REV B DATE: 11/30/2022
USER MANUALS\21-27717_BLEND_USER MANUAL_NM(L)(H)HSSV_HTD_SELF-SVC_CASE
BLEND® SELF-SERVICE HEATED MERCHANDISERS
> THIS USER MANUAL IS APPLICABLE TO MODELS NM4855HSSV AND NM7255HSSV
> SOLID BACK UNITS WITH FIXED METAL PERFORATED PLENUM (SHOWN THROUGHOUT MANUAL)
> CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE WHILE MOVING INTO POSITION!
> ONLY USE CORNERS OF CASE TO PUSH OR PULL CASE INTO POSITION!
Model NM4855HSSV
Shown At Left
Model NM7255HSSV
Shown At Right
Note: See Blend® Case-To-Case
Adjoinment Guide P/N 21-26284 For
Lineup Options As Well As
Step-By-Step Lineup Instructions.
SCC P/N
21-27717
®
User
Manual
BLEND
READ AND SAVE THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS …………………………………………………………………………………...…...
OVERVIEW / DISPLAY TYPE I vs. II / COMPLIANCE / WARNINGS / PRECAUTIONS ……………...
INSTALLATION: DISCONNECTING CASE FROM SKID …………………………......……..…………...
INSTALLATION, CONT’D.: CASTER ADJUSTMENT / LOCK / UNLOCK / CASE REMOVAL
FROM SKID .………………………………………………………………………………...………….
INSTALLATION, CONT’D: ATTACHING FRONT AND SIDE TOE-KICKS ...…………………………...
INSTALLATION, CONT’D: SHELVING ASSEMBLIES / SHELVING RETAINER CLIP REMOVAL …
INSTALLATION, CONT’D: PLUG IN UNIT / TURN ON MAIN POWER SWITCH AND LED LIGHTS
SWITCH - MODEL NM4855HHSSV ONLY …………………….....………………………………..
INSTALLATION, CONT’D: PLUG IN UNIT / TURN ON MAIN POWER SWITCH AND LED LIGHTS
SWITCH - MODEL NM7255HHSSV ONLY …………………….....………………………………..
CASE DESIGN & FIELD SERVICE PARTS LIST - MODEL NM4855HSSV SECTION ONLY ……….
CASE DESIGN & FIELD SERVICE PARTS LIST - MODEL NM7255HSSV SECTION ONLY ……….
CASE STARTUP / HEATER SETTINGS / LIGHTS SWITCH / SHUTTING DOWN CASE ..…………..
PRODUCT PLACEMENT / AIRFLOW CONSIDERATION / LOAD LINES ………………………….…..
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ..…....…...…………...….
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER) ……....
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL ONLY) ...………………......
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ……….
SERIAL LABEL LOCATION & INFORMATION LISTED / TECHNICAL INFORMATION & SERVICE ...
PROGRAMMABLE CONTROLLER (SELECT, CLICK ON OR SCAN QR CODE FOR
INFORMATION) …………………………………………………………………….....……………….
STRUCTURAL CONCEPTS TECHNICAL SERVICE CONTACT INFORMATION & LIMITED
WARRANTY ………………………………………………………………………….....…...…...….....
