Side 1/35

FUSION SERVICE REFRIGERATED MID-VOLUME DELI MERCHANDISERS > FLAT ANGLED FRONT GLASS

> CURVED FRONT GLASS > VERTICAL FRONT GLASS > REAR LIFT FRONT GLASS > REMOTE & SELF-CONT.

> FULL AND OPEN END PANELS > REFRIGERATED-TO-DRY SWITCH AT CASE REAR (OPTIONAL)

REV AB DATE: 07/07/2023

USER MANUALS\5-9410_FUSION_USER MANUAL_GMDS_GMDSES_GMDSNA_GMDSV_REF_SVC_DELI_CASE

Model GMDSX4R

Model GMDS6R

With Rear Sliding Doors

GMDS6R.5773D No Rear Sliding

Doors / Rear Flip-Up Ledge

Model GMDSES6R / End Panel

Removed / Front & Rear Shelves /

Variety of Product Steps

GMDSNA4R.5773M

45° Inside Wedge

Note: See Next Page For

Various Models That This

User Manual Is Applicable.

Model GMDSX4R.5773J /

Rear Hinged Door /

Curved Front Panel

Model GMDS10R.5773F / Open Rear Section /

Curved Front Panel / Flip-Up Ledges / Scale Stand

Model GMDSES8R / End Panel Removed /

Optional Case-To-Case Glass / Front &

Rear Shelves / Variety of Product Steps

GMDSV4R / Front Vertical Glass

(Top-Hinge) /Rear Sliding Doors /

Optional Scale Stand

Model GMDSVX9R.6694

Radius Corner / Curved Front /

4 Swinging Front Doors

GMDS10R.7673 / Curved Front

Glass / Rear Sliding Doors /

Optional Rear Ledge /

Rear Storage Bins

SCC P/N

5-9410

USER

MANUAL

FUSION

CAREFULLY FOLLOW THESE INSTRUCTIONS

Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com

TABLE OF CONTENTS / LIST OF MODELS INCLUDED IN MANUAL

TABLE OF CONTENTS / LIST OF MODELS ENCOMPASSED IN MANUAL ……….………………….…..

OVERVIEW / UNIT TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING …..……….……...

INSTALLATION: REMOVAL FROM SKID, REMOVING LOWER FRONT PANELS ..……...…….…….….

INSTALLATION, CONT’D: BOLTING AND CAULKING UNITS TOGETHER ……………….………...……

INSTALLATION, CONT’D: POSITIONING & ALIGNING CASE / FRAME SUPPORT RAIL SHIMMING ..

INSTALLATION, CONT’D: FRONT GLASS ALIGNMENT & ADJUSTMENT (VIA RAIL SYSTEM) ……...

INSTALLATION, CONT’D: PROBE LEADS BOX / FIELD WIRING BOX / BALLAST (OR OPTIONAL

LED DRIVER) / ANTI-CONDENSATE AXIAL FANS .…………………………………………..….….

INSTALLATION, CONT’D: REFRIGERATION LINES / STUB-UPS / DRAINS ……..…………….….……..

INSTALLATION, CONT’D: SCALE STAND WITH OUTLETS & CAT5 / FLIP-UP LEDGE ………….……..

START-UP AND OPERATION ………………..………………………………………………………………….

MAINTENANCE FUNDAMENTALS: LED LIGHT FIXTURES / REMOVAL & REPLACEMENT...………..

MAINTENANCE FUNDAMENTALS, CONT’D: SHELF ASSEMBLIES ………………………………....……

MAINTENANCE FUNDAMENTALS, CONT’D: SHELF ASSEMBLIES / STEPS ………………….………..

MAINTENANCE FUNDAMENTALS, CONT’D: DRAIN, TXV VALVE ACCESS ………………………....….

MAINTENANCE FUNDAMENTALS, CONT’D: REAR SLIDING DOORS ……………………………….…..

MAINTENANCE FUNDAMENTALS, CONT’D: REAR LIFT FRONT GLASS ………………………………..

MAINTENANCE FUNDAMENTALS, CONT’D: REFRIGERATED TO DRY SWITCH (OPTIONAL) ……...

MAINTENANCE FUNDAMENTALS, CONT’D: CUTTING BOARD / REAR LEDGE REMOVAL ...……….

MAINTENANCE FUNDAMENTALS, CONT’D: REFRIGERATION PACKAGE LAYOUT ……………….…

MAINTENANCE FUNDAMENTALS, CONT’D: REMOTE UNIT FIELD ACCESS BOX / MISTING

SYSTEMS…………………………………………………………………………………………………...

CLEANING SCHEDULE - INTERIOR: TO BE PERFORMED BY STORE PERSONNEL .………………...

CLEANING SCHEDULE - EXTERIOR: TO BE PERFORMED BY STORE PERSONNEL ………….……..

CLEANING SCHEDULE -STAINLESS STEEL: TO BE PERFORMED BY STORE PERSONNEL ……...

PREVENTIVE MAINTENANCE - TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY ....

TROUBLESHOOTING - TO BE PERFORMED BY STORE PERSONNEL (UNLESS NOTED

OTHERWISE) ……………………………………………………………………………………………...

TROUBLESHOOTING - CONDENSING SYSTEM (TO BE PERFORMED BY TRAINED SERVICE

PROVIDERS ONLY) ……………………………………………………………………………………...

TROUBLESHOOTING - EVAPORATOR SYSTEM (TO BE PERFORMED BY TRAINED SERVICE

PROVIDERS ONLY) ………………………...……………………………………………………….…...

SERIAL LABEL INFORMATION & LOCATION ..……………………………………...…....…………..….…..

PROGRAMMABLE CONTROLLER INFORMATION ……………………..……………………………….…..

TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ….……….…............

3-5

16-17

29-30

THIS OPERATING MANUAL INCLUDES (BUT IS NOT LIMITED TO) THE FOLLOWING MODELS:

GMBS552R GMBS652R GMDS2R.5773 GMDSNA4R.5773M GMDS4R GMDS4R.5068 GMDS4R.5773B

GMDS5R GMDS5R.5773C GMDS6R GMDS6R.5241 GMDS6R.5773D GMDS8R GMDS8R.5182

GMDS8R.5243A GMDS8R.6803D GMDSES6 GMDSES8R GMDSES12R GMDS10R GMDS10R.5243

GMDS10R.5773F GMDS10R.7673 GMDS12R GMDS12R.5241A GMDSV3D.6694 GMDSV3R.6694

GMDSV4R.6749B GMDSVC3R GMDSVC6R GMDSVC6R.6694 GMDSVC8R GMDSVC8R.6694

GMDSVCX9R.6694 GMDSVX4R GMDSX4R GMDSX4R.5773J GMDSVX4R.7215 GMDSX9R

GMDSVX9R GMDSVX9R.6694 and GMDSVX9R.7215.
