INSTRUCTION MANUAL CE42LM6R

CE42LM6DPB

CE42LM6WP

CE42SR2

CE52LH2R

CE52LH2WP

CE52SR2

LCD Monitor

Please read this Instruction book before using your LCD monitor.

We wish you many hours of pleasure from your new LCD monitor.

TABLE OF CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . 2

SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . 3

Installation and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

SERVICING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Federal Communications Commission Notice . . . . . . . . . 4

AC Power Cord Requirement . . . . . . . . . . . . . . . . . . . . . . 5

End-User License . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Step: 1 Mains Connection . . . . . . . . . . . . . . . . . . . . . . . . . 6

Step: 2 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Remote control battery installation . . . . . . . . . . . . . . . . . . 7

Controls and Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Menu Operation ................................. 8

Picture menu ................................... 8

MENU OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Picture menu ................................... 9

Sound menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Time menu ..................................... 9

Setup menu .................................... 9

PC Adj. menu ...................................10

INSTALLATION MODE . . . . . . . . . . . . . . . . . . . . . . . .11

Installation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Selection of picture size . . . . . . . . . . . . . . . . . . . . . . . . . .12

PIP/POP Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

OPERATION (IN TEXT MODE) . . . . . . . . . . . . . . . . . 14

Teletext Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

SPECIFICATIONS/HELPFUL HINTS . . . . . . . . . . . . 15

Speciﬁcation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Helpful hints ....................................15

DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

PC/DVI-D/COMPONENT SIGNAL SUPPORT

TIMING LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

RS232C COMMAND TABLES . . . . . . . . . . . . . . . . . . 18

TABLE OF CONTENTS

Robust monitor (CE42LM6R, CE42LM6DPB, CE52LH2R)

The robust monitor can be used in a wide variety of environments for dusty and oily circumstance such as fast food, digital signage, industrial

and public display.

¡NON GLARE ACRYLIC PANEL

This monitor set has a non glare acrylic panel. This offers the protection for the panel surface in the public display applications and easy

to clean the panel.

¡ALUMINUM CABINET & NON HOLES DESIGN

This monitor set uses Anodized aluminum and it has quite unique “Non-Holes” ventilation design which protects against mischief in the

public display applications and less maintenance when used in a dusty or oily environment.

Weather proof monitor (CE42LM6WP, CE52LH2WP)

Weather resistant and water proof in accordance with the IP66 standard.

¡ANTI REFLECTION TAMPER GLASS

This monitor set has a tough anti refection tampered glass. This offers the protection for the panel surface in the public display circum-

stance.

¡ALUMINUM CABINET & NON HOLES DESIGN

This monitor set uses Anodized aluminum and it has quite unique “Non-Holes” ventilation design which protect against mischief in the

public display applications and less maintenance from dust and oil circumstance, and having perfect protection of IP66 weather-resistant

approval.

Daylight readable monitor (CE42SR2, CE52SR2)

In addition to Weather proof monitor, it has adaptive brightness in accordance with prevailing light conditions.

¡EXTENSIVE INPUT & OUTPUT TERMINALS (for all products)

This monitor set has various input and output terminals including component (Y,Pb,Pr) or RGBHV input and output with 5-BNC, compos-

ite video input and output with BNC, and RS-232 control port (serial D-Sub 9) input and output which offer the daisy chain connection.

There are computer inputs (a D-Sub 15 RGB terminal) and DVI-D input with HDCP for High deﬁnition signals. There are also jacks for

external speakers.

Trademarks

Each name of corporations or products in this book is either a registered trademark or a trademark of its respective corporation.

GB GB

Produkt Specifikationer

Mærke:	Sanyo
Kategori:	Skærm
Model:	CE-52SR2
Bredde:	1304 mm
Dybde:	227 mm
Højde:	804 mm
Vægt:	83000 g
Produktfarve:	Sølv
Skærm diagonal:	52 "
Skærmopløsning:	1920 x 1080 pixel
HD-type:	Fuld HD
Skærmens lysstyrke:	970 cd/m²
Responstid:	8 ms
Synsvinkel, horisontal:	176 °
Synsvinkel, vertikal:	176 °
Opbevaringstemperatur (T-T):	-20 - 60 °C
Udgangseffekt (RMS):	8 W
Komponentvideo (YPbPr/YCbCr) indgang:	1
Udgange til hovedtelefoner:	1
Strømforbrug (typisk):	360 W
Driftstemperatur (T-T):	-20 - 40 °C
Indbygget kamera:	Ingen
Slot til kabellås:	Ingen
Billedformat:	16:9
Tilslutning af hovedtelefoner:	3,5 mm
Kontrastforhold (dynamisk):	2000:1
Pixel pitch:	0.6 x 0.6 mm
TV-tuner, integreret:	Ingen
Produktdesign:	Digital fladpaneldisplay
Antal DVI-D-porte:	1
