E L T Pause Previous/Next Tools ReturnR
1. PhotosPress the or button to select ◄ ► , then press the
button in the menu.Media Play
2. Press the ◄ ► ▲ ▼/ / / button to select the desired photo in the file
xWhile a photo list is displayed, press the
button on the remote control to star t the slide show.
xAll files in the file list section will be displayed in the slide show.
xDuring the slide show, files are displayed in order.
xDuring the slide show, you can adjust the slide show speed using
xYou can move to other file using or ◄ ► button.
✎Music files can be automatically played during the Slide Show if
the is set to .Background Music On
✎The Mode in Background Music cannot be changed until the
BGM has finished loading.
yCMYK, YCCK Colour space JPEG are not supported.
Playing selected video/music/photo files
1. Press the Yellow button in the file list to select the desired file.
2. Repeat the above operation to select multiple files.
mark appears to the left of the selected files.
xTo cancel a selection, press the Yellow button again.
xTo deselect all selected files, press the button and select TOOLS
3. Press the button, and then select TOOLS Play Selected
Playing the video/music/photo file group
While a file list is displayed, move to any file in desired group.
Media Play - Additional Functions
Videos/Music/Photos Play Option menus
When playing a file, press the button.TOOLS
Category Operation Videos Music Photos
Title You can move the other file directly.
You can play movie and music files
You can adjust the picture size to your
Picture Mode You can adjust the picture setting.
Sound Mode You can adjust the sound setting.
You can play the video with Subtitles. This
function only works if the subtitles are the
same file name as the video.
You can change the audio language if the
video has more than one language.
You can start or stop a Slide Show.
You can select the slide show speed during
You can set and select background music
when watching a Slide Show.
You can zoom into images in full screen
Rotate You can rotate images in full screen mode.
You can see detailed information about
DivX® Video On Demand : Shows the registration code
authorized for the TV. If you connect to the DivX web site and
register with 10-digit registration code, you can download the VOD
activation file. Once you play it using , the registration Media Play
✎For more information on DivX® VOD, visit http://vod.divx.
Information: Select to view information on the connected device.
Display Resolution 1920 x 1080
Environmental Considerations
10°C to 40°C (50°F to 104°F)
10% to 80%, non-condensing
-20°C to 45°C (-4°F to 113°F)
5% to 95%, non-condensing
Model Name UA32EH5000 / UA32EH5030 / UA32EH5080 UA40EH5000 / UA40EH5030 / UA40EH5080
738.3 X 444.9 X 93.2 (mm)
738.3 X 498.2 X 191.7 (mm)
927.6 X 551.0 X 93.0 (mm)
927.6 X 606.5 X 227.6 (mm)
Model Name UA42EH5000 UA46EH5000
Screen Size 107 cm 117 cm
975.0 X 576.9 X 93.0 (mm)
975.0 X 633.7 X 227.6 (mm)
1059.8 X 625.6 X 94.3 (mm)
1059.8 X 680.7 X 227.6 (mm)
✎Design and specifications are subject to change without prior notice.
✎For information about power supply, and more about power consumption, refer to the label attached to the product.
ySupported Subtitle Formats
Advanced SubStation Alpha .ass
SubStation Alpha Text FormatMKV
Advanced SubStation Alpha Text FormatMKV
MPEG-4 Timed text Text FormatMP4
Container ResolutionVideo Codec
Bit rate(Mbps) Audio Codec
DivX 3.11/4.x/5.1/6.0 1920x1080 6~30 30Mbps
H264 1920x1080 6~30 30Mbps
AVC 1920x1080 6~30 30Mbps
MJPEG 640x480 6~30 10Mbps
DivX 3.11/4.x/5.1/6.0 1920x1080 6~30 30Mbps
MPEG4 SP / ASP 1920x1080 6~30 30Mbps
H264 1920x1080 6~30 30Mbps
MJPEG 640x480 6~30 10Mbps
DivX 3.11 / 4.x /5.1 / 6.0 MP3 / AC3 1920x1080 6~30 30Mbps
MPEG4 SP / ASP 1920x1080 6~30 30Mbps
H.264 1920x1080 6~30 30Mbps
MPEG2 1920x1080 6~30 30Mbps
H. 264 BP / MP / HP 1920x1080 6~30 30Mbps
MPEG1 1920x1080 24/25/30 30Mbps
MPEG2 1920x1080 24/25/30 30Mbps
H. 264 BP / MP / HP 1920x1080 6~30 30Mbps
MPEG4 SP / ASP 1920x1080 6~30 30Mbps
H.264 1920x1080 6~30 30Mbps
H.264 1920x1080 6~30 30Mbps
Sorenson H.263 1920x1080 6~30 30Mbps
yVideo content will not play, or not play correctly, if there is an error
in the content or the container.
