1 2 3 4 5
6
: - 90 °C temp. ºC. (Temp.) Select the temperature (: = cold)
- 1200*
(rpm)
Select the spin speed (*depending on the model) or (no final spin,
laundry soaks in the last rinsing water, display panel - - -)
1 - 24h (Finished in) Programme end after
Status displays Programme sequence displays:
þüüüücü-0- Wash, rinse, spin, programme duration or end (-0-)
$Childproof lock –> page 5
Open the washing machine door, reload laundry –> page 4, 5
End of programme when ...
... inicio (Start /Pause) flashes and -0- appears on the
display panel.
Interrupting the programme
Programmes at high temperatures:
– Cool washing: Choose (rinse).
– Press inicio (Start/Pause).
Programmes at lower temperatures:
– Choose (spin) or C (drain).
– Press inicio (Start/Pause).
Changing the programme, if ...
... you have selected the wrong programme by mistake:
– Reselect the programme.
– Press inicio (Start/Pause). The new programme starts
from the beginning.
Reloading laundry, if ... –> page 5
... Press inicio (Start/Pause), both the symbols YES and
+ are lit in the display panel. If NO is lit, the washing
machine door cannot be opened.
– Press inicio (Start/Pause).
Correct installation according to the
separate Installation instructions.
Checking the machine
– Never use a damaged machine.
– Inform customer service.
Connecting the mains plug
Make sure your hands are dry.
Take hold of the plug only.
Turning the tap on
Compartment II: Detergent for the main wash, water softener, bleach, stain remover
Sorting and loading laundry
Follow the manufacturer's care information.
According to the information on the care labels.
According to type, colour, soiling and temperature.
Do not exceed the maximum load -> page 7.
Observe the important information -> page 6.
Insert large and small items of laundry.
Close the washing machine door. Take care not to trap items of laundry
between the washing machine door and the rubber seal.
Add detergent and care products
Measure accordingly:
Amount of laundry, soiling, water hardness (ask your water supply
company) and manufacturer's instructions.
Pour liquid detergent into the appropriate dispenser and place in the drum.
Your washing machine
Congratulations ä You have opted for a modern, high-quality
domestic appliance manufactured by Siemens. The washing
machine is distinguished by its economical energy consumption.
Each machine that leaves our factory has been inspected thoroughly
to ensure that it functions properly and is in perfect condition.
Further information: http://www.siemens-homeappliances.com
Environmentally friendly waste disposal
All packaging must be disposed of in accordance with
environmental guidelines.
This appliance is certified in accordance with European Directive
2002/96/EEC on waste electrical and electronic equipment
(WEEE).
This directive provides the framework for the EU-wide collection and
reuse of used appliances.
Intended use
Contents Page
ʋIntended use .......................................................................................1
ʋProgrammes ........................................................................................1
ʋSetting and adjusting the programme ...........................................3
ʋWashing ...........................................................................................3/4
ʋAfter washing ......................................................................................4
ʋIndividual settings ..........................................................................5/6
ʋImportant information ...................................................................... 6
ʋOverview of programmes ................................................................7
ʋSafety instructions .............................................................................8
ʋConsumption values .........................................................................8
ʋCare .....................................................................................................9
ʋInformation on the display panel ....................................................9
ʋMaintenance .................................................................................... 10
ʋWhat to do if... .................................................................................. 11
Protection of the environment/Conservation tips
– Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
– Wash normally soiled laundry without a pre-wash.
– Instead of resistentes algod. (Cottons/clrds) 90 °C, choose the
programme resistentes algod. (Cottons/clrds) 60 °C with the
additional function ecoPerfect j. Comparable cleaning result
with significantly lower energy consumption.
– Measure the detergent according to the manufacturer's
instructions and water hardness.
– If the laundry is then dried in the tumble dryer, select the spin
speed according to the instructions of the dryer manufacturer.
Preparation
Before washing for the first time
Wash once without any laundry -> page 9.
Setting** and adjusting programmes
Display panel /
option buttons
Programme selector Start/Pause
(reload)
Programme selector for
switching the machine on
and off and for selecting
the programme. Can be
turned in either direction.
Programmes
Detailed overview of programmes -> page 7.
Temperature and spin speed can be selected individually, irrespective of the
selected programme and programme progress.
resistentes algod.
(Cottons/clrds)
Hard-wearing fabrics
+ prelav. (Prewash) Hard-wearing fabrics –> page 6
sintéticos (Easy-care) Easy-care fabrics
+ prelav. (Prewash) Easy-care fabrics –> page 6
mix (Mixed fabrics) Different types of laundry
delicado/seda (Delicates/silk) Delicate washable fabrics
ÿ lana/lã (Wool) Hand/machine-washable wool
(Rinse) With subsequent spin
centrifug. adicional (Spin) Laundry washed by hand
C (Drain) Drain rinsing water for
centrifug. adicional suave
(Gentle spin)
Laundry washed by hand with a reduced spin
speed
express 15 min. (Rapid) Short programme
microfibras (microfibre) All-weather, sports and outdoor fabrics –> page 6
camisas/business
(Shirt/blouse)
No-iron shirts
prendas oscuras/roupa
escura (Easy-care plus)
Dark-coloured fabrics
** If the $ symbol flashes in the
display panel, the childproof lock
is active -> deactivate, page 5.
