• Using unsupported modules may degrade performance,
cause errors, or prevent the operating system from
starting.
Maximum memory 16 GB (2 x 8 GB)
Flash memory 4 GB (dual-boot OS protection)
Storage
Drive bays 4 x 3.5-inch SATA 6 Gbps 4 x 3.5-inch SATA 6 Gbps 12 x 3.5-inch SATA 6 Gbps
Tip
The drive bays are backward compatible with SATA 3 Gbps
drives.
Drive compatibility 3.5-inch bays:
• 3.5-inch SATA hard disk drives
• 2.5-inch SATA hard disk drives
• 2.5-inch SATA solid-state drives
Note
For the list of compatible drive models and expansion cards,
go to https://www.qnap.com/compatibility.
SSD cache acceleration
support
This device supports SSD cache acceleration for all drives.
Hot-swapping This device supports hot-swapping for all drives.
Network
2.5 Gigabit network
interface
2 x 2.5 GbE RJ45
Note
These ports provide 2.5 Gbps, 1 Gbps, 100 Mbps, and 10 Mbps
network connection speeds.
External I/O Ports & Expansion Slots
PCIe slots 1 x PCIe Gen 3 x2
Tip
For the list of compatible drive models and expansion cards,
go to https://www.qnap.com/compatibility.
USB ports 2 x USB 2.0 Type-A
2 x USB 3.2 Gen 2 Type-A
HDMI ports 1 x HDMI
Interface
TS-x64U User Guide
Product Overview 5

Component TS-464U-4G TS-464U-RP-4G TS-1264U-RP-4G
Buttons • Power
• Reset
Dimensions
Form factor 1U Rackmount 1U Rackmount 2U Rackmount
Dimensions (H x W x D) 43.3 x 482.6 x 483.9 mm
(1.70 x 19.0 x 19.05 in)
43.3 x 482.6 x 508.7 mm
(1.70 x 19.0 x 20.03 in)
88.7 x 482.2 x 423.8 mm
(3.49 x 18.98 x 16.69 in)
Net weight 6.6 kg (14.55 lbs) 8.12 kg (17.90 lbs) 9.43 kg (20.79 lbs)
Others
Rail compatibility RAIL-B02
Note
• Rail kits are not included with the NAS and must be
purchased separately. For details, contact an authorized
reseller or go to .https://shop.qnap.com
• Information on rail kit installation can be found in the
installation guide included in the rail kit package. For
details, go to https://www.qnap.com/go/product/rail-kit.
Power supply unit 1 x 250W, 100-240V AC,
50/60Hz
2 x 250W, 100-240V AC,
50/60Hz
2 x 300W, 100-240V AC,
50/60Hz
System battery CR2032 lithium battery (3V, 225 mAh)
Fans 2 x 40 mm, 12V DC fans 2 x 40 mm, 12V DC fans 2 x 80 mm, 12V DC fans
Operating temperature 0˚C to 40˚C (32˚F to 104˚F)
Relative humidity • Non-condensing relative humidity: 5% to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
Tip
For the list of compatible drive models and expansion cards, go to https://www.qnap.com/
compatibility.
Package Contents
Item Quantity
TS-x64U NAS 1
Power cords • TS-464U-4G: 1
• TS-464U-RP-4G: 2
• TS-1264U-RP-4G: 2
Ethernet cable 1 x Cat5e (RJ45)
Screws for 3.5-inch drives • TS-464U-4G: 16
• TS-464U-RP-4G: 16
• TS-1264U-RP-4G: 48
TS-x64U User Guide
Product Overview 6
Produkt Specifikationer
Mærke: | QNAP |
Kategori: | I DEN |
Model: | TS-464U-RP |
Type: | NAS |
Tænd-/slukkontakt: | Ja |
Vekselstrømsindgangsspænding: | 100 - 240 V |
Bredde: | 430 mm |
Dybde: | 479 mm |
Højde: | 43.3 mm |
Vægt: | 8120 g |
Produktfarve: | Sort |
Pakkevægt: | 10100 g |
USB-port: | Ja |
Opbevaringstemperatur (T-T): | -20 - 70 °C |
Relativ luftfugtighed ved drift (H-H): | 5 - 95 % |
Relativ luftfugtighed ved opbevaring (H-H): | 5 - 95 % |
Antal HDMI-porte: | 1 |
Ethernet LAN-porte (RJ-45): | 2 |
Antal USB 2.0-porte: | 2 |
Ethernet LAN: | Ja |
Processorkerner: | 4 |
Strømforbrug (typisk): | 51.404 W |
Driftstemperatur (T-T): | 0 - 40 °C |
