Thank you for purchasing your SMARTSCAN inducon cooker by Sunpentown. Make full use of
your new inducon range. Please carefully read this manual and keep on hand for future
l Please plug this cooktop in the correct 15-amp outlet.
l Do not share the outlet with other appliances and make sure
it is correctly plugged in.
l Do not touch the ceramic plate immediately aer cooking,
the plate may remain hot due to heat transferred from the
l Do not insert any object in the inlet or outlet to prevent
l Do not damage the ceramic plate.
l If the ceramic plate is broken, please turn unit off and unplug from outlet
l If the electric cord is damaged, please contact our service technician for a
l This appliance is equipped with overheat protecon feature.
l Those with a pacemaker should consult they physician before using this
l If the cooktop surface is broken or cracked, do not use the product as it may
If the cooktop is not working properly, please contact our service technician for
assistance. Do not disassemble the unit by yourself.
LIST OF SUITABLE / UNSUITABLE COOKWARE
B. Do not touch hot surfaces. Use handles or knobs.
C. To protect against electrical shock, do not immerse cord or appliance in
D. Close supervision is necessary when any appliance is used by or near
E. Unplug from outlet when not in use and before cleaning. Allow to cool
before pung on or taking off parts.
F. Do not operate any appliance with a damaged cord or plug or aer the
appliance malfuncons or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examinaon, repair
G. The use of accessory aachments not recommended by the appliance
manufacturer may cause injuries.
I. Do not let cord hang over edge of table or counter, or touch hot surfaces.
J. Do not place on or near a hot gas or electric burner, or in a heated oven.
K. Extreme cauon must be used when moving an appliance containing hot
oil or other hot liquids.
L. Always aach plug to appliance first, then plug cord into the wall outlet. To
disconnect, turn any control to “off”, then removed plug from wall outlet.
M. Do not use appliance for other than intended use.
N. Save these instrucons.
lThe cooktop can be surface-mounted into
lThe cooktop can be flush with the countertop
P
P
P
PPO
O
O
OOW
W
W
WWE
E
E
EER
R
R
RR
S
S
S
SSR
R
R
RR-
-
-
--1
1
1
110
0
0
008
8
8
88M
M
M
MMR
R
R
RR
S
S
S
SSR
R
R
RR-
-
-
--1
1
1
11 08
08
08
0808 M
M
M
MMR
R
R
RR
l Always place cookware or other objects on the top plate gently as the ceramic plate may
l Please use suitable cookware, otherwise abnormal cooking or damage may occur.
l The self-protect circuit will protect the unit when power supply is unstable. The red
power light will be flashing and cooking will stop.
KEY POINTS BEFORE USING THE COOKTOP
Do not put heated oil in the pan while
Keep away from water source;the cooktop
will not work if the air inlet and the air outlet
credit card,disc,watch or radio.
Place cooktop on flat surface,but keep away from
the wall or other arcles. for best results,leave
at least 4 inches from all sides.
When the air inlet or the air outlet is blocked,
high,cooktop will stop heang.
Page 1 Important Safeguards–
Page 3 Installaon of Control Box –
Page 4 Installaon of Inducon Burner/Range–
Page 6 Key Points Before Using the Cooktop–
Page 7 List of Suitable & Unsuitable Cookware–
INSTALLATION OF INDUCTION BURNER/RANGE
Install in Counter Top/Table.Unit: inch.
Please allow 4 inch ventilation each side.
1. Plug in power cord (120V / 60Hz) - unit will beep once. ON/OFF indicator light will
2. Place suitable cookware and add food contents.
4. Select 650W or 1000W by pressing the Power buon(1000W model only).
Note: This is the heang power used to reach your hold temperature. Unit default is
5. Press the C/F buon to switch temperature display from Celsius to Fahrenheit
(or vice versa), turn control knob to select the temperature.
6. When done, turn unit off by pressing ON/OFF buon.
20 Hold temperature sengs:
l Safety feature: if no cookware is placed, unit will shut off aer 2 minutes.
l To avoid temperature jump, please cook at least 1 quart of food/content.
l Actual temperature may vary slightly due to different variables,
such as: surrounding temperature, content and volume of food, and if using a lid,
l Use flat cookware and place in center of plate.
l When using cookware that is not flat or with an uneven boom, the set temperature
will be VERY different from the actual temperature.
l If content is thick/creamy, we suggest heang at 650W.
90 110 130 150 170 180 200 220 240 260
270 290 310 330 350 360 380 400 420 440
165 176 182 193 204 215 226
l Unplug the cord before any cleaning is done.
l To clean the ceramic plate, use a so sponge with dish detergent. Then
wipe clean with damp towel.
l Clean fan intake with vacuum whenever necessary.
DO NOT IMMERSE THE COOKTOP IN WATER TO SOAK. THIS
Is the pan be placed on the induction
cooker? Or is it an induction compatible
Check if the voltage is low
Check if the voltage is high
Check if the IGBT sensor or relevant circuit was
Circuit board inner fan was broken or
the air inlet is blocked.
Check if the coil temperature sensor cable was
broken, or the plug is unplug.
Check the circuit board if the components
Warning: Changes or modificaons to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a consumer
ISM equipment. These limits are designed to provide reasonable protecon against
harmful interference in a residenal installaon.This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the
instrucons, may cause harmful interference to radio communicaons. However, there
is no guarantee that interference will not occur in a parcular installaon.If this
equipment does cause harmful interference to radio or television recepon, which can
be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separaon between the equipment and receiver.
lConnect the equipment into an outlet on a circuit different from that to which the
lConsult the dealer or an experienced radio TV technician for help.
This device complies with part 18 of the FCC rules.
Operaon is subject to the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operaon.
12.60” x 13.4” x 3.94” (H)
Overheat protecon. Automac hazard detecon. Circuit protecon sensor.
High voltage. 20A fuse. Small object heat prevenon. Thermostat. Pan
If this product is found to be faulty as a result of faulty materials or
workmanship within one year from date of purchase, it will be repaired
This guarantee is subject to the following terms:
Sunpentown must be nofied of the fault. l
Proof of purchase must be presented to Sunpentown’s nominated representavel
The warranty will be void if the product if modified, misused or repaired by an l
The warranty aer repair will not be extended beyond the original one-year l
All replacement parts will be new or recondioned. l
Parts, which are replaced, become the property of Sunpentown. l
The warranty applies for the use of the product in the USA only. l
Warranty does not include freight charges. l
Incidental or consequenal damage caused by possible defects with this product. l
Damage to product caused by improper power supply voltage, accident,fire, l
Failure of product resulng from unauthorized modificaons to the product. l
Improper installaon or failure to perform the necessary maintenance. l
SUNPENTOWN INTERNATIONAL INC.
14625 Clark Ave. City of Industry, CA 91745
This GUARANTEE is in addion to your Statutory Rights
