Contents

1. Precautions for safety and use ________________________ 20

2. Fitting the appliance in the top ________________________ 21

2.1 _______________________________________21 Fixing to the supporting structure

2.2 Fitting the adhesive foam rubber strip ____________________________________22

2.3 _________________________________________________22 Fitting the ﬁxing clips

2.4 Fitting the hob into the hole in the work- top________________________________22

3. Electrical connection ________________________________ 23

4. Gas connection ____________________________________ 24

4.1 _______________________________________________24 Bottled gas connection

4.2 ____________________________________________________24 Room ventilation

4.3 ____________________________________________24 Combustion gas discharge

5. Adapting to different types of gas ______________________ 25

5.1 _______________________________________________25 Removing the hob skin

5.2 ______________________________________________26 Adjusting for bottled gas

5.3 ______________________________________________26 Adjusting for natural gas

5.4 Adjusting the primary air ﬂow ___________________________________________26

5.5 ____________________________________________27 Reassembling the hob skin

5.6 ______________________________27 Adjusting the minimum setting for natural ga

5.7 ____________________________________27 Adjusting the minimum for bottled gas

5.8 ___________________________________________________27 Hob burner layout

5.9 ________________________________________________27 Greasing the gas taps

6. Description of controls ______________________________ 28

6.1 The front panel ______________________________________________________28

7. Using the hob _____________________________________ 29

7.1 ________________________________________________29 Fitting the pan stands

7.2 ______________________________________32 Lighting burners with safety device

7.3 _____________________________________32 Practical hints for using the burners

7.4 ______________________________________________________32 Pan diameters

8. Cleaning and maintenance ___________________________ 33

8.1 ____________________________________________________33 Cleaning the hob

8.2 Cleaning instructions for an acid-etched glass hob __________________________33

8.3 _____________________________________________33 Cleaning the components

THESE INSTRUCTIONS ONLY APPLY TO THE COUNTRIES OF DESTINATION WHOSE

IDENTIFICATION SYMBOLS ARE LISTED ON THE COVER OF THIS MANUAL.

THIS BUILT-IN HOB IS CLASSIFIED AS CLASS 3.

INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualiﬁed

engineer who is to check the gas supply system and install, commission and test the

appliance.

INSTRUCTIONS FOR THE USER: these provide recommendations for use, a

description of the controls and the correct procedures for cleaning and maintaining the

appliance.

Further information about the products can be found at www.smeg.com

Precautions for Safety and Use

1. Precautions for safety and use

THIS MANUAL IS AN INTEGRAL PART OF THE A LIANCE. TAKE GOOD CARE OF IT AND KEEP IT PP

TO HAND THROUGHOUT THE HOB'S LIFE CYCLE. USERS ARE ADVISED TO READ THIS MANUAL

AND ALL THE INSTRUCTIONS IT CONTAINS BEFORE USING THE HOB. ALSO KEEP THE SET OF

NOZZLES PROVIDED IN A SAFE PLACE. INSTALLATION MUST BE CARRIED OUT BY QUALIFIED

STAFF IN COMPLIANCE WITH THE RELEVANT REGULATIONS. THIS APPLIANCE IS INTENDED FOR

HOUSEHOLD USE AND COMPLIES WITH THE CURRENTLY IN FORCE. THE EEC DIRECTIVES

APPLIANCE IS BUILT TO PROVIDE THE FOLLOWING FUNCTION: COOKING AND HEATING FOODS;

ALL OTHER USES ARE TO BE CONSIDERED IMPROPER.

THE MANUFACTURER DECLINES ALL LIABILITY FOR USES OTHER THAN THOSE STATED ABOVE.

NEVER LEAVE PACKAGING RESIDUES UNATTENDED IN THE HOME. SEPARATE WASTE

PACKAGING MATERIALS BY TYPE AND CONSIGN THEM TO THE NEAREST SEPARATE DISPOSAL

CENTRE.

IF CRACKS OR FISSURE FORM, OR IF THE GLASS CERAMIC COOKING SURFACE BREAKS, TURN S

OFF THE APPLIANCE IMMEDIATELY. DISCONNECT THE POWER SUPPLY AND CALL TECHNICAL

SUPPORT.

THE APPLIANCE MUST BE CONNECTED TO EARTH IN COMPLIANCE WITH ELECTRICAL SYSTEM

SAFETY REGULATIONS.

THE PLUG TO BE CONNECTED TO THE POWER SUPPLY LEAD AND THE RELATIVE SOCKET MUST

BE OF THE SAME TYPE AND COMPLY WITH THE RELEVANT REGULATIONS.

THE POWER SUPPLY SOCKET MUST BE ACCESSIBLE EVEN AFTER THE APPLIANCE HAS BEEN

BUILT- . IN

NEVER DISCONNECT THE PLUG BY PULLING ON THE POWER SUPPLY LEAD.

IMMEDIATELY AFTER INSTALLATION, CARRY OUT A QUICK TEST ON THE HOB FOLLOWING THE

INSTRUCTIONS PROVIDED LATER IN THIS MANUAL. IF THE APPLIANCE FAILS TO OPERATE,

DISCONNECT IT FROM THE ELECTRICAL MAINS AND CONTACT YOUR NEAREST SERVICE

CENTRE.

NEVER ATTEMPT TO REPAIR THE APPLIANCE YOURSELF.

AFTER EACH USE OF THE HOB, ALWAYS CHECK THAT THE CONTROL KNOBS ARE TURNED TO

"ZERO" (OFF).

NEVER PLACE PANS WITH BOTTOMS WHICH ARE NOT PERFECTLY FLAT AND SMOOTH ON THE

HOB PAN STANDS.

NEVER USE PANS OR GRIDDLE PLATES WHICH PROJECT BEYOND THE OUTSIDE EDGE OF THE

HOB.

THE NAMEPLATE WITH THE TECHNICAL DATA, SERIAL NUMBER AND MARK IS IN A VISIBLE

POSITION UNDERNEATH THE CASING, ANNEXED TO THIS MANUAL AND APPLIED TO THE QUALITY

CERTIFICATE.

THIS NAMEPLATE MUST NEVER BE REMOVED.

THE APPLIANCE IS INTENDED FOR USE BY ADULTS. KEEP CHILDREN AT A SAFE DISTANCE AND

NEVER ALLOW THEM TO PLAY WITH IT.

THIS APPLIANCE IS TAGGED UNDER EUROPEAN DIRECTIVE 2002/96/EC ON WASTE ELECTRICAL

AND ELECTRONIC EQUIPMENT (WEEE).

THIS DIRECTIVE CONTAINS THE REGULATIONS VERNING THE COLLECTION AND RECYCLING GO

OF DECOMMISSIONED APPLIANCES THROUGHOUT THE EUROPEAN UNION.

The manufacturer declines all responsibility for injury or damage caused by failure to comply

with the above regulations or deriving from tampering with even just one part of the appliance

and the use of non-original spare parts.
