Side 1/8

A-TYPE, S-TYPE, T-TYPE & CRUISER SCOOTERS

OWNER’S MANUAL

Read and understand this entire manual before allowing

child to use this product! For assistance contact Razor.

DO NOT RETURN TO STORE.

NOTE: Manual illustrations are for demonstration purposes only.

Illustrations may not reﬂect exact appearance of actual product.

Speciﬁcations subject to change without notice.

Please have your product along with the 22 character product I.D. code with you

before contacting Razor for warranty assistance and/or replacement parts.

Product I.D. Code: _____________ - ____________ - ____________

BEFORE YOU BEGIN

Need Help? Visit our web site for replacement parts, product support, a list of authorized service centers in the US and customer service contact information

at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer Service

contact information is listed at the back of this manual.

BEFORE YOU BEGIN

Remove contents from box. Inspect the contents of the box for scratches and/or dents that may have occurred during

shipping. Because your scooter was partially or fully assembled and packed at the factory, there should not be any

problems, even if the box has a few scars or dents.

WARNING:

DO NOT USE NON-RAZOR

PRODUCTS WITH YOUR

SCOOTER. Razor scooters have

been built to certain Razor design

speciﬁcations. The original

equipment supplied at the time

of sale was selected on the basis

of its compatibility with the

frame, fork and all other parts.

Certain aftermarket products may

not be compatible and will void

the warranty.

Required Tools

5 mm

Allen Wrench

(S, T and A4 Kick

Scooters only)

Product ID Locations:

1. Side of Deck Plate

2. Box - Side of UPC (Not Shown)

Box Contents:

• Scooter

• Allen Wrench (Select Models)

• Owner’s Manual

Quick-Release Lever

(Select Models)

Extension Tube

(Select Models)

Joint Release Lever/

Pivoting Mechanism

(Select Models)

Brake

T-bar

Collar Clamp

Steering Column Adjusting Screw (A4 Only)

PRE-RIDE CHECKLIST

How to Ride

Place one foot on the baseboard, push forward with the other foot. Steer with both hands on the handlebars.

For enhanced cornering, lean slightly into the direction of the turn.

How to Stop

For controlled stops, apply the brake by stepping on the rear brake. Razor recommends that you practice applying

the brake at various speeds and in an open area free from obstructions before riding your scooter around others.

USAGE

Deck and Handlebars

Check for cracks or broken connections. Although broken decks

are rare, it is possible for an aggressive rider to run into a curb

or object and wreck and bend or break the deck. Get in the habit

of inspecting your scooter on a regular basis.

Hardware/Loose Parts

Check and secure all fasteners before every ride. Make sure the

collar clamp, quick release lever (select models), and handlebar

spring buttons are locked properly in place before riding. There

should not be any unusual rattles or sounds from loose parts

or broken components. If the unit is damaged, do not ride.

Reference “Safety Warnings” on page 1 of this manual.

Safety Gear

Always wear proper protective gear, such as an approved safety

helmet. Elbow pads and kneepads are recommended. Always

wear closed toe shoes (lace-up with rubber soles) and keep

shoelaces tied and out of the way of the wheels. NEVER RIDE

BAREFOOTED OR IN SANDALS.

Laws and Regulations

Always check and obey any local laws or regulations.

Be Careful!

You will see people on TV and maybe even people you know doing

tricks and stunts. These are people who have been practicing on

scooters for a very long time. Don’t try something until you are

ready. Avoid steep inclines and don’t ride too fast — you can lose

control and fall. Skateboard parks are not designed for scooters.

Never ride in trafﬁc or on the street and watch your surroundings

for pedestrians, bikers, boarders and skaters.

Maintain a hold on the handlebars at all times.

Need Help? Visit our web site for replacement parts, product support, a list of authorized service centers in the US and customer service contact information

at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer Service

contact information is listed at the back of this manual.

REPAIR AND MAINTENANCE

Using a 3 mm Allen wrench and with the scooter in the upright and locked position, adjust the set screw at the

baseboard until there is no free-play between the baseboard and the steering column. Be careful not to over-tighten this

screw as it need only be snug against the steering column. Verify the adjustment by releasing the steering column from

the locked position and folding the scooter. The joint lever should not bind and the folding movement should be smooth.

The spring-loaded mechanism should automatically lock and be fully seated in the upright position.

Baseboard/Steering Column Adjusting Screw (A4 ONLY)

Wheels and Bearings

Under normal circumstances and conditions, Razor wheels and wheel bearings are maintenance free. Nonetheless, it

is the responsibility of the owner or guardian to periodically inspect the wheels for wear and tear, the axle for proper

tightness, and bearings for side-to-side play, and loose parts. When a wheel or wheel bearing develops play, this is an

indication of excess wear and replacement is necessary. Replace immediately with only genuine Razor wheels. Worn

wheels/bearings are considered normal wear-and-tear and are not covered by the Razor Warranty. Wheels other than

genuine Razor wheels may not be compatible with your Razor scooter. The use of anything other than genuine Razor

replacement parts may affect your safety and will void your warranty.

Replacement Parts

The most frequently requested replacement parts are available for purchase at some Razor retail partners.

For the complete selection of replacement parts visit shop.razor.com.

Repair Centers

For a list of authorized Razor repair centers:

• Check online at www.razor.com.

• Additional Customer Service contact information is listed at the back of this manual.

Cleaning Your Scooter

Wipe with a damp cloth to remove dirt and dust. Do not use industrial cleaners or solvents as they may damage the

surfaces. Do not use alcohol, alcohol-based or ammonia-based cleaners as they may damage or dissolve the plastic

components or soften the decals or decal adhesive.

WARNING: Wheelies

and other stunt-type riding reduces

your ability to maneuver and control

your scooter. Take the necessary

precautions, such as wearing

appropriate protective gear and

practice in a area safe for stunt

riding and free from obstructions.

WARNING: Keep ﬁngers

clear of the pivoting mechanism

when folding or unfolding the

scooter (select models).

Produkt Specifikationer

Mærke:	Razor
Kategori:	Scooter
Model:	A5 Air
Type:	Klassisk scooter
Bredde:	890 mm
Dybde:	428 mm
Højde:	980 mm
Vægt:	5070 g
Brugervejledning:	Ja
Produktfarve:	Sølv
Maksimal belastningsvægt:	100 kg
Bremsesystem:	Fodbremse
Sammenfoldelig:	Ja
Normal brug:	Asphalt, Cobblestone, Pebble
Antal hjul:	2 hjul
Anbefalet køn:	Ethvert køn
Anbefalet alder (min.):	8 År
Antal produkter inkluderet:	1 stk
Hjultype:	Oppustelige hjul
Ergonomisk greb:	Ja
Anbefalet alder:	Voksne
Hjulstørrelse:	200 mm
Støtteben:	Ja
Højdejustering af styret:	Ja
Justerbar rathøjde:	Ja
Cykelstyr - længde:	340 mm
Dæk materiale:	Aluminium
