Side 1/2

In case of an error the screen will display the error code as below:

WARNING AND ERROR MESSAGE

INTRODUCTION

Thank you for purchasing the eFUEL 1200W, 50A AC/DC Switching Power Supply V2. We are confident

that you will be very pleased with its performance because our AC/DC Switching Power Supply is

designed and manufactured by skilled professionals using the highest standard in workmanship. You can

be assured of many years of trouble-free service.

Your eFUEL AC/DC switching Power Supply is designed to use household AC power sources to power

devices that demand DC power. The eFUEL converts standard mains power of AC 100-240V to DC 15-

30V power and can supply up to 50 amperes of continuous power.

Dual DC output ports are converted from banana connectors to XT90 battery connectors. It gets more

convenient & safe to charge the most popular battery with the XT90 connector and avoid the possibilities

of reverse polarity.

INSTRUCTION MANUAL



1200W,50A AC/DC SWITCHING

POWER SUPPLY V2

SK-200015

AC Power

Input

Power

Switch

AC INPUT

100-240V

OFF

Temp. Controlled Fan

CAUTION:

Check the AC Voltage

Before POWER ON

Cooling

Fan

Two main DC outputs(up to 50 amperes), three output(up to 10 amperes each) with ON/OFF switch.

Output voltage adjustable: 15-30V.

LCD indicates output voltage and current.

AC 100-240V worldwide operation: need not any alternative switcher, worldwide safe operation.

Two USB ports: 5V/2.1A total for iPad, smart phone, digital cameras and etc.

Smart cooling fans: automatic temperature control.

Over-current, over-voltage, over-load and over-temperature protection.

FEATURES

Over temperature protection. Over current protection. Over power protection.

The power supply's overload protection circuit automatically shuts down the power supply when overloaded. To reset the

power supply, please TURN OFF the power supply, reduce the load after warning signs disappear, then TURN ON.

If OCP or OPP shows on the LCD screen, switch off the power, reduce the load after warning signs disappear, then turn

on again.

Helpful Tip:

When this unit is working with Revolectrix Cellpro Power Lab 8, to maximize its efficiency without damaging eFuel

1200W and Power Lab 8, please set the Power Source of Power Lab 8 as following:

5V/2.1A

USB Port

Cooling

Fan

Current & Voltage

Readout

Voltage Adjustment Dial

(15V-30V)

Dual DC Output

(Max. 50A)

Three deputy outlet

(Max. 10A)

OPERATION

Please check all connections and confirm the wall AC outlet has power before switching on the power supply.

The LCD will display the actual output voltage and current. If the voltage is NOT suitable for your charger or other

devices, use the rotary dial to adjust the output voltage.

Output PowerChart

Output Voltage(V)

Max Current(A)

Max Power(W)

1150

1200

50.0

48.0

46.2

44.4

42.9

41.4

40.0

Output Voltage(V)

Max Current(A)

Max Power(W)

50.0

750

800

850

900

950

1000

1050

1100

To take full advantage of eFUEL 1200W’s capability, the output voltage should be 24V DC or higher. Per Ohm’s law,

24V x 50A = 1200W. Therefore, if you want to attain 1200W of output power, the output voltage must be set to 24V or

higher.

The actual amount of output current is also limited to 1200 Watts. If the output voltage is 30V, the max current is 40A.

Warning: Don’t adjust the output voltage when the power supply is working.

Or damage may occur to the charger.

Warning:

Output

Voltage

Output

Current

Output voltage

adjustable 15-30V

Press and hold the rotary dial for 3 seconds, and the output voltage value will start to blink, then turn the dial clockwise

or counter-clockwise to change the value, press the dial rotary once to confirm the desired value.

If you don’t press the rotary to confirm for 5 seconds during the process, the power supply will take the present

value as your selected automatically.

NOTE:

How to Adjust the Output Voltage?

1. Ensure the power switch is OFF

2. Connect the load to the POWER SUPPLY

3. Plug the Power Supply into an AC outlet

4. Turn the power switch ON

P o w e r S o u r c e

> D C P o w e r S o u r c e

S u p p l y C u r r e n t

L i m i t ? > 4 0 . 0 A

L o w S p l y L i m i t ?

> 2 4 . 0 V