ySound or video may not work if the contents have a standard bit
rate/ frame rate above the compatible Frame/sec listed in the table
yIf the Index Table is in error, the Seek (Jump) function is not
yThe menu may take longer to appear if the video’s bit rate exceeds
yVideo content can not be played, if there are many contents in one
Supports up to H.264, Level 4.1
H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and AVCHD are not supported.
– Below 1280 x 720: 60 frame max
– Above 1280 x 720: 30 frame max
Supports up to WMA7, 8, 9 STD, 9 PRO, 10 PRO
WMA 9 PRO and WMA 10 PRO support 5.1 channel. (LBR mode of WMA Pro is not
WMA Lossless is not supported.
Pause Jump Tools ReturnL T R
1. MusicPress the or button to select ◄ ► , then press the
button in the menu.Media Play
2. Press the / / / button to select the desired Music in the file ◄ ► ▲ ▼
button or (Play) button.
✎During music playback, you can search using the and ◄ ►
(FF) buttons do not function during play.
✎Only displays the files with MP3 and PCM file extension. Other
file extensions are not displayed, even if they are saved on the
✎If the sound is abnormal when playing MP3 files, adjust the
Equalizer in the Sound menu. (An over-modulated MP3 file
may cause a sound problem.)
Assembling the Cable manager
If you remove the attached sticker on the TV screen, clean the residues and then watch TV.
Do not spray water directly onto the product. Any liquid that goes into the
product may cause a failure, fire, or electric shock.
Clean the product with a soft cloth dampened with in a small amount of water.
Do not use a flammable liquid (e.g. benzene, thinners) or a cleaning agent.
Installing the Wall Mount Kit
The wall mount kit (sold separately) allows you to mount the TV on
the wall. For detailed information on installing the wall mount, see
the instructions provided with the wall mount. Contact a technician
for assistance when installing the wall mount bracket.
Samsung Electronics is not responsible for any damage to the
product or injury to yourself or others if you elect to install the TV
Wall Mount Kit Specifications (VESA)
✎The wall mount kit is not supplied, but sold separately.
Install your wall mount on a solid wall perpendicular to the floor.
When attaching to other building materials, please contact your
nearest dealer. If you install the TV on a ceiling or slanted wall, it
may fall and result in severe personal injury.
xStandard dimensions for wall mount kits are shown in the table
xWhen purchasing our wall mount kit, a detailed installation
manual and all parts necessary for assembly are provided.
xDo not use screws that do not comply with the VESA standard
xDo not use screws longer than the standard dimension, as they
may cause damage to the inside of the TV set.
xFor wall mounts that do not comply with the VESA standard
screw specifications, the length of the screws may differ
depending on the wall mount specifications.
xDo not fasten the screws too firmly. This may damage the
product or cause the product to fall, leading to personal injury.
Samsung is not liable for these kinds of accidents.
xSamsung is not liable for product damage or personal injury
when a non-VESA or non-specified wall mount is used or the
consumer fails to follow the product installation instructions.
xDo not mount the TV at more than a 15 degree tilt.
xAlways have two people mount the TV on a wall.
