– PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS
WARNING: Avoid potential personal injuries and property damage!
●DO NOT INSTALL THIS MOUNT IN A FIREWALL (The wall between a garage and a living space, or the wall between two condominiums or occupancies sharing a wall).
Contact your local building inspector before cutting a hole in the drywall if unsure.
●This product is designed ONLY to be installed into wood stud walls— DO NOT INSTALL INTO DRYWALL ALONE
●Do not use this product near water; such as a bath tub, wash bowl, kitchen sink, laundry tub, swimming pool, or in a wet basement.
●Equipment shall be installed in accordance with ANSI/NFPA 70, National Electrical Code (NEC), NFPA 72, CAN-ULC-S540, Canadian Electrical Code,
and/or other applicable sections of ANSI/IEEE C2 & National Electrical Safety Code (NESC). Equipment intended for installation in information
technology equipment (computer) rooms should be installed in accordance with NFPA 75, Standard for the Fire Protection of Information
Technology Equipment.
●Installation shall be completed by a professional electrical contractor or low voltage technician.
●Do not use this product for any purpose not explicitly specified by manufacturer
●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use
Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Check your TV owner’s manual to see if there are any special requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product,
contact Customer Service: +1 (800)-359-5520
135 lbs.
(61.2 kg)
TV Weight Limit
(including accessories)
DO NOT EXCEED
If your TV (plus accessories) weighs MORE, this
mount is NOT compatible.
Visit SANUS.com or call customer service to find a
compatible mount.
Tools
Needed
AwlPencil Level TapeStud
Finder ScrewdriverTape
Measure
1/8 in.
(3 mm)
Drill BitElectric Drill
Call Customer Service:
+1 (800)-359-5520
ONLY install on
wood stud wall.
Drywall alone
will NOT hold the
weight of your TV.
Unsure
wood studs
16" spacing
ACCEPTABLE
CAUTION:
DO NOT install
in drywall alone
