Side 1/2
HD1TCS
High Definition traditional Style Camera
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
2. Features
4. OSD Menu
①Switch for Selection of Video out / SDI out
②Video output for Test Monitor
③Power(12V DC / GND)
④HDcctv 1.0 OUTPUT
⑤OSD Button (UP/DOWN/LEFT/RIGHT/SET)
⑥Power LED
3. Controller
①
①
①
①①
②
②
②
②②
③
③
③
③③
④
④
④
④④
Main Menu
Lens ▷
▷
▷
▷▷
Shutter ▷
▷
▷
▷▷
BLC ON
AGC MID
White Balance ▷
▷
▷
▷▷
Adjust ▷
▷
▷
▷▷
Reset ▷
▷
▷
▷▷
Return
* Lens
-DC : DC Lens Type Setting
IRIS ADJ [ Value] : IRIS Open Level Control
Only Operate when DC lens is active
- Manual : Manual Lens Type Setting
- Return : Function Back
*Shutter
-Flicker : This function triggers the screen in the 50Hz power range, preventing the
screen flicker that can result from the dissonance of vertical
synchronization frequency and blink frequency.
- Auto : Only Operate when Manuals Lens is active
- Manual : 1/30, 1/60, 1/600, 1/1200, 1/6000, 1/12000
- Return : Function Back
* BLC
- Provides light level control to overcome severe back light condition
* AGC
- OFF / LOW / MID / HIGH
* White Balance
- AWB : Auto White Balance Mode Setting
- Fixed[Value] : 2300,3100,5000,6800
- Manual : White Balance Mode Manual Setting
R-Gain [Value] : R-Gain Value Control
B-Gain [Value] : B-Gain Value Control
-Return : Function Back
* Adjust
- Sharpness [Value] : Sharpness Control
- Brightness : Adjust a brightness setting of monitoring status
- Contrast : Adjust a contrast of monitoring status
- Day / Night : [Auto]
[Color]
[B/W]
- Return : Function Back
* Reset
- Would you like to reset? Yes or No
* 1/3” Sony 720P HD CMOS Sensor (Megapixel Resolution)
* HDcctv 720p30 Video Output (1.5Gb/S Digital over coax)
* Video Output for Test Monitor
* True Mechanical Day / Night (ICR)
* Min. Illumination – Color : 0.2Lux, F1.2 / B/W : 0.01Lux, F.1.2
* Install using RG 59cable & BNC connectors
* 5 year warranty
⑤
⑤
⑤
⑤⑤
⑥
⑥
⑥
⑥⑥
4. OSD Menu Details
1. Package Contents
1 HD1TCS camera
1 Mounting Adapter
2 Screw
1 Wrench
HD1TCS
High Definition traditional Style Camera
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
6. SPECIFICATIONS 7.DIMENSIONS
Item
HD1TCS
Image Sensor
1/3" Sony CMOS
Total Pixels
1384(H)x1076(V) approx. 1.49M Pixel
Effective Pixels
1329(H)x1049(V) approx.1.39M Pixel
Recommended Pixel
1280(H)x1024(V) approx.1.31MPixel
Video Format
Progressive Scan
Sync Format
Internal Sync
Recommended Lens
F Number: 2.8 or More
S/N Ratio
50dB or More
AGC
OSD support
Day/Night
OSD support
Lens Mount
C/CS Mount
Application Lens
DC / Manual
Video Output
720P 30HZ
Video Output Format
1.5G/s Digital over Coax
Power Source
12Volts DC
Power Consumption
400mA / 12Volts DC
Operational Temperature
-14℉
℉
℉
℉℉ to 122℉
℉
℉
℉℉
Control
Key Button
Weight
600g
Dimension
66mm(H)x66mm(W)x134.5mm(L)
66
66
Front View
134.5
Side View
Unit : mm
Rev.101020
Speco Technologies is constantly developing product
improvements. We reserve the right to modify product
design and specifications without notice and without
incurring any obligation.
