SR-18AC/SR-18BC/SR-18CC(110-120V/1800W)
SR-34AC/SR-34BC/SR-34CC(220V-240V/3400W)
SR-34AWC/SR-34BWC(220V-240V/3400W)
If this product is found to be faulty as a result of faulty materials or
workmanship within one year from date of purchase, it will be repaired
This guarantee is subject to the following terms:
Sunpentown must be nofied of the fault. l
Proof of purchase must be presented to Sunpentown’s nominated representavel
The warranty will be void if the product if modified, misused or repaired by an l
The warranty aer repair will not be extended beyond the original one-year period. l
All replacement parts will be new or recondioned. l
Parts, which are replaced, become the property of Sunpentown. l
The warranty applies for the use of the product in the USA only. l
Warranty does not include freight charges. l
Incidental or consequenal damage caused by possible defects with this product. l
Damage to product caused by improper power supply voltage, accident,fire, l
Failure of product resulng from unauthorized modificaons to the product. l
Improper installaon or failure to perform the necessary maintenance. l
SUNPENTOWN INTERNATIONAL INC.
14625 Clark Ave. City of Industry, CA 91745
This GUARANTEE is in addion to your Statutory Rights
Thank you for purchasing your SMARTSCAN inducon cooker by Sunpentown. Make full use of
your new inducon range. Please carefully read this manual and keep on hand for future
CO
CO
CO
CO
CO O
O
O
O
OK
K
K
K
K
TE MP ON/O FF
l Please plug this cooktop in the correct 20-amp outlet.
l Do not share the outlet with other appliances and make sure
it is correctly plugged in.
l Do not touch the ceramic plate immediately aer cooking,
the plate may remain hot due to heat transferred from the
l Do not insert any object in the inlet or outlet to prevent
l Do not damage the ceramic plate.
l If the ceramic plate is broken, please turn unit off and unplug from outlet
l If the electric cord is damaged, please contact our service technician for a
l This appliance is equipped with overheat protecon feature.
l Those with a pacemaker should consult they physician before using this
l If the cooktop surface is broken or cracked, do not use the product as it may
If the cooktop is not working properly, please contact our service technician for
assistance. Do not disassemble the unit by yourself.
LIST OF SUITABLE / UNSUITABLE COOKWARE
l Do not drop the cookware on the top plate while cooking. The ceramic plate may
l Please use suitable cookware, otherwise abnormal cooking or damage may occur.
l The self-protect circuit will protect appliance while power is unstable. The power
red light will be flashing and cooking will stop.
Do not place any other arcles on the cooktop
plate except proper cookware.
Do not touch the ceramic plate aer cooking as
surface may retain heat from cookware.
Do not insert screwdriver or other metal parts
Do not damage the ceramic plate. If the ceramic
plate is broken, please turn off the unit and unplug
The operaon of this inducon cooktop has two funcons: COOK and TEMP.
In <COOK> Funcon (COOK indicator is on):
l LED displays a one or two digit number, indicang the power level (1-20)
l Unit will connuously cook unl: manually shut off.
In <TEMP> Funcon (TEMP indicator is on):
l LED displays a two or three digit number, indicang cooking temperature.
(90°F/32°C, 110°F/43°C, 130°F/54°C, 150°F/65°C, 170°F/76°C, 180°F/82°C,
200°F/93°C, 220°F/104°C, 240°F/115°C, 260°F/126°C, 270°F/132°C, 290°F/143°C,
310°F/154°C, 330°F/165°C, 350°F/176°C, 360°F/182°C, 380°F/193°C, 400°F/204°C,
420°F/215°C, 440°F/226°C)
l Unit will cook unl set temperature is reached and will keep warm.
l When set temperature is reached, unit will stop heang. Unit starts heang again when
it senses temperature has dropped below seng.
l Temperature difference: when cooking a large pot of soup or other contents, please be
advised that the temperature inside the pot will vary from point to point. For example,
the boom secon (closest to cooktop) will be a bit hoer than the middle secon. The
type and quality of cookware can affect temperature transfer.
1. Plug in power cord( refer to Specificaon on Page 10 for correct power input),
2. Please use suitable cookware and add food contents.
3. Press ON/OFF buon (red indicator light will illuminate, COOK mode by default).
4. Press COOK/TEMP buon to select seng
l COOK mode: LED displays power level: 1~20
l TEMP mode: LED displays temperature: 90~440°F/32~226°C
5.Turn knob clockwise/counter-clockwise to set power level or temperature.