Do not install your Wall Mount Kit
while your TV is turned on. It may
result in personal injury due to
Securing the TV to the Wall
Caution: Pulling, pushing, or climbing onto the TV
may cause the TV to fall. In particular, ensure that your
children do not hang over or destabilize the TV; doing
so may cause the TV to tip over, resulting in serious
injuries or death. Follow all safety precautions provided
on the included Safety Flyer. For added stability, install
the anti-fall device for safety purposes, as follows.
To prevent the TV from falling
✎Since the necessary clamps, screws, and string are not
supplied, please purchase these additionally.
1. Put the screws into the clamps and firmly fasten them onto the
wall. Confirm that the screws have been firmly installed onto the
✎You may need additional material such as an anchor
depending on the type of wall.
✎Since the necessary clamps, screws, and string are not
supplied, please purchase these additionally.
2. Remove the screws from the back Centre of the TV, put the
screws into the clamps, and then fasten the screws onto the TV
✎Screws may not be supplied with the product. In this case,
please purchase the screws of the following specifications.
3. Connect the clamps fixed onto the TV and the clamps fixed onto
the wall with a strong cable and then tie the string tightly.
xInstall the TV near to the wall so that it does not fall
xIt is safe to connect the string so that the clamps fixed on
the wall are equal to or lower than the clamps fixed on the
xUntie the string before moving the TV.
4. Verify all connections are properly secured. Periodically check
connections for any sign of fatigue for failure. If you have
any doubt about the security of your connections, contact a
The Kensington Lock is not supplied by Samsung. It is a device
used to physically fix the system when using it in a public place.
Refer to the manual provided with the Kensington Lock for
additional information on proper use.
” icon on the rear of the TV. The Kensington
✎The position and colour may differ depending on the model.
To lock the product, follow these steps:
1. Wrap the Kensington lock cable around a large, stationary object
2. Slide the end of the cable with the lock attached through the
looped end of the Kensington lock cable.
3. Insert the locking device into the Kensington slot on the product.
✎These are general instructions. For exact instructions, see the
User manual supplied with the locking device.
✎The locking device has to be purchased separately.
✎The location of the Kensington slot may be different
depending on the TV model.
If you have any questions about the TV, first refer to this list. If none of these troubleshooting tips apply, please visit “www.samsung.com,”
then click on Support, or contact the call centre listed on the back-cover of this manual.
Problem Possible Solution
The TV image does not look as good as
• If you have an analogue cable/set top box, upgrade to a digital set top box. Use HDMI or Component cables to
deliver HD (high definition) picture quality.
• Cable/Satellite subscribers: Try HD stations from the channel line up.
• Antenna connection: Try HD stations after performing Auto tuning.
✎Many HD channels are up scaled from SD(Standard Definition) contents.
• Adjust the Cable/Set top box video output resolution to 1080i or 720p.
• Make sure you are watching the TV at the minimum recommended distance based on the size and definition of
The picture is distorted: macroblock
error, small block, dots, pixelization
• Compression of video contents may cause picture distortion especially in fast moving pictures such as sports and
• Low signal level or bad quality can cause picture distortion. This is not a TV issue.
• Mobile phones used close to the TV (cca up to 1m) may cause noise in picture on analogue and digital TV.
Colour is wrong or missing. If you’re using a component connection, make sure the component cables are connected to the correct jacks. •
Incorrect or loose connections may cause colour problems or a blank screen.
There is poor colour or brightness. Adjust the options in the TV menu. (go to • Picture Picture mode / Colour / Brightness / Sharpness)
• Adjust Energy Saving option in the TV menu. (go to MENU - Setup -Eco Solution Energy Saving - )
• Try resetting the picture to view the default picture settings. (go to MENU - Picture - Picture Reset)
There is a dotted line on the edge of
• If the picture size is set to , change it to Screen Fit 16:9.
• Change cable/satellite box resolution.
The picture is black and white. If you are using an AV composite input, connect the video cable (yellow) to the Green jack of component input 1 •
When changing channels, the picture
freezes or is distorted or delayed.
