Smeg TR103IP2 Manual

Smeg Komfur TR103IP2

Læs gratis den danske manual til Smeg TR103IP2 (27 sider) i kategorien Komfur. Denne vejledning er vurderet som hjælpsom af 37 personer og har en gennemsnitlig bedømmelse på 4.8 stjerner ud af 19 anmeldelser. Har du et spørgsmål om Smeg TR103IP2, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/27

PRECAUTIONS - 3391477A162/C

PRECAUTIONS 33

General safety instructions 33

Installation 37

Appliance purpose 38

This user manual 38

Manufacturer’s liability 38

Identification plate 38

Disposal 38

Information for European Control Bodies 39

Energy efficiency technical data 39

To save energy 39

Light sources 39

How to read the user manual 39

DESCRIPTION 40

General description 40

Hob 40

Control panel 41

Other parts 42

Accessories 42

USE 43

Preliminary operations 43

Using the accessories 43

Using the hob 44

Using the storage compartment (where present) 46

Using the oven 46

Digital programmer 47

Cooking advice 49

Cooking information table (multifunction oven) 50

Cooking information table (auxiliary oven) 51

Cooking information table (vertical oven) 51

CLEANING AND MAINTENANCE 52

Cleaning the appliance 52

Cleaning the glass ceramic hob 52

Knobs 52

Cleaning the door 52

Cleaning the oven cavity 54

Cleaning the roof of the oven (only for some

models/cavities) 55

Vapor Clean (on some models only) 55

Extraordinary maintenance 56

INSTALLATION 57

Positioning 57

Electrical connection 59

Instructions for the installer 59

We advise you to read this manual carefully, which contains all the instructions for maintaining the

appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com

PRECAUTIONS

General safety instructions

Risk of personal injury

• During use the appliance and

its accessible parts become

very hot. Keep children well

away from the appliance.

• The appliance becomes very

hot during use. Make sure that

you never touch the heating

elements inside the oven.

• Protect your hands by wearing

oven gloves when moving food

inside the oven.

• Never try to put out a fire or

flames with water: Turn off the

appliance and smother the

flames with a fire blanket or

other appropriate cover.

• This appliance may only be

used by children aged 8 years

and over, and by people of

reduced physical, sensory or

mental capacity, or lacking in

experience in the use of

electrical appliances, provided

that they are supervised or

have been given instructions on

the safe use of the appliance

and of the hazards associated

with it.

• Children must not play with the

34 - PRECAUTIONS 91477A162/C

appliance.

• Keep children under the age of

eight at a safe distance unless

they are constantly supervised.

• Keep children under the age of

8 away from the appliance

when it is in use.

• Cleaning and maintenance

must not be carried out by

unsupervised children.

• Be aware of how rapidly the

cooking zones heat up. Do not

place empty pans on the heat.

Danger of overheating.

• After use the cooking zones

remain hot for a certain period

of time after they have been

turned off. Do not touch the hob

surfaces.

• The cooking process must

always kept under control. A

short cooking process must be

continuously monitored.

• WARNING: Leaving food that

contains fat and/ oil

unattended when cooking can

be dangerous and can cause a

fire. DO NOT attempt to

extinguish a fire with water. Turn

off the appliance and smother

the flames, for example with a

lid or a blanket.

• Do not use the Booster and/or

the Double Booster functions (if

present) to heat fats or oils. Fire

hazard.

• Do not place metal objects,

such as dishes or cutlery, on the

surface of the hob during

cooking as they may overheat.

• Do not cook foods in closed

tins or containers or plastic

containers.

• Do not insert pointed metal

objects (cutlery or utensils) into

the slots in the appliance.

• Do not use or store flammable

materials near the appliance.

• Do not pour water directly onto

very hot trays.

• Keep the oven door closed

during cooking.

• If you need to move food or at

the end of cooking, open the

door 5 cm for a few seconds,

let the steam come out, then

open it fully.

• Do not open the storage

compartment (where available)

when the oven is on and still

hot.

• The items inside the storage

compartment (where available)

could be very hot after the oven

has been used.

• Switch off the appliance

immediately after use.

• Do not pull the cable to unplug

the appliance (if present).

• DO NOT USE OR STORE

FLAMMABLE MATERIALS IN

THE STORAGE

COMPARTMENT (IF

AVAILABLE) OR NEAR THE

APPLIANCE.

