REV A DATE: 5/22/24
21-33897 OASIS REF SELF-SERVICE MI-EN-A-052224
SELF-SERVICE MULTI-PURPOSE REFRIGERATED ISLAND DISPLAY CASES
> Note: See Next Page For List of Models To Which This Manual Applies
Important!
See Page 13
For Product And
Signage Placement
Guidelines!
MI48R / Removable Exterior Panels /
No Acrylic Airflow Risers or Dividers
MI36R
MI44R
MI33R
USER
MANUAL
PN 21-33897
OASIS
READ AND SAVE THESE INSTRUCTIONS
®
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
MI46R
2
TABLE OF CONTENTS
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS .............…..
CASE REMOVAL FROM SKID (LOCKING/UNLOCKING CASTERS) ……………………..………….…..
EXTERIOR PANEL ATTACHMENT (AFTER REMOVAL FROM SKID AND PROPERLY
POSITIONED) …………………………………………………………………………………….……..
POSITIONING-LEVELING UNIT / START-UP / TEMPERATURE CONTROL / 41 °F & 38 °F
SWITCH ………………………..…………………………………………………………………….…..
ADJUSTABLE ACRYLIC DIVIDERS / FIXED ACRYLIC DIVIDERS / HORIZONTAL GLASS
FIXTURES …………………………………………………….………………………………………....
EVAPORATOR SECTION ACCESS: BAFFLED DECK PAN ASSEMBLIES / THERMOMETER .…......
EVAPORATOR SECTION ACCESS, CONT’D: LOWER DECK PAN REMOVAL / EVAPORATOR
SECTION COMPONENTS ………………………………………………………………………….….
LOAD LIMIT (LOAD LINE) GUIDELINES / CASE FRONT & REAR DESIGNATIONS /
THERMOMETER ………………………………………………………………………………….…….
PRODUCT AND SIGNAGE PLACEMENT GUIDELINES …………………………………………………..
REFRIGERATION FUNDAMENTALS - REFRIGERATION. PACKAGE / TEMPERATURE
CONTROLLER / EVAPORATOR PAN ACCESS ……...……………………………….…………...
CONDENSER PACKAGE EXPLODED PICTORIAL - WITH SMALL HOT GAS LOOP
CONDENSATE UNIT …..……………………………………………………………………………...
CONDENSER PACKAGE EXPLODED PICTORIAL - WITH LARGE HOT GAS LOOP
CONDENSATE UNIT ...………………………………………………………………………………...
CLEANING SCHEDULE …………….………………….……………………………….…………………….
PREVENTIVE MAINTENANCE (PERFORMED BY TRAINED SERVICE PROVIDER) ………………...
TROUBLESHOOTING (GENERAL) ..………………….………………………………….……….………….
SERIAL LABEL LOCATION & INFORMATION LISTED / TECH INFO & SERVICE …………..………..
PROGRAMMABLE CONTROLLER INFORMATION…... …….…………………………………………….
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ...……………..…
3-6
7
8
9
10
11
12
13
14
15
16
17
18
19-24
25-26
27
28
29
This Operating Manual Applies To The Following Models*:
MI3R.5429, MI3R.6212B, MI36R, MI5R, MI6R, MI6R.6212C, MI6R.6620, MI6R.7065, MI8R,
MI8R.6212A, MI32R, MI33R, MI36R, MI44R, MI44R.7523, MI45R, MI46R, MI48R & MI48R.7788
*Note: Manual May Also Apply To Additional Models Not Listed Herein.
