Manual Is Applicable To The Following Models*
GMGX4, GMG4, GMG6, GMG8, GMG8.6552,
GMG12, GVGV4, GMGV8 and GMGV12
*Note: This manual may also be applicable
to models NOT listed herein.
FUSION GMG GRAVITY & BLOWER COIL MEAT & SEAFOOD REFRIGERATED SERVICE UNITS
REV N DATE: 7/6/2023
USER MANUALS\5-4467_FUSION_USER MANUAL_GMG_GRAVITY COIL_MEAT-SEAFOOD_CASE
Model GMG4 Seafood Case: Remote
Unit ||| Rear Sliding Doors Removed.
Ice Pans Used (Instead of Wire
Racks as used in Meat Case Models
GMG6, GMG8 and GMG12)
Model GMG12 Meat Case: Remote Unit / Rear Sliding
Doors Removed. Wire Racks Used (Instead of Ice Pans
As Used in Seafood Model GMG4)
Model GMG12 Hybrid Unit Meat Case: Remote Unit / Gravity Coil (Upper),
Evaporator Coil (Lower) and Shelf / Rear Sliding Doors Removed. Wire
Racks Used (Instead of Ice Pans as used in Seafood Model GMG4)
Model GMG6 Meat Case:
Self-Contained Unit ||| Rear
Sliding Doors Intact / Wire
Racks Used (Instead of Ice
Pans Used In Meat
Case Models GMG4)
Model GMGX4 Blower Coil
Wedge Case: Remote Unit /
Single Rear Hinged Door / Ice
Pans Used (Instead of Wire
Racks as used in Meat Case
Models GMG6, GMG8
and GMG12)
Model GMGV12: Remote Service Unit / Mid-Volume Angled Back
With Gravity Coil and Vertical “Lift-Up” Front Glass / Rear Sliding
Doors (Shown Removed) / Ice Pans Used (Instead of Wire Racks
as used in Meat Case) / Optional Paper Roller
Model GMG4.6552: Remote Unit
Mid-Volume Angled Back Deli Case
With Gravity Coil and Scale Stand
Model GMGV4
Blower Coil Case:
Self-Contained
Unit / Wire Racks
SCC P/N
5-4467
USER
MANUAL
FUSION
CAREFULLY FOLLOW THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS / APPLICABLE MODELS
2
3-5
6
7-8
9
10
11
12
13
14
15
16
17-18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33-35
36
37-39
40
41
42
TABLE OF CONTENTS / APPLICABLE MODELS ..…………………………………………………...……….
OVERVIEW / TYPE I vs. TYPE II UNITS / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING .......
INSTALLATION: REMOVAL FROM SKID, REMOVING LOWER FRONT PANEL / REAR PANEL ……….
INSTALLATION, CONTINUED: POSITIONING & ALIGNING CASE / BOLTING & CAULKING UNITS
TOGETHER ………………………………………………………………………………………………..
INSTALLATION, CONTINUED: FRAME SUPPORT RAIL SHIMMING .……………………………………...
INSTALLATION, CONTINUED: FRONT GLASS ALIGNMENT & ADJUSTMENT (VIA RAIL SYSTEM) ….
INSTALLATION, CONTINUED: PROBE LEADS BOX / FIELD WIRING BOX / BALLAST (OR
OPTIONAL LED DRIVER) / AXIAL FANS …………….………………………………………………...
INSTALLATION, CONTINUED: THERMOMETER PLACEMENT & PURPOSE / SCALE STAND /
CAT-5 / OUTLETS………………………………………………………………………………………….
OPERATION: WIRE RACKS ACCESS AND REMOVAL (MEAT CASES ONLY) - PAGE 1 of 2 .................
OPERATION: ICE TRAY ACCESS AND REMOVAL (MEAT CASES ONLY) - PAGE 2 of 2 ……………….
OPERATION: REFRIG. LINES ROUTING / DRAINS / TXV (SEAFOOD CASES ONLY) PG 1 of 2 ………
OPERATION: ICE TRAY ACCESS AND REMOVAL (SEAFOOD CASES ONLY) - PG 2 of 2 .....................
OPERATION: MODEL GMGX4 BLOWER COIL WEDGE UNIT ONLY ………………………………………
OPERATION: REFRIGERATION LINES / STUB-UPS / DRAINS (GMG8 MODEL) - PG 1 of 2 ..…………..
OPERATION: REFRIGERATION LINES / STUB-UPS / DRAINS (GMG12 MODEL) - PG 2 of 2 .………….
OPERATION: HYBRID CASE GRAVITY COILS, EVAPORATOR COILS, SHELVING / LAYOUT .………..
OPERATION: SELF-CONTAINED MODEL MEAT CASE REAR DRAIN/TEMP. CONTROLLER …………
OPERATION: SELF-CONTAINED MODEL SEAFOOD CASE DRAIN/TEMP. CONTROLLER …………...
OPERATION: DISPLAY CASE START-UP / LIGHT SWITCHES ……………………………………………..
STOCKING / MAINTAINING PROPER PRODUCT CONDITION / IMPORTANT PROCEDURES ……......
MAINTENANCE FUNDAMENTALS: DISPLAY SHELVES AND BRACKETS …………………………….....
MAINTENANCE FUNDAMENTALS: REAR SLIDING DOORS / T-8 LIGHT FIXTURES /
SUPPLEMENTAL FLOOD LIGHTING & SUPPLEMENTAL SPOT or FLOOD LIGHTING ……..….
MAINTENANCE FUNDAMENTALS: LED LIGHT FIXTURES / REMOVAL & REPLACEMENT ……..…….
MAINTENANCE FUNDAMENTALS: PRODUCT PLACEMENT TO MAINTAIN PROPER AIRFLOW …….
MAINTENANCE FUNDAMENTALS: CUTTING BOARD (REAR LEDGE) REMOVAL / PAPER
ROLLER (OPTIONAL) …...…………...................................................................................................
CONDENSER PACKAGE (HEATER ROD EVAPORATOR PAN) ...………………………….…………..….
CONDENSER PACKAGE (HOT GAS LOOP EVAPORATOR PAN / HEATER ROD OVERFLOW PAN) ...
CLEANING SCHEDULE (INTERIOR) - TO BE PERFORMED BY STORE PERSONNEL………...…….....
CLEANING SCHEDULE (EXTERIOR) - TO BE PERFORMED BY STORE PERSONNEL……..…..……...
TROUBLESHOOTING - GENERAL ISSUES ………………………………………..…………...……………..
SERIAL LABEL INFORMATION & LOCATION ..……………………………………...…....………….………..
PROGRAMMABLE CONTROLLER INFORMATION….………………………………………...….……..........
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ...……….…...............
Note: This Manual Is Applicable To The Following Models: GMGX4, GMG4, GMG6, GMG8, GMG8.6552,
GMG12, GVGV4, GMGV8 and GMGV12. It May Also Be Applicable To Models NOT Listed Herein.
