Side 1/23

REV L DATE: 07/26/2023

USER MANUALS\20-17518_FUSION_USER MANUAL_GHSS(L)(H)HLB_HTD SHELVING-DECK_SELF-SVC_CASE

Note: See Next Page For Partial List Of

Models That This Manual Is Applicable To.

FUSION HEATED SHELVING, SELF-SERVICE 55 1/4”, 60” and 66 1/4” TALL MERCHANDISERS

Standard 3-Shelf Model GHSS460H (Shown

Stocked For Illustrative Purposes Only)

Standard 3-Shelf Model GHSS656HLB

(With Stainless Steel Front Bumper)

Standard 3-Shelf Model GHSS856HLB

(With Stainless Steel Front Bumper)

Standard 3-Shelf Model GHSS456HLB

Optional Controls Placement (Either Front or Rear)

With LEDs (Instead of Incandescent Lights)

SCC P/N

20-17518

USER

MANUAL

FUSION

CAREFULLY FOLLOW THESE INSTRUCTIONS

Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com

TABLE OF CONTENTS

OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS .............…..

INSTALLATION: SKID REMOVAL / FRAME SUPPORT RAIL SHIMMING / LEVELER

ADJUSTMENTS ..………………………….…………………………………..…………………..…….

INSTALLATION, CONT’D: FIELD ACCESS WIRING CONNECTIONS/ SWITCHES /

THERMOMETERS …...………………………………………………………………………………….

INSTALLATION, CONT’D: IMPORTANT! HEATED SHELF “DANGER - HOT” LABEL PLACEMENT

REMOVING VERTICAL LOWER FRONT (OR REAR) PANELS …………………………………………..

START-UP, OPERATION & SHUTDOWN - MODEL GHSS460H & GHSS656HLB 3-SHELF UNITS

(FRONT ACCESS UNITS) / AUTHORIZED PERSONNEL ONLY! ..………………………………

START-UP & OPERATION - MODEL GHSS456HLB (REAR ACCESS UNIT) - AUTHORIZED

PERSONNEL ONLY! ..……………………………………………………………………………………

START-UP & OPERATION - MODEL GHSS460HLB 3-SHELF UNIT (FRONT ACCESS UNIT)

AUTHORIZED PERSONNEL ONLY! ..………………………………………………………………..

START-UP & OPERATION - MODEL GHSS660H 4-SHELF UNIT (FRONT ACCESS UNIT)

AUTHORIZED PERSONNEL ONLY! …………………………………………………………………

DOOR REMOVAL (OPTIONAL) / DECK, SHELVING, OVERHEAD DIFFERENTIATION ………...…...

INCANDESCENT LAMP FIXTURES / REPLACEMENT GUIDELINES ……….…………………………..

OPTIONAL LED LIGHTS / SWITCH / LED LIGHT FIXTURES / LED REMOVAL and

REPLACEMENT ………………………………………………………………………………………...

VAPOR THERMOMETER ……………………………………………………………………………………….

CLEANING SCHEDULE (DAILY / WEEKLY) - CASE EXTERIOR .………………………….……..……..

CLEANING SCHEDULE (DAILY / WEEKLY) - CASE INTERIOR ………………………………………....

CLEANING SCHEDULE (DAILY / WEEKLY) - CASE EXTERIOR & INTERIOR: STAINLESS STEEL

TROUBLESHOOTING ….…………………………………………………..………………...…………..……..

SERIAL LABEL & LOCATION / TECHNICAL INFORMATION / ADD’L INFORMATION ……..……….

PROGRAMMABLE CONTROLLER (SELECT, CLICK ON OR SCAN QR CODE FOR INFO)…………

TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ..…….………........

3-4

This Manual Is Applicable To The Following Models*

GHSS452HLB / GHSS456HLB / GHSS460H / GHSS460HLB / GMSS467H / GMSS667H

GMSS867H / GHSS652HLB / GHSS656HLB / GHSS660H / GHSS856HLB

*This Manual May Be Applicable To Models Not Listed Above or Herein.