6.When cooking is done, turn unit off by pressing ON/OFF buon.
l Safety feature: if no cookware is placed, unit will shut off aer 2 minutes.
l To avoid temperature jump, please cook at least 1 quart of food/content.
l Actual temperature (in TEMP mode) may vary slightly due to different variables,
such as:surrounding temperature, food content and volume, and if using a lid, etc.
l When using cookware that is not flat or with an uneven boom, the set temperature
will be VERY different from the actual temperature.
KEY POINTS BEFORE USING THE COOKTOP
Do not place one cooktop on top of another while plugged into power
Do not put heated oil in the pan while
If the cooking oil is not enough or an empty
pan is le on the cooktop for too long, it will
credit card,disc,watch or radio.
Place cooktop on flat surface,but keep away from
the wall or other arcles. for best results,leave
at least 4 inches from all sides.
When the air inlet or the air outlet is blocked,
the internal temperature of the cooktop rises and
stove. If the surrounding temperature is
high,cooktop will stop heang.
Warning: Changes or modificaons to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a consumer
ISM equipment, pursuant to Part 18 of the FCC Rules. These limits are designed to
provide reasonable protecon against harmful interference in a residenal installaon.
This equipment generates,uses,and can radiate radio frequency energy and, if not
installed and used in accordance with the instrucons, may cause harmful interference to
radio communicaons.However, there is no guarantee that interference will not occur
in a parcular installaon.If this equipment does cause harmful interference to
radio or television recepon, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
lReorient or relocate the receiving antenna.
lIncrease the separaon between the equipment and receiver.
lConnect the equipment into an outlet on a circuit different from that to which the
lConsult the dealer or an experienced radio TV technician for help.
This device complies with part 18 of the FCC rules.
Operaon is subject to the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operaon.
B. Do not touch hot surfaces. Use handles or knobs.
C. To protect against electrical shock, do not immerse cord or appliance in
D. Close supervision is necessary when any appliance is used by or near
E. Unplug from outlet when not in use and before cleaning. Allow to cool
before pung on or taking off parts.
F. Do not operate any appliance with a damaged cord or plug or aer the
appliance malfuncons or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examinaon, repair
G. The use of accessory aachments not recommended by the appliance
manufacturer may cause injuries.
I. Do not let cord hang over edge of table or counter, or touch hot surfaces.
J. Do not place on or near a hot gas or electric burner, or in a heated oven.
K. Extreme cauon must be used when moving an appliance containing hot
oil or other hot liquids.
L. Always aach plug to appliance first, then plug cord into the wall outlet. To
disconnect, turn any control to “off”, then removed plug from wall outlet.
M. Do not use appliance for other than intended use.
N. Save these instrucons.
NOTE: Do not use extension cord. If one must be used, use a cord with a
minimum of 14 gauge and no longer than 10 feet.
Overheat protecon. Automac hazard detecon. Circuit protecon
sensor. High voltage. 20A fuse. Small object heat prevenon. Thermostat.
14.17W x 17.7D x 5.08H in.
Page 1 Important Safeguards–
Page 6 Key Points Before Using the Cooktop–
Page 7 List of Suitable & Unsuitable Cookware–
If LED displays any of the following error codes, unit needs to be sent in for service:
EC,E0,E1,E2,E3,E4,E7,E8,E9.
Is the pan be placed on the induction
cooker? Or is it an induction compatible
Check if the voltage is low
Check if the voltage is high
Check if the IGBT sensor or relevant circuit was
Circuit board inner fan was broken or
the air inlet is blocked.
Check if the coil temperature sensor cable was
broken, or the plug is unplug.
Check the circuit board if the components
l Unplug the cord before any cleaning is done.
l To clean the ceramic plate, use a so sponge with dish detergent. Then
wipe clean with damp towel.
l Clean fan intake with vacuum whenever necessary.
DO NOT IMMERSE THE COOKTOP IN WATER TO SOAK. THIS
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instrucons, may cause harmful interference
to radio communicaons. However, there is no guarantee that interference will not
occur in a parcular installaon. If this equipment does cause harm to radio or television
recepon, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
l Reorient or relocate the receiving antenna.
l Increase the separaon between the equipment and receiver.
l Connect equipment to an outlet that’s on a different circuit than the receiver.
l Consult the dealer or an experienced radio/TV technician for help.
Changes or modificaons not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