Ethernet LAN-datahastigheder: | 10,1000,2500,100 Mbit/s |
Sikkerhedsalgoritmer: | HTTPS, SSH, 256-bit AES, FIPS 140-2 |
Intern hukommelse: | 4 GB |
Kabler inkluderet: | AC, LAN (RJ-45) |
Understøttede filsystemer: | FAT32, exFAT, HFS+, NTFS, ext3, ext4 |
Operativsystem installeret: | QNAP Turbo System |
DHCP-klient: | Ja |
DHCP-server: | Ja |
Knap til nulstilling: | Ja |
LED-indikatorer: | HDD, Status, Power, LAN |
Version af operativsystem: | 5.0.1 |
Harmoniseret systemkode (HS): | 84714100 |
Processorfrekvens: | - GHz |
Processorserie: | Intel® Celeron® |
Processor boost frekvens: | 2.9 GHz |
Processortråde: | 4 |
Intern hukommelsestype: | DDR4 |
Hukommelse form faktor: | SO-DIMM |
On-board grafikkort, model: | Intel® UHD Graphics |
Understøttede Windows-operativsystemer: | Windows 10, Windows 8, Windows 7, Windows 11 |
Understøttede Mac-operativsystemer: | Ja |
Understøttede Linux-operativsystemer: | Ja |
Andre understøttede operativsystemer: | Solaris 10 |
Hukommelsesstik: | 2 |
Processorproducent: | Intel |
HDMI-version: | 1.4b |
Understøttet browser: | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
Flashhukommelse: | 4000 MB |
Understøtter S.M.A.R.T.: | Ja |
Lydalarm: | Ja |
Understøttede operativsystemer til servere: | Windows Server 2019, Windows Server 2012 R2, Windows Server 2008 R2, Windows Server 2016, Windows Server 2012 |
Adgangskontrolliste (ACL): | Ja |
Jumbo Frames support: | Ja |
Antal blæsere: | 2 blæser(e) |
Understøttet datalagringsdrev typer: | HDD & SSD |
Antal understøttede lagerdiske: | 4 |
Datalagringsdriver installeret: | Ingen |
Kabinettype: | Stativ (1U) |
Ventilator diameter: | 40 mm |
Kølingstype: | Aktiv |
Dynamisk DNS (DDNS): | Ja |
Understøtter RAID: | Ja |
Redundant strømforsyning: | Ja |
Understøttede lagerdrev brugerflader: | Serial ATA II, Serial ATA III |
Placering af strømforsyning: | Indbygget |
Wake-on-LAN klar: | Ja |
Blæser, spænding: | 12 V |
Installeret lagerdisktype: | Ingen |
Total installeret opbevaringskapacitet: | - TB |
Kapacitet af datalagringsdrev: | - GB |
RAID-niveauer: | 0, 6,1, JBOD, 5,10 |
Hot-swap drevbåse: | Ja |
Enhedsklasse: | Små & mellemstore virksomheder |
Backup funktion: | Ja |
Backup detaljer: | Cloud, iSCSI LUN |
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte: | 2 |
Understøttede lagerdisk størrelser: | 2.5, 3.5 " |
Strømforsyningens kapacitet (PCU): | 250 W |
Antal strømforsyninger: | 2 |
Online RAID-migrering: | Ja |
Online RAID-udvidelse: | Ja |
Maksimal understøttede RAM: | 16 GB |
iSCSI-understøttelse: | Ja |
Indbygget FTP-server: | Ja |
System logfil: | Ja |
Flersproget support: | Ja |
Snapshot: | Ja |
Varm reservedel: | Ja |
Filmappe: | CIFS/SMB |
Strømforbrug (HDD standby): | 37.469 W |
Antal strømkabler: | 2 |
Samtidige forbindelser: | 1500 |
Disk roaming: | Ja |
Antal skruer: | 84 |
RAID genbygget: | Ja |
Disk scanning: | Ja |
Har du brug for hjælp?
Hvis du har brug for hjælp til QNAP TS-464U-RP stil et spørgsmål nedenfor, og andre brugere vil svare dig
I DEN QNAP Manualer
12 Januar 2025
14 Oktober 2024
6 Oktober 2024
2 September 2024
31 August 2024
29 August 2024
27 August 2024
24 August 2024
19 August 2024
18 August 2024
I DEN Manualer
- Mustang
- Promise Technology
- D-Link
- Seagate
- Toshiba
- Maxdata
- HP
- Netgear
- Infortrend
- Samsung
- AIC
- Veritas
- LaCie
- Allnet
- Approx
Nyeste I DEN Manualer
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