• DO NOT USE AEROSOLS IN

THE VICINITY OF THIS

APPLIANCE WHILST IT IS IN

Produkt Specifikationer

Mærke:	Smeg
Kategori:	Komfur
Model:	TR103IP2
Afrimningsfunktion:	Ja
Bredde:	1000 mm
Dybde:	600 mm
Højde:	900 mm
Vægt:	121400 g
Produktfarve:	Cremefarvet
Kontroltype:	Knapper
Lampe type:	Halogen
Produkttype:	Range komfur
Strøm:	43 A
Pakkevægt:	133100 g
Pakkedybde:	670 mm
Pakkebredde:	1060 mm
Pakkehøjde:	1015 mm
Indvendig belysning:	Ja
Genopvarmningsfunktion:	Ingen
Grill:	Ja
Damp madlavning:	Ingen
Rotisserie:	Ingen
Børnesikring:	Ja
Selvrensende:	Ingen
Komfurtype:	Zone induktionskogeplade
Antal kogeplader / madlavningsområde:	5
Antal elektriske kogeplader:	5
Blus/kogeplade zone 1 strøm:	1300 W
Blus/kogeplade zone 2 strøm:	2300 W
Blus/kogeplade zone 1 strømkilde:	Elektrisk
Blus/kogeplade zone 2 strømkilde:	Elektrisk
Gryde detektering:	Ja
Blus/kogeplade zone 2 diameter:	180 mm
Blus/kogeplade zone 1 diameter:	130 mm
Blus/kogeplade zone 3 diameter:	270 mm
Blus/kogeplade zone 4 diameter:	180 mm
Blus/kogeplade zone 4 strømkilde:	Elektrisk
Blus/kogeplade zone 3 strømkilde:	Elektrisk
Energieffektivitetsklasse:	A
ECO-tilstand:	Ja
Antal glasdørpaneler:	3
Varmebeskyttende dør:	Ja
Kølende ventilator i døren:	Ja
Antal ovne:	3
Ovn nettokapacitet:	61 L
Pizza fremstillingsfunktion:	Ingen
Energieffektivitetsindeks (EEI):	95.1
Strømledning inkluderet:	Ja
Oprindelsesland:	Italien
Hurtig varme:	Ingen
Udtrækkelige drejeknapper:	Ingen
Blæser grillfunktion:	Ja
Grill med fuld overflade:	Ingen
Antal hylder:	1 hylder
Aftagelig dørglas:	Ja
Bund opvarmning:	Ingen
Top opvarmning:	Ingen
Langsom madlavning:	Ingen
Blus/kogeplade zone 5 strømkilde:	Elektrisk
Blus/kogeplade zone 4 strøm:	1300 W
Blus/kogeplade zone 5 diameter:	210 mm
Blus/kogeplade zone 5 strøm:	2300 W
Blus/kogeplade zone 3 strøm:	2300 W
Elektronisk tænding:	Ingen
Komfurlåg:	Ingen
Boost funktion:	Ja
Ovn strømkilde:	Elektrisk
Ovn samlet kapacitet:	70 L
Wokbrænder:	Ingen
Ovn 2 størrelse:	Stor
Ovn 2 nettokapacitet:	84 L
Ovn 2 strømkilde:	Elektrisk
Ovn 2 energieffektivitetsklasse:	B
Indvendig belægning:	Emalje
3D varmluft:	Ingen
Ovndør materiale:	Glas
Teleskopiske hylder:	Ja
Ovn 2 antal hylder:	4 hylder
Ovn 2 interiør belysning:	Ja
Ovn 2 dørmateriale:	Glas
Ovn 2 antal glasdørepaneler:	2
Ovn 2 grill:	Ingen
Ovn 2 bundvarme:	Ingen
Ovn 2 aftageligt glas i låge:	Ja
Ovn timer:	Ja
Stegeplade:	Ingen
Grill med blæser:	Ingen
Antal funktioner:	5
Ovntilberedningsmetode:	Blæserassisteret
Nem at rengøre (ovn):	Ja
Wok ring:	Ingen
Ovn 2 antal funktioner:	1
Ovn 2 teleskopiske hylder:	Ingen
Ovn 3 nettokapacitet:	36 L
Ovn 3 størrelse:	Lille
Ovn 3 strømkilde:	Elektrisk
Ovn 3 antal funktioner:	1
Ovn 3 grill:	Ja
Ovn 3 langsom madlavning:	Ingen
Ovn 3 holde varm funktion:	Ingen
Ovn 3 antal hylder:	1 hylder
Ovn 3 interiør belysning:	Ja
Ovn 3 dørmateriale:	Glas
Ovn 3 teleskopiske hylder:	Ingen
Ovn holde-varm funktion:	Ingen
Bundvarme & blæser:	Ingen
Ovn 3 konvektionstilberedning:	Ingen
Ovn 3 afrimningsfunktion:	Ingen
Ovn 3 antal glasdørepaneler:	3
Ovn 3 konventionel tilberedning:	Ingen
Ovn 3 blæser grillfunktion:	Ingen
Gas omdannelsessæt:	Ingen
Ovn 2 topvarme:	Ingen
Ovn 2 top og bund varme:	Ja
Ovn 2 rotisserie:	Ingen
Teppanyaki:	Ingen
Nem at rengøre (blus):	Ja
Lukket låge grillning:	Ja
Katalytiske foringer på sidevægge:	Ingen
Ovn 2 afrimningsfunktion:	Ingen
Ovn 2 holde varm funktion:	Ingen
Ovn 2 top, bund & blæser:	Ja
Ovn 2 genvarmefunktion:	Ingen
Halv grill:	Ingen
Åben låge grillning:	Ingen
Ovn 2 damptilberedning:	Ingen
Ovn 2 katalytiske foringer på sidevægge:	Ingen
Ovn 3 aftageligt glas i låge:	Ja
Ovn 3 katalytiske foringer på sidevægge:	Ingen
Vippegitter:	Ja
Baseopvarmning & blæser:	Ja
Ovn 2 blæser grillfunktion:	Ingen
Ovn 2 langsom madlavning:	Ingen
Ovn 3 topvarme:	Ingen
Ovn 3 top, bund & blæser:	Ingen
Ovn 3 bundvarme:	Ingen
Ovn 3 basisvarme & blæser:	Ingen
Ovn 2 halv grill:	Ingen