Additional functions and options
buttons –> Individual settings,
page 5.
inicio (pausa + carga)
(Start/Pause)
Washing
1
2
Removing the washing
Open the washing machine door and remove the washing.
If c(without final spin) is active: Turn the programme
selector to C (Drain) or select the spin speed.
Press inicio (Start/Pause).
– Remove any foreign objects - risk of rusting.
– Leave the washing machine door and detergent
drawer open so that any residual water can
evaporate.
Turning the tap off
Not required for Aqua-Stop models –> Refer to installation
instructions
Switching off
Turn the programme selector to (Off).
Washing
Detergent drawer with
compartments I, II, ~
Washing machine
door
Compartment u: Fabric softener, starch
Compartment I: Detergent for pre-wash
ʋfor domestic use only,
ʋfor washing machine-washable fabrics and hand-wash-
able wool in detergent solution,
ʋto be operated with cold drinking water and commer-
cially available detergents and care products which are
suitable for use in washing machines.
.
– Do not leave children unattended near the
washing machine.
– The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
– Keep pets away from the washing machine.
Dilute viscous fabric softener and fabric conditioner with water.
This prevents blockages.
Individual settings
ʑ
Options buttons
You can change the spin speed and the temperature before the selected programme starts
and while it is running. The effects depend on the programme progress.
ʑ
temp. ºC (Temperature)
You can change the displayed washing temperature. The maximum selectable temperature
depends on the current programme.
ʑ
(spin speed in rpm)
You can change the displayed spin speed. The maximum selectable spin speed depends on
the model and on which programme is currently selected.
ʑ
(Finished in)
When you select the programme, the relevant programme duration is displayed. You can
delay the start of the programme before it begins. The "finished in" time can be set in
increments of one hour up to a maximum of 24 hours. Press the (finished in) button
repeatedly until the required number of hours is displayed (h = hour). Press inicio (Start/
Pause).
ʑ
Additional functions –> and overview of programmes, see page 7
speedPerfect iFor washing in a shorter time with a washing outcome comparable to
that of the standard programme. Maximum load –> Overview of
programmes, page 7.
ecoPerfect jFor saving energy with a washing performance comparable to that of
the standard programme.
menos
(Easy-iron)
Special spin sequence with subsequent fluffing. More gentle final spin
- residual moisture in the laundry slightly increased.
extra
(Extra rinse)
Additional rinse cycle. For areas with very soft water or for further
enhancing the spin result.
ʑ
Childproof lock and reloading
$
Childproof lock/
Appliance lock
You can lock the washing machine to prevent the functions you have
set from being changed inadvertently.
ON/OFF: Press and hold the inicio (Start/Pause) button for
5 seconds after the start/end of the programme.
Note: The childproof lock can remain activated until you wish to start
the next programme, even after switching off the machine.
Then you can deactivate the childproof lock before the start of the
programme and activate it again as necessary once the programme
has started.
YES + o
Reload
If you want to add subsequent items of laundry after the programme
has started, press the inicio (Start/Pause) button. The machine
checks whether reloading is possible.
YES + illuminated: Reloading is possible.
NO flashes: wait until YES + light up.
Note: do not open the door until both the YES + symbols are lit.
NO: It is not possible to reload.
Note: For safety reasons, the washing machine door remains locked
when the water level and/or temperature is high, or during spinning.
To continue the programme, press the
inicio (Start/Pause)
button.
ʑ
inicio (pausa + carga) (Start/Pause)
To start the programme or to subsequently load additional laundry, and to activate/deactivate
the childproof lock.
Individual settings
ʑ
Signal
Important information
Protecting the laundry and the machine
– Empty pockets.
– Look out for metal items (paperclips, etc.).
– Wash delicates in a laundry bag (tights, curtains, underwired bras).
– Fasten zips, do up any buttons.
– Brush sand out of pockets and collars.
– Remove curtain fittings or place in the laundry bag.
Laundry with varying degrees of soiling
Wash new items of clothing separately.
light Do not pre-wash. If required, choose the additional function speedPerfect i.
Pre-treat any stains as necessary.
intense Do not load as much laundry.
Choose a programme with pre-wash (pre-wash at 30 °C).
Soaking Load laundry of the same colour
Pour soaking agent/detergent into compartment II in accordance with the manufacturer's instructions. Turn the
programme selector to resistentes algod. (Cottons/clrds) 30 °C and press inicio (Start/Pause). After approx.
10 minutes, press inicio (Start/Pause) to pause the programme. Once the required soaking time has elapsed,
press inicio (Start/Pause) again to continue the programme, or select a different programme.
Starching Laundry must not be treated with fabric softener
Starching is possible in all wash programmes if liquid starch is used. Pour the starch in accordance with the
manufacturer's instructions into fabric softener compartment ~ (rinse first if necessary).
Dyeing/bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel. Always follow the dye
manufacturer's instructions! Do not use the washing machine for bleaching clothes!
Microfibras (Outdoor clothing) Laundry must not be treated with fabric softener
Special detergent is available for machine washing, particularly in sports shops. Dosage according to the manufacturer's
instructions. Place the special detergent for outdoor clothing in compartment II.
Turn the programme selector to microfibras (microfibre). Press Temperature and inicio (Start/Pause).
