Side 1/37
G-SERIES MID-VOLUME REFRIGERATED SERVICE DELI MERCHANDISERS
> VERTICAL FRONT GLASS WITH REAR HINGES
> VERTICAL FRONT GLASS WITH FRONT HINGES
> REMOTE & SELF-CONTAINED > FULL AND OPEN END PANELS
> REFRIGERATED-TO-DRY SWITCH AT CASE REAR (OPTIONAL)
> REAR SLIDING DOORS > OPTIONAL SCALE STAND
Rev F Date: 7.2.2021 Operating Manuals\Standard\G-Series_Mid-Volume Ref Svc Deli_Vertical Glass_Rear Hinges_21-01524.pub
Structural Concepts Corporation ∙ 888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION AND
OPERATING MANUAL
G-SERIES P/N 21-01524
GMDSV6R.7115C
GMDSV4R
GMDSV12R.7183
GMDSVC3R
GMDSV8R
CAUTION!
FRAGILE!
HOLD
GLASS
FIRMLY.
SLOWLY
OPEN &
CLOSE.
CAUTION!
FRAGILE!
DO NOT
STRIKE
DECKS
OR PANS
AGAINST
EDGE OF
GLASS.
GLDSV4R
GLDSV6R.6670C
GMDSV4R.7503
2
TABLE OF CONTENTS / LIST OF MODELS INCLUDED IN MANUAL
TABLE OF CONTENTS / LIST OF MODELS ENCOMPASSED IN MANUAL ……….……………………………….
OVERVIEW / UNIT TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING …..……….………………...
INSTALLATION: REMOVAL FROM SKID, REMOVING LOWER FRONT PANELS ..……...…….……..………….
INSTALLATION, CONT’D: CASE ADJOINMENT INSTRUCTIONS ……………….………….………………………
INSTALLATION, CONT’D: FRAME SUPPORT RAIL SHIMMING ..……………………………………......................
INSTALLATION, CONT’D: FRONT GLASS ALIGNMENT & ADJUSTMENT (VIA RAIL SYSTEM) .………………
INSTALLATION, CONT’D: FRONT GLASS, UPRIGHT and TOP BOARD ADJUSTING - APPLICABLE TO
MODELS GLDS & GLDSV ONLY ………...…………………………………………………………………….
INSTALLATION, CONT’D: FIELD WIRING BOX / RACEWAY / LED DRIVER / ANTI-CONDENSATE FANS …..
INSTALLATION, CONT’D: REFRIGERATION LINES / STUB-UPS / DRAINS ……..…………….….………………
INSTALLATION, CONT’D: SCALE STAND WITH OUTLETS & CAT5 / FLIP-UP LEDGE ………….……………..
START-UP AND OPERATION ………………..…………………………………………………………………………...
MAINTENANCE FUNDAMENTALS: LED LIGHT FIXTURES / REMOVAL & REPLACEMENT…………………...
MAINTENANCE FUNDAMENTALS, CONT’D: SHELF ASSEMBLIES ………………………………....…………….
MAINTENANCE FUNDAMENTALS, CONT’D: DRAIN, TXV VALVE ACCESS ………………………....…………..
MAINTENANCE FUNDAMENTALS, CONT’D: REAR SLIDING DOORS ……………………………….……………
MAINTENANCE FUNDAMENTALS, CONT’D: REAR HINGED FRONT GLASS …………………………………...
MAINTENANCE FUNDAMENTALS, CONT’D: FRONT HINGED GLASS DOORS ………………………………….
MAINTENANCE FUNDAMENTALS, CONT’D: REFRIGERATED TO DRY SWITCH (OPTIONAL) ……………….
MAINTENANCE FUNDAMENTALS, CONT’D: CUTTING BOARD / REAR LEDGE REMOVAL ...………………..
MAINTENANCE FUNDAMENTALS, CONT’D: CONDENSATE PACKAGE LAYOUT ……………….…………….
CLEANING SCHEDULE - INTERIOR: TO BE PERFORMED BY STORE PERSONNEL .………………………….
CLEANING SCHEDULE - EXTERIOR: TO BE PERFORMED BY STORE PERSONNEL ………….……………...
CLEANING SCHEDULE -STAINLESS STEEL: TO BE PERFORMED BY STORE PERSONNEL ………………..
PREVENTIVE MAINTENANCE: TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY .................
TROUBLESHOOTING: TO BE PERFORMED BY STORE PERSONNEL UNLESS NOTED OTHERWISE ….....
TROUBLESHOOTING: TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY………………….
TROUBLESHOOTING: CONDENSING SYSTEM (PERFORMED BY TRAINED SERVICE PROVIDERS ONLY)
TROUBLESHOOTING: EVAP. SYSTEM (PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) .………..
SERIAL LABEL INFORMATION & LOCATION ..……………………………………...…....…………………...….…..
CAREL® TEMPERATURE CONTROLLER INFORMATION ………………………………………….….…………...
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ...……….…........................
2
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27-29
30
31
32
33
34-36
37
--- THIS OPERATING MANUAL INCLUDES (BUT IS NOT LIMITED TO) THE FOLLOWING MODELS ---
GLDSV3R
GLDSV3R.6602
GLDSV4R
GLDSV6R
GLDSV8R
GLDSV8R.7183
GLDSV10R
GLDSV10R.6670A
GMDSV10R.7115E
GLDSV12R
GMDSV12R.7694
GLDSV442R.6670F
GLDSV542R.7042B
GLDSV642R.6670C
GLDSV842R.6670B
GLDSV842R.7042D
GLDSV1242R.6670D
GLDSV1242R.6839F
GLDSV1242R.7042F
GLDSV1242R.7186F
GMDSESV8R
GMDSESV12R
GMDSV3R.6694
GMDSV4R
GMDSV4R.6806A
GMDSV4R.6694
GMDSV4R.6749B
GMDSV4R.6924
GMDSV4R.7215
GMDSV4R.7503
GMDSV5R.7215
GMDSV6R
GMDSV6R.6694
GMDSV6R.6806C
GMDSV6R.7115C
GMDSV8R
GMDSV8R.6694
GMDSV8R.6749A
GMDSV8R.7063B
GMDSV8R.7115D
GMDSV8R.7183
GMDSV8R.7215
GMDSV8R.7896
GMDSV8R-RD
GMDSV10R.6806E
GMDSV10R.7215
GMDSV12R
GMDSV12R.7063D
GMDSV12R.7115F
GMDSV12R.7215
GMDSV12R.7280
GMDSV12R.7695
GMDSVC3R.6694
GMDSVC3R.7215
GMDSVC4R
GMDSVC4R.7215