• If connected with a cable box, please try to reset the cable box. Reconnect the AC cord and wait until the cable
box reboots. It may take up to 20 minutes.
• Set the output resolution of the cable box to 1080i or 720p.
There is no sound or the sound is too
• Please check the volume the of external device connected to your TV.
The picture is good but there is no
• Set the option to in the sound menu.Speaker Select TV Speaker
• If you are using an external device, make sure the audio cables are connected to the correct audio input jacks on
• If you are using an external device, check the device’s audio output option (ex. you may need to change your
cable box’s audio option to HDMI when you have a HDMI connected to your TV).
• If you are using a HDMI cable, a separate audio cable is required.
• If your TV has a headphone jack, make sure there is nothing plugged into it.
The speakers are making an
• Check the cable connections. Make sure a video cable is not connected to an audio input.
• For antenna or cable connections, check the signal strength. Low signal level may cause sound distortion.
The TV will not turn on. Make sure the AC power cord is securely plugged in to the wall outlet and the TV.•
• Make sure the wall outlet is working.
• Try pressing the button on the TV to make sure the problem is not the remote. If the TV turns on, refer to POWER
“The remote control does not work” below.
The TV turns off automatically. Ensure the is set to in the menu. • Sleep Timer Off Time
• If your PC is connected to the TV, check your PC power settings.
• Make sure the AC power cord is plugged in securely to the wall outlet and the TV.
• When watching TV from an antenna or cable connection, the TV will turn off after 10 ~ 15 minutes if there is no
There is no picture/video. Check cable connections (remove and reconnect all cables connected to the TV and external devices).•
• Set your external devices’ (Cable/Set top Box, DVD, Blu-ray etc) video outputs to match the connections to the
TV input. For example, if an external device’s output is HDMI, it should be connected to an HDMI input on the TV.
• Make sure your connected devices are powered on.
• Be sure to select the TV’s correct source by pressing the button on the TV remote.SOURCE
Problem Possible Solution
RF(Cable/Antenna) Connection
The TV is not receiving all channels. Make sure the Antenna cable is connected securely.•
• Please try (Initial setup) to add available channels to the channel list. Go to Plug & Play MENU - Setup - Plug &
Play (Initial setup) and wait for all available channels to be stored.
• Verify the Antenna is positioned correctly.
The picture is distorted: macroblock
error, small block, dots, pixelization
• Compression of video contents may cause picture distortion, especially on fast moving pictures such as sports
• A low signal can cause picture distortion. This is not a TV issue.
A “ ” message Mode Not Supported
• Set your PC’s output resolution so it matches the resolutions supported by the TV.
The video is OK but there is no audio. If you are using a HDMI connection, check the audio output setting on your PC.•
The picture will not display in full screen. HD channels will have black bars on either side of the screen when displaying up scaled SD (4:3) contents.•
• Black bars on the top and bottom will appear during movies that have aspect ratios different from your TV.
• Adjust the picture size options on your external device or TV to full screen.
The remote control does not work. Replace the remote control batteries with the poles (+/–) in the right direction.•
• Clean the transmission window located on the top of the remote control.
• Try pointing the remote directly at the TV from 5~6 feet away.
The cable/set top box remote control
does not turn the TV on or off, or adjust
• Programme the Cable/Set top box remote control to operate the TV. Refer to the Cable/Set top box user manual
A “ ” message Mode Not Supported
• Check the supported resolution of the TV, and adjust the external device’s output resolution accordingly. Refer to
resolution settings in this manual.
There is a plastic smell from the TV. This smell is normal and will dissipate over time.•
TV is tilted to the right or left side. Remove the stand base from the TV and reassemble it.•
There are difficulties assembling the
• Make sure the TV is placed on a flat surface. It is necessary to use magnetized screw driver if you cannot remove
The Channel menu is grey out
• The Channel menu is only available when the TV source is selected.
