Side 1/30
FUSION REFRIGERATED SELF-SERVICE MEDIUM VOLUME MERCHANDISERS*
REV N: 05/18/2023
USER MANUALS\20-18548_FUSION_USER MANUAL_GMSS_GMSSEH_GMSSV_REF_SELF-SVC_MED-VOL_CASE
Please Note:
1. Your specific model number is located on the serial label. Serial labels are affixed at a wide range of
places (on the header, near thermostat, at case rear, behind panels/toe-kicks, on electrical boxes, etc.).
2. See SERIAL LABEL INFORMATION & LOCATION in this User Manual for sample serial label.
3. Cases shown in this User Manual may differ from models chosen with different features or options.
Model GMSS1252R
Model GMSSEH852R
Model GMSS352R.8110**
Model GMSS852R With Optional
Metal Security Grid
*For a list of models represented by this User
Manual, see page 2. **Details of Model
GMSS352R.8110’s unique shelving, product
dispensers & product stops are on page 10.
SCC P/N
20-18548
USER
MANUAL
FUSION
CAREFULLY FOLLOW THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
OVERVIEW / CONDITION TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING .......….
INSTALLATION: SKID REMOVAL, POSITIONING AND LEVELING CASE ………………….....……..
INSTALLATION, CONTINUED: BOLTING and CAULKING UNITS TOGETHER …………………..….
INSTALLATION, CONTINUED: FRAME SUPPORT RAIL SHIMMING ……………………………...…..
ELECTRICAL CONNECTIONS / FIELD WIRING BOX / LIGHT BALLASTS / TERMINAL STRIP ......
REFRIGERATION LINES / STUB-UPS / DRAINS …...……………………………………………………..
MODEL GMSS352R.8110 SHELVING SPECIFICS, PRODUCT DISPENSERS AND PRODUCT
STOPS …………………………………………………………………………………………………...
CONDENSER PACKAGE (SELF-CONTAINED UNITS ONLY): MODEL GMSS852R ...………………
CONDENSER PACKAGE (SELF-CONTAINED UNITS ONLY): MODEL GMSS352R.8110 ……….....
FIELD ACCESS BOX / ELECTRICAL COMPONENTS / PROGRAM. CONTROLLER, ETC. -
MODEL GMSSEH852R .………………………………………………………….….………...….……
FIELD ACCESS BOX / ELECTRICAL COMPONENTS / PROGRAM. CONTROLLER, ETC. -
MODEL GMSSEH1252R …………………………………………………………………….……….
FIELD ACCESS BOX / ELECTRICAL COMPONENTS / PROGRAM. CONTROLLER, ETC. -
MODEL GMSS852R …………………………………………………………………………………….
FIELD ACCESS BOX / ELECTRICAL COMPONENTS / PROGRAM. CONTROLLER, ETC. -
MODEL GMSS352R.8110 ……………………………………………………………………………...
START-UP AND OPERATION / THERMOMETER LOCATION AND FUNCTION ……………………..
MAINTENANCE FUNDAMENTALS, CONT’D: LED LIGHT FIXTURES ………………………………...
MAINTENANCE FUNDAMENTALS, CONT’D: EVAPORATOR FANS, REFRIGERATION LINES,
TXV & DRAIN ACCESS ……………………………………………………………………………….
MAINTENANCE FUNDAMENTALS, CONT’D: SHELF ASSEMBLY & UNDER CASE CLEANING ...
MAINTENANCE FUNDAMENTALS: HONEYCOMB AIR DIFFUSERS ………………………………….
CLEANING SCHEDULE TO BE PERFORMED BY STORE PERSONNEL (UNLESS SPECIFIED
OTHERWISE) ..…..…...…............................................................................................................
TROUBLESHOOTING - GENERAL ……………………………………..………………...…..………….….
TROUBLESHOOTING - CONDENSING SYSTEM ………………………………………………………….
TROUBLESHOOTING - EVAPORATOR SYSTEM …………………………………………………………
SERIAL LABEL INFORMATION & LOCATION …….……………………..………………….……...…….
PROGRAMMABLE CONTROLLER INFORMATION ..…………………………………………………….
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ………………......
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22-23
24-25
26
27
28
29
30
The Following Models Are Represented By This Manual:
GMSS352R.8110, GMSS452R, GMSS552R, GMSS652R, GMSS852R, GMSS1052R, GMSSEH852R,
GMSS1052R, GMSS1252R, GMSSEH1252R, GMSSV452R GMSSV552R, GMSSV652R, and GMSSV852R.
Note: This manual may also be used for models not listed above.
