Side 1/2

1 2

P16S18G - 16- - - Port Gigabit PoE + 2 Port Gigabit SFP + 2 Port Gigabit Copper Ethernet Switch

User Manual

Packing List

Open the product box and carefully unpack all contents box should contain the following items. . The

Please check before installation, if any missing, please contact your distributor immediately. are

Items Quantity

Switch 1 pc

AC Power Cable 1 pc

Mounting Accessories 1 set

Quick Installation Guide 1 pc

Product Introduction

This providswitch es sixteen - -Gigabit Ethernet RJ 45 downlink ports, two Gigabit Ethernet RJ 45 uplink

ports and two Gigabit SFP uplink ports. All RJ 45 downlink ports support Power Ethernet (PoE+) - -over-

and deliver up to 30W power per port.

The switches in three modes: default, VLAN, and flow control. It can be widely used in video work

security monitoring systems, network projects, etc.

Hardware Introduction

Dimensions (mm)

────────◀

◀

◀◀◀

◀

◀◀◀

◀

◀◀

16-Port Gigabit PoE + 2-Port Gigabit SFP + 2-Port Gigabit Copper Ethernet Switch

Front Panel (16 Port PoE Switch)-

Rear Panel (16- Port PoE Switch)

Led Indicators

Indicators Descriptions Status

Power Power Supply Indicator

On The Main Power Supply is working.

Off The Main Power Supply is off.

Link Port Link Indicator

On The port is linking normally.

Blink The port is transmitting or receiving data.

Off The port links down.

PoE Port PoE Indicator

On The port is supplying PoE normally.

Off The port stopped supplying PoE.

DIP Switch

Status Descriptions

Default Default mode. All ports are free to communicate

VLAN Downlink ports are isolated from each other, but can communicate with uplink ports

Flow control E s nable flow control function, this mode is suitable for video surveillance transmission

Note:

After changing the mode, please power on the device again to enter the corresponding mode.

16 Gigabit PoE + 2-Port -Port Gigabit SFP + 2-Port Gigabit Copper Ethernet Switch

▶

▶▶▶

▶

▶▶▶

▶

▶▶────────

────────◀

◀

◀◀◀

◀

◀◀◀

◀

◀◀

16-Port Gigabit PoE + 2-Port Gigabit SFP + 2-Port Gigabit Copper Ethernet Switch

3 4

Installation Steps

1) Before installation, please disconnect the power supply of each signal source and equipment. Live

installation may damage the transmission equipment.

2) The switch supports 19-inch rack, desktop and wall-mounted installations. Users can install the

switch in a rack, or place it on a clean, stable, grounded workbench, or on a vertical, stable wall.

The 19-inch rack installation steps are shown in the following table:

Step 1: Fix the hangers on the side of the switch.

Accessories

Step 2: Install the switch on the rack with screws in the package.

Accessories

Step 3: Continue to install other devices in the rack. The distance

between the devices should be more than 5cm.

Accessories

N/A

3) After step 2) is completed, please use Cat5 or thicker cables to connect the switch and the device.

4) Check the installation and the wiring, after confirming that the connection is correct and reliable,

power on the switch.

The installation is complete.

CAUTION

 Power on the system only after confirming that the wiring is correct, to avoid damage to the

equipment.

 connect For better transmission performance, it is recommended to use Cat5 or better cables to

the switch and powered devices.

 to For better protection performance, it is recommended always make the ground connection first

and disconnect it at the end when operating the unit.

 -Each PoE RJ 45 port can provide a maximum power of 30W for a powered device. Please do not

connect to a powered device with a power exceeding 30W.

 id Before operating or maintaining the switch, please read the user manual carefully to avo

equipment damage caused by misoperation.

Specifications

Items UTP3- - GSW1604TS P200

Ethernet Ports

Downlink Ports 16*10/100/1000 Base- - - - T PoE RJ 45 (Auto MDI/MDI X)

Uplink Ports

2*10/100/1000 Base- - - -GBIC) T RJ 45，2*1000 Base X SFP(Mini

PoE

PoE Standard

IEEE 802.3af/at

（

PSE

）

PoE Power Supply Type

End- span

PoE Pin Assignment + - 1/2（）, 3/6（）

PoE Power Output

54V DC

PoE Power

30W max for each port, 175W max

Switch Property

Standards

IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3X

Forwarding Modes Store and Forward

Packet Buffer

4Mbyte

MAC Table

Switching Capacity 40Gbps / non-blocking

Packet Forwarding Rate

28Mpps

Power Supply

Input Voltage 100V~240V AC, 50/60Hz

Power Consumption 200W (Including PoE)

Reliability

Surge Immunity 6kV, Standard: IEC6000-4-5

ESD 6 kV Contact Discharge, 8kV Air Discharge, standard: IEC61000-4-2

Operating Temperature

14F~122F (-10C to 50C)

Storage Temperature -40 85F~1 F (-40C to 85C)

Operating Humidity

5%~95% (Non-condensation)

Physical Parameters

Led Indicators

1*PWR Indicator

16*Downlink Port Link Indicators

16*Downlink Port PoE Indicators

4*Uplink Port Link Indicator

Dimension(W*D*H)

17.4” 11.2” 442mm*x x 1.7” ( 285 ) mm*44mm

Gross Weight

11 Lbs.(5000g)

Net Weight 8.4 Lbs. ( 3800g)

Material

Metal

Installation

Rack mounted/ wall mounted desktop/

Certifications

CE, FCC

Speco Technologies is constantly developing and improving products. REV: 12/21/2020 –

We reserve the right to modify product design and specifications without notice and without incurring any obligation.

Speco Technologies . 200 New Highway . Amityville . NY . 11701 . www.specotech.com