Your settings are lost after 30 minutes or
every time the TV is turned off.
• If the TV is in the mode, it will reset audio and picture settings every 30 minutes. Change the settings Store Demo
from Store Demo Home Use Plug & Play mode to mode in the (Initial setup) procedure. Press the SOURCE
button to select mode, go to (Initial setup)TV MENU →Setup →Plug & Play →ENTER
You have intermittent loss of audio or
• Check the cable connections and reconnect them.
• Loss of audio or video can be caused by using overly rigid or thick cables. Make sure the cables are flexible
enough for long term use. If mounting the TV to the wall, we recommend using cables with 90 degree
You see small particles when you look
closely at the edge of the frame of
• This is part of the product’s design and is not a defect.
There are recurrent picture/sound issues. • Check and change the signal/source.
A reaction may occur between the
rubber cushion pads on the base stand
and the top finish of some furniture.
• To prevent this, use felt pads on any surface of the TV that comes in direct contact with furniture.
✎This TFT LED panel uses a panel consisting of sub pixels which require sophisticated technology to produce. However, there may be a few bright or dark
pixels on the screen. These pixels will have no impact on the per formance of the product.
✎You can keep your TV as optimum condition to upgrade the latest firmware on web site (samsung.com Downloads) by USB.→ Support →
Enjoy photos, music and/or movie files saved on a
USB Mass Storage Class (MSC) device.
2. Connect a USB device containing photo, music and/or movie
files to the jack on the side of the TV.USB
3. When USB is connected to the TV, you can select .Media Play
❑Using the Media Play Menu
1. Press the MENU button. Press the or button to select ▲ ▼
Application, then press the ENTER
2. Media Play (USB) Press the or button to select ▲ ▼ , then
3. Videos, Music, Press the or button to select an icon (◄ ►
Photos, Settings), then press the ENTER
✎It might not work properly with unlicenced multimedia files.
✎If you want to view detailed information of the file or
connected device, press button in the file list, and TOOLS
then select or .Detailed Information Device Information
✎Need-to-Know List before using Media Play (USB)
xThe file system supports FAT16, FAT32 and NTFS.
xCertain types of USB Digital camera and audio devices may not
be compatible with this TV.
xMedia Play only supports USB Mass Storage Class (MSC)
devices. MSC is a Mass Storage Class Bulk-Only Transport
device. Examples of MSC are Thumb drives and Flash Card
Readers. Devices should be connected directly to the TV’s USB
port. USB (HDD) is supported.
xBefore connecting your device to the TV, please back up your
files to prevent them from damage or loss of data. SAMSUNG is
not responsible for any data file damage or data loss.
xA USB device that requires high power (more than 1A) may not
xDo not disconnect the USB device while it is loading.
xThe higher the resolution of the image, the longer it takes to
xIf a file is corrupted or the TV does not support the file type, the
“Not Supported File Format” message appears.
xIf a USB extension cable is used, the USB device may not be
recognized or the files on the device may not be read.
xThe TV cannot play MP3 files with DRM that have been
downloaded from a for-pay site. Digital Rights Management
(DRM) is a technology that supports the creation, distribution,
and management of digital content in an integrated and
comprehensive way, including protecting the rights and
interests of content providers, preventing illegal copying of
contents, and managing billings and settlements.
xPTP device is not supported.
xIf an over-power warning message is displayed while you are
connecting or using a USB device, the device may not be
recognized or may malfunction.
xIf the TV has no input during the time set in Auto Protection
Time, the Screensaver will run.
xThe power-saving mode of some external hard disk drives may
be released automatically when your connect them to the TV.
xIf you use a USB extension cable, the TV may not recognize the
USB device or may not be able to read the files on the device.
xIf a USB device connected to the TV is not recognized, the
list of files on the device is corrupted, or a file in the list is not
played, connect the USB device to a PC, format the device, and
xIf a file you deleted from the PC is still found when you run
Media Play, use the “Empty the Recycle Bin” function on the
PC to permanently delete the file.
xPhotos only supports sequential jpeg format.
xThe scene search and thumbnail functions are not supported
xIf the number of files and folders saved on a USB storage
device is approximately over 4000, the files and folders may not
appear and some folders may not be opened.
xThe maximum displayed number of files, including sub folders,
in one folder of USB storage device is 2000.
xThe media may not be playing smoothly when using the device
1. VideosPress the or button to select ◄ ► , then press the
button in the menu.Media Play
2. Press the / / / button to select the desired video in the ◄►▲▼
- The selected file is displayed on the top with its playing
- If video time information is unknown, playing time and the
progress bar are not displayed.
- During video playback, you can search using the and ◄
✎In this mode, you can play movie clips contained in a game,
but you cannot play the game itself.
This marking on the product, accessories or literature indicates that the product and its electronic accessories should not be disposed of
with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of
For more information on safe disposal and recycling visit our website www.samsung.com/in or contact our Helpline numbers - 18002668282, 180030008282.
TheaterSound, SRS and the symbol are
trademarks of SRS Labs, Inc.
TheaterSound technology is incorporated under
licence from SRS Labs, Inc.
SRS TheaterSound™ provides the most immersive
surround sound experience from the TVs built-in
speakers, while maintaining steady volume and
delivering rich bass and clear dialog.
DivX Certified to play DivX video up to HD 1080p,
including premium content.
ABOUT DIVX VIDEO: DivX® is a digital video
format created by DivX, LLC, a subsidiary of Rovi
Corporation. This is an official DivX Certified®
device that plays DivX video. Visit divx. com for
more information and software tools to convert your
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certified® device must be registered in order to
play purchased DivX Video-on-Demand (VOD)
movies. To obtain your registration code, locate
the DivX VOD section in your device setup menu.
Go to vod.divx.com for more information on how
to complete your registration. Covered by one or
more of the following U.S. patents : 7,295,673;
7,460,668; 7,515,710; 7,519,274
DivX®, DivX Certified® and associated logos are
trademarks of Rovi Corporation or its subsidiaries
and are used under license.
Manufactured under Licence from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,487,535 & other
U.S. and worldwide patents issued & pending.
DTS, the Symbol, & DTS and the Symbol together
are registered trademarks & DTS 2.0 Channel is a
© DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
Open Source Licence Notice
Open Source used in this product can be found on the following webpage.
(http://opensource.samsung.com) Open Source Licence Notice is written
To send inquiries and requests for questions regarding open sources,
contact Samsung via Email (oss.request@samsung.com).
This product uses some software programs which are distributed under
the Independent JPEG Group.
ICU License - ICU 1.8.1 and later
COPYRIGHT AND PERMISSION NOTICE
Copyright (c) 1995-2008 International Business Machines Corporation and
others All rights reserved.
Permission is hereby granted, free of charge, to any person obtaining a
copy of this software and associated documentation files (the "Software"),
to deal in the Software without restriction, including without limitation
the rights to use, copy, modify, merge, publish, distribute, and/or sell
copies of the Software, and to permit persons to whom the Software is
furnished to do so, provided that the above copyright notice(s) and this
permission notice appear in all copies of the Software and that both the
above copyright notice(s) and this permission notice appear in supporting
THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY
KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO
EVENT SHALL THE COPYRIGHT HOLDER OR HOLDERS INCLUDED IN
THIS NOTICE BE LIABLE FOR ANY CLAIM, OR ANY SPECIAL INDIRECT
OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES WHATSOEVER
RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN
AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS
ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR
PERFORMANCE OF THIS SOFTWARE.
Except as contained in this notice, the name of a copyright holder shall
not be used in advertising or otherwise to promote the sale, use or other
dealings in this Software without prior written authorization of the copyright
All trademarks and registered trademarks mentioned herein are the
property of their respective owners.
[UEH5000-AR]BN68-04685A-02ENG.indd 2 2013-10-11 5:13:48
